Crowcon's 35+ years gas detection expertise has been instrumental in developing a range of control panels to suit all applications. All our fixed gas monitoring systems can be interfaced with any fire and gas detector and distributed control system (DCS). In addition each system can be engineered to drive remote annunciators and mimic panels.
Our fixed gas monitoring range consists of:
Vortex 1 to 12 channel control system
Gasmaster 1 to 4 channel control system
Gasflag Single channel control system
Gasmonitor Plus 1 to 16 channel control system
CellarSafe CO2 monitoring system
Ditech modular gas and fire detection and extinguishant control system
|
|
Features:
-Superior Low Energy Control for Micro Welding
-Ultra Fast Closed Loop Control
-Single Phase Power Supply
-Three Feedback Modes for DC Welders
-Graphical Display and Intuitive DC Welder Monitoring
The UB25 linear DC welder provides unsurpassed levels of control for micro-miniature resistance welding. This DC welder power supply should be used for smaller applications where closed-loop feedback control and fast response times are required. Safety critical applications such as those found in the medical and automotive markets will benefit from UB25’s precision low energy control.
|
|
Low Power Linear DC Welder with Built-in Monitor - UB25
Features:
- Superior Low Energy Control for Micro Welding
- Ultra Fast Closed Loop Control
- Single Phase Power Supply
- Three Feedback Modes for DC Welders
- Graphical Display and Intuitive DC Welder Monitorin
The UB25 linear DC welders (successor to the Unibond II) provide unsurpassed levels of control for micro-miniature resistance welding. These DC welder power supplies should be used for smaller applications where closed-loop feedback control and fast response times are required. Safety critical applications such as those found in the medical and automotive markets will benefit from UB25’s precision low energy control.
|
|
No matter what the application, Draeger's System Centers will design a monitoring system for your specific needs.
Whether it is a single wall mount unit for only one or a few points, a 19" rack mounted modular controller, or a full blown SCADA system with cabinetts to house the electronics and wiring, our experienced engineers will help to design the system that fits. Even PC monitoring consoles with event log displays and zoom-in plant layouts are available from Draeger Safety.
|
|
|
|
|
|
AB425S:
New universal control unit for almost all sewing machine drives with 1 or 2 stepping motors.
* Control unit for Efka DC1500 or DC1550 motor
* - and 2 stepping motors Efka SM200 and SM 250
* - or 3. party products up to 60V and 5A phase current
* User customized programming of individual and even complex functional sequences in a higher programming language for specially designed sewing workplaces and sewing automats using Efka C200 compiler
* Flexible pre defined seam programs
* Synchronous operation of all drives
* X/Y function
* Output signals for use on sewing automats
* USB port for data storage uploading and downloading
* Updates via USB with email possible
* Flash technology, no EPROM
* Digital parameter setting directly on the control unit
* Programmable light barrier functions
* Separate knee switch connection for KN19
* Integrated tread monitor function
* Wide range of HMI: Variocontrol V810, V820, V850 und Variotouch V900
* Easier mounting on sewing machine thanks to compact control box housing
* 29 short-circuit proof outputs
* 28 digital inputs freely programmable
* 2 analog inputs
* 2 digital / analog converter output (0-10V)
* Operating hours counter
* Machine operating time monitoring with optical or acoustic signal for maintenance
* Expandable to other Efka drives via CANefka
|
|
R50MP motor pump control unit is suitable to control and protect Diesel and motor pump engines.
It includes an engine protection unit ,which is named PDM1MP, which, besides running indications, stops the engine in case of alarm. It also protect the water pump by means an instrument which allows work pressure surveying and setting up the minimum and maximun value of pressure at which the engine needs to be stopped.
|
|
The production line offers follwing features:
- Inline assembly concept (3 assembly cells in a row)
- Concept is designed für 3 diferent product types
- Special system design for flexibility, high precision clean production run
- Free flowing workpiece carrier system
- Special palletizing system for parts feeding and providing final assembled parts
- Bowl feeder for micro parts
- Open control system Simatic S7 and bus system DP
- Cycle time 10 sec. (6 units per minute)
- Technical availability 86%
- Working operations: parts feeding, pick and place operations, orientating, high precision mounting, testing, parts palletizing
- Rohwedder services: Process planning, system development and design, complete supply and implementation of production line, production assistance (SOP)
|
|
|
|
|
|
BODAS controllers for quickly and affordably creating a mobile-hydraulic complete solution without time-consuming and expensive hardware development.
