Baldor's line of brake motors are available in totally enclosed fan cooled, open drip proof, or explosion proof designs, in either single or three phase. Stock ratings are available from .25 horsepower through 30 horsepower. These motors use a mechanical spring set brake with a manual release. Brake motors may be used on machine tools, conveyors, door operators, speed reducers, hoists, or any application requiring quick stops and positive holds.
|
|
Delphi ATDC series self-braking motors use spring-pressure brakes, firmly spliced onto a cast iron shield at the back of the motor.
These motors include:
+ The hand release lever that permits to release the brake, making it possible to move the shaft.
+ The separate brake power supply that is achieved, whenever needed, by connecting directly to the brake terminal board located inside the motor terminal box.
+ The PTO thermal protectors in the winding
Delphi ATDC series maintain also the peculiarities described in the Delphi series catalogue
|
|
The IEC-normalized BN motors comply with all the applicable international standards, including the EMC and LV Directives. They are available in the 0.06 - 30 kW range in the foot and the flange mounting version, the latter in both the IM B5 and the IM B14 configuration. Single and dual pole version available with generally, three brake options offered, one DC and two AC supply, lending further flexibility to the system. Finally, all motors are inverter duty.
|
|
|
|
|
|
ASYNCHRONOUS BRAKE MOTORS
- General use single phase:
LS FMC : DC - Aluminium alloy housing
- General use three-phase:
LS FCR : Aluminium alloy housing
LS FAP : Alternating current - Aluminium alloy housing
LS FCPL : DC - Aluminium alloy housing
LS FMC : DC - Aluminium alloy housing
FLS FCR : Cast iron housing
FLS FAP : Alternating current - Cast iron housing
FLS FCPL : DC - Cast iron housing
- Lifting use:
LS FCR (UL) : Aluminium alloy housing
LS FCPL (UL) : DC - Aluminium alloy housing
- Translation use:
LS FCR (UT) : Aluminium alloy housing
LS FCPL (UT) : DC - Aluminium alloy housing
- Variable speed:
LS VARMECA FCR : Decentralised variable speed
LSMV FCR : Centralised variable speed
LSMV FCPL : Centralised variable speed - Continuous current
- Atex:
LSPX FCR : Dust ATEX Zone 21 - Aluminium alloy housing
FLSPX FCR : Dust ATEX Zone 21 - Cast iron housing
- Variable speed Atex:
LSPX VARMECA FCR : Dust ATEX Zone 21 - Decentralised variable speed
LSMVPX FCR : Dust ATEX Zone 21 - Centralised variable speed
LS VARMECA FCR Zone 22 : Dust ATEX Zone 22 - Decentralised variable speed
LSMV FCR Zone 22 : Dust ATEX Zone 22 - Centralised variable speed
- Food industry:
LSiA FCR : Enclosed three-phase brake motors
- Machine tool:
LS FCR (MO) : Machine tool enclosed three-phase brake motors
Guaranteed availability - Please determine reception date !!!
|
|
Standard Features
Output: 0.12 up to 7.5kW
Multivoltage – (220-240/380-415//440-460V or 380-415/660-690//440-460V)
Self Ventilated (TEFC)
EFF2 Improved Efficiency
Cast Iron Frames (63 up to 132M)
Mounting: B3T
Degree of Protection: IP55
Terminal block
Squirrel cage rotor/ Aluminium die cast
V´Ring on both endshields
Stainless steel nameplate AISI 316
Class “F” insulation
Continuous duty
Ambient temperature: 40ºC, 1000 m.a.s.l.
Metric thread cable entries in terminal box
Suitable for Inverter Duty applications*
Paint color: RAL 5007
*For additional details about Inverter operation, please contact our technical support.
*Special Insulation for voltage above 575V
Optional Features
Single Voltage (other voltages)
Other mounting configurations
Thermal protection:
Thermistors for frame 132S and below (Standard for frame 160 and above)
Thermostats
RTD-PT 100
Space heaters
Class “H” insulation
|
|
|
With the X-Class, Force Control transforms oil-shear technology into affordable, off-the-shelf designs. Four standard models-XB1, XB2, XB3, and XB4, covers the most popular size range for brakes. Convenient double C-face or motor brake mounting and Clamped-Split-Quill allows drop-in, bolt-up installation.
|
|
Design with single-disk, spring brake
Main applications machine tools, timber processing, drive technology, transmission, process technology
Special applications winches, jetways, elevators, stage equipment, printing machines, packaging machines
Performance range 0,06 - 37 kW
Size 56 - 200
|
|
|
Grove Gear offers a lightweight alternative to both cast iron worm and coaxial (inline) helical gear reducers. Although there are pros and cons to cast iron and aluminum, one application might strongly lean toward cast iron where another may require only aluminum construction. The Grove designed aluminum gear reducers have some very distinctive advantages including: lightweight and compact construction, lower purchase and shipping costs and extreme mounting flexibility. In addition, the paint-free exterior of Grove aluminum reducers makes them a perfect solution in many applications, including washdown; food, chemical and pharmaceutical processing.
