Imao corporation mechanical clamping elements

... -profile cam edge clamp for quick workpiece setup. Spiral cam provides quick clamping just by turning the handle. The jaw pushes workpiece forward and downward with max 6000N. The minimum jaw height ...

Clamping force: 220 N

... the handle provides secure clamping. Available for 10, 12, 14, 15, 16 and 20mm diameter shaft. -More Efficient Than Conventional Method As the handle is turned down, it pushes the locking block toward the shaft for ...

Clamping force: 400, 200 N

ONE TOUCH PUSH LOCK CLAMPS Quick & easy lock with constant clamping force Feature ・The piston pushes out to clamp the object such as steel bar or shaft by turning the handle. ・The ...

Clamping force: 0.8 kN - 1.2 kN

Manual swing clamp for quick workpiece setups without using tools. The clamp arm swings into position over the workpiece and clamps straight down just by turning the handle. Spiral cam ...

Clamping force: 700 N - 1,100 N

... Ideal for machining, assembly and inspection fixture. Can clamp both rough and finish surfaces. Clamp arm moves forward to clamp and backward to unclamp. Clamping ...

Clamping force: 2,400 N - 4,200 N

... fixture. Clamp arm moves forward to clamp and backward to unclamp. Clamping force: 2400 to 4200N Allowable operating load of handle: 170 to 200N Materials: Body, Spindle: S45C ...

Clamping force: 500 N - 1,400 N

Clamping stroke is long by thrusting of clamping bar and can clamp recessed part. (For horizontal use) Can hold workpiece by a clamping bar with easy handle swing ...

Clamping force: 300 N - 700 N

... easy operation! Spiral cam provides quick & secure clamping. The simple design keeps cost low and the small size allows more workpieces per load. Minimum body size is only 12 mm + R25 mm small clamp ...

Clamping force: 2 kN - 3.5 kN

HOOK CLAMPS -Features- -Strong & very compact clamp for machining. -Available in 2 thread sizes of M4 or M6. -Compact design for applications in limited space -Clamp that is designed to move up ...

Clamping force: 2 kN - 3.5 kN

HOOK-CLAMP ASSEMBLIES -Feature- -The hook clamp is designed to move up and down in conjunction with the tightening screw, for prevention of galling in the hook-clamp holder. -Materials- Clamp ...