|
|
Type Code: AEALZB / AEAUZE / AEAUZF
Aluminum Frame Induction Brake Motors
Low Voltage, TEFC, AS, BS Design B
Output 0.12 ~ 18.5 KW
Pole (Speed) 2 ~ 6
Voltage 380V, 400V, 415V
Frequency (Hz) 50
Frame Size 63 ~ 132M
Protection Enclosure IP 55
Design Standards: BS, AS
Environment: non-hazardous
Stator Insulation: Class F Insulation, SF 1.0
|
|
|
|
|
|
FRAME SIZE:
63 ... 160 - aluminium frame
OUTPUT:
0.12 ... 22 Kw
POLES:
2, 4, 6, 8 (pole changing on request)
INSULATION CLASS:
F
MOUNTING:
IM B3, IM B5 and IM B14 standard and special
DEGREE OF PROTECTION:
IP54 (IP55 on request)
MOTOR FEATURES:
output power on S1 duty
motors conforming to IE1 code; 2 and 4 poles motors conforming to IE2 code efficiency values according to IEC 60034-30;2008; efficiency testing method IEC 60034-2-1;2007
external fan (IC411)
- VERY HIGH- TORQUE A.C. BRAKE - series AMF
very high braking torque (Mb > 2 MN)
continuous braking torque adjustment in the range 30% ... 100% Mb max
standard braking torque setted at 70% Mb max (on request 30% ... 100% Mb max )
double braking surface
high braking capacity, powerful and precise
standard brake supply: 230/400V-50 Hz with separate terminal block
axial hand release always supplied loose
TYPICAL APPLICATIONS: heavy duty, lifting, cranes/bridge cranes, ceramic machines and wherever a very high intervention frequency and a powerful and precise braking is required
- HIGH TORQUE A.C. BRAKE – series AMBZ
very high braking torque (Mb > 1.5 MN)
double braking surface
TYPICAL APPLICATIONS: automation with high intervention frequency, gear motors, lifting, handling machineries
SPECIAL EXECUTIONS:
efficiency values conforming to EPAct; flywheel, anti-sticking brake disk; degree of protection IP56
|
|
|
|
|
|
BM series are asynchronous, three phase, self-braking. BM series power range is from 0.06 kW up to 11 kW. The motor brakes in case of power supply failure. The brake supply is DC as standard with the rectifier built in the terminal box. On request is possible to have a separate brake supply. The rectifier is supplied with an over-voltage and radio frequency emission protection.
BM series is projected to withstand high overheating guaranteeing high reliability, also under severe operating conditions.
BM series is suitable to be controlled by inverters. The winding insulation class is F. Class H available on request.
Motor enclosure is TEFC, IP54 protection degree (IP55/IP56 available on request). An hexagonal hole is present on the shaft end to allow manual rotation (up to 132 frame size). All the BM series motors can be provided with the brake hand release.
Shields and flanges are aluminium made for motors up to 90 frame size, and cast iron for motor frame size from 100 up to 132. On request 132 frame size motors can be supplied with cast iron frame.
BM series main features are a robust construction, an extremely silent running and braking, the gradual braking action and motor starting, and a notable compactness in dimensions. All MGM motors are CSA approved.
|
|
|
|
|
|
FRAME SIZE:
63 ... 160 - aluminium frame
OUTPUT:
0.12 ... 22 kW
POLES:
2, 4, 6, 8 (pole changing on request)
INSULATION CLASS:
F
MOUNTING:
IM B3 ,IM B5 and IM B14 standard or special
DEGREE OF PROTECTION:
IP54 (IP55 on request)
MOTOR FEATURES:
output power on S1 duty
motors conforming to IE1 code as standard; 2 and 4 poles motors conforming to IE2 code efficiency values according to IEC 60034-30;2008; efficiency testing method IEC 60034-2-1;2007
external fan (IC411)
- HIGH TORQUE DC BRAKE - series AMBY
high braking torque (Mb > = 1.5 MN)
step adjustment braking torque (~33%; 67%; 100% Mb max)
double braking surface
progressive and noiseless braking
a.c. brake on request (series AMBZ)
Typical applications: gearmotors, lifting, packing machineries, transfer machineries, automation requiring a smooth intervention
- LOW TORQUE DC BRAKE AND REDUCED OVERALL DIMENSIONS - series AMS
non adjustable braking torque (Mb < = MN)
increased braking torque (+50% of the Mb catalogue value)
single braking surface
progressive (cast iron fan) and noiseless braking
Typical applications: woodworking/cutting machineries, automation requiring progressive braking, wherever a long braking periods and high braking duties are required
SPECIAL EXECUTIONS:
certification cURus; hand release lever; encoder; axial independent cooling fan; double shaft
|
|
|
|
|
|
BA series motors are asynchronous, three phase, self-braking. BA series power range is from 0.25 kW up to 45 kW. The motor brakes in case of power supply failure.
The brake supply is AC as standard. On request is available a DC brake (the rectifier is enclosed in the conduit box) and or a separate brake supply.
BA series is projected to withstand high overheating guaranteeing high reliability, also under severe operating conditions.
BA series is suitable to be controlled by inverters. The winding insulation class is F. Class H available on request.
Motor enclosure is TEFC, IP54 protection degree (IP55/IP56 available on request). An hexagonal hole is present on the shaft end to allow manual rotation (up to 132 frame size). All the BA series motors are provided with the brake hand release.
Shields and flanges are aluminium made for motors up to 90 frame size, and cast iron for motor frame size from 100 up to 132 mm. On request 132 frame size motors can be supplied with cast iron frame.
Frame, shields and flanges are cast iron made from 160 up to 225 frame size.
BA series main features are the robust construction, a very short braking time, an high and constant braking torque, frequent and heavy braking cycles, rare and easy maintenance. All MGM motors are CSA approve
|
|
Clutch & Brake Motors
This compact precision motor is equipped with an internal clutch and brake mechanism. This combination makes it ideal for applications involving frequent START/STOP operation, positioning, indexing, jogging and incremental feeding.
Suitable for high-frequency operation
Compact design
Highly reliable gearheads
|
|
|
SEW-Eurodrive's squirrel-cage motors and brakemotors deliver exceptional performance and reliability combined with low maintenance. Designed for continuous duty under tough service conditions, these low-noise brakemotors are used wherever fast, safe braking is a major application requirement.
|
|
Series: B... 63 to 355
Output range: 0.12 kW to 500 kW, higher output ratings available on request
Speeds: 3,000; 1,500; 1,000; 750 rpm, pole-changeable versions available on request
Brake types: Lenze BFK458, KEB .08.210, Mayr 800.410.3, Stromag BZFM
Features: Energy-efficient and environment-friendly, designed to DIN EN 60034 (IEC 72), mounting dimensions and assignment of output ratings to DIN 42673, 42677 or progressive, robust low-vibration grey-cast iron design, degree of protection IP 55, higher degrees up to IP 65 on request, class F insulation with thermal reserve, class H available as an option, terminal box optionally top-mounted, RHS or LHS up to frame size 315, various modifications possible
|
|
|
The asynchronous motors brakes of the series "BA" are equipped D ‘ a three-phase brake (System patented MGM). This type of brake ensures a fast and precise thanks to high stalling torques and adjustable braking and very reduced response time without artifice of cut. On request, it can be equipped with brake D.C. They pre-are equipped d’ a manual releasing and d’ a device of hand drive operation. Powers: 0,08 to 37 kw Sizes: 71 to 225 Mono-speeds: 2,4,6,8 poles bi- speeds: 2/4 – 2/6 – 2/8 – 2/12 - 4/6 – 4/8 – 4/12 poles etc… Engines with special characteristics lifting Many options available. Homologations: THIS – UL – SCUMS.
|
|
| ... products without technical information |
| |
|
Nexen servo motor brake modules mount between the servo motor and the gear reducer or on the free end of a ball screw spindle. Nexen offers a wide range of sizes and flanges to fit any brand of motor. These zero backlash brake modules are ideal as redundant safety brakes for z-axis applications or to stop high inertia systems from coasting after a power interruption. The spring applied brakes offer high holding torques and short emergency stopping distances.
|
|
For over 30 years, Matrix has designed and manufactured more than 700 variants of spring-applied, electromagnetic brakes for the leading servomotor manufacturers in Europe, North America, and Asia Pacific. Matrix is a global leader in providing the highest torque in the smallest size envelope making our brakes the preferred performance solution in servo motor braking. Matrix provides custom design and support to provide the most cost-effective solution to any customer application.
-Spring-applied, electrically released brakes with low backlash for precision holding applications
-Permanent magnet brakes with zero backlash for precision holding applications
Typical Servo Motor Applications
* Packaging
* Semiconductor equipment
* Welding and assembly robots
* Machine tools
* Medical equipment
* Printing machinery
|
|
| ... products without technical information |
| |
|
|