The RC controllers are the heart of the BODAS system with multifunctional inputs and outputs for the control of the electrohydraulics components in the machine. BODAS RC controllers are optimally meeting the requirements of mobile working machines with a diversified application spectrum.
In complex applications, multiple controllers can be connected via the CAN bus to form a network. The number of the inputs and outputs can be extended quickly and economically with the CAN I/O-extension module RCE. Safety features integrated in the standard version enable simple and reliable machine diagnostics.
Matched to the RC controllers, the BODAS software modules offer preconfigured application solutions for drive and working hydraulics. A comprehensive tool chain for parameterization, for diagnostics and for flashing the BODAS controllers is available with the BODAS-service.
For custom solutions, you can use the BODAS RC controllers as a freely programmable platform.
Features:
- Safety features:
-Detection of cable break
-Detection of short circuit
-Monitoring the outputs
-Bosch watchdog module
-Central switch for all power outputs
- Output stages with pulse-width-modulated current regulation (PWM)
- Robust case
- High EMC > 100 V/m
- Download the software from a PC to the flash memory
- CAN bus or RS232 interfaces
- Interfaces matched to Rexroth electrohydraulics
|
|
Electronic controllers are designed for electric motor drives
based on the battery supplied asynchronous motors, electronicaly commutated brushless motors with permanent magnets and DC commutator motors. They are designed for use in various
drive systems. They are built in the MOSFET technology. Their
method of operation is adapted to the operation with various
types of motors. Controllers are designed on the basis of
processors; therefore a wide setting of functions is possible.
They are built for the nominal voltages from 12 V to 80 V
and control of load currents up to 800 A.
|
|
|
The CVC electronic controller has been designed as control system for hydrostatic tracks vehicles with separate - left and right - hydraulic circuit. The CVC controls in closed loop the displacement of the two pumps, or the speed of the two wheels, to make sure that it corresponds to the given command in whatever use conditions.
|
|
|
|
|
|
BODAS controllers for quickly and affordably creating a mobile-hydraulic complete solution without time-consuming and expensive hardware development.
The RC controllers are the heart of the BODAS system with multifunctional inputs and outputs for the control of the electrohydraulics components in the machine. BODAS RC controllers are optimally meeting the requirements of mobile working machines with a diversified application spectrum.
In complex applications, multiple controllers can be connected via the CAN bus to form a network. The number of the inputs and outputs can be extended quickly and economically with the CAN I/O-extension module RCE. Safety features integrated in the standard version enable simple and reliable machine diagnostics.
Matched to the RC controllers, the BODAS software modules offer preconfigured application solutions for drive and working hydraulics. A comprehensive tool chain for parameterization, for diagnostics and for flashing the BODAS controllers is available with the BODAS-service.
For custom solutions, you can use the BODAS RC controllers as a freely programmable platform.
Features:
- Safety features:
-Detection of cable break
-Detection of short circuit
-Monitoring the outputs
-Bosch watchdog module
-Central switch for all power outputs
- Output stages with pulse-width-modulated current regulation (PWM)
- Robust case
- High EMC > 100 V/m
- Download the software from a PC to the flash memory
- CAN bus or RS232 interfaces
- Interfaces matched to Rexroth electrohydraulics
|
|
Control unit unipos C110:
- linear path controller
- CNC + PLC
- controls max. 9 axes, servo motors or stepper motors
- DC motors on request
Control unit Unipos 120 / 220:
- Point to point controller
- Control unit to control stepper motors
- CNC
Control unit unipos 420-W:
- continuous path controller
- CNC + PLC
- Controls max. 8 axes, 4 axes simultaneous
Control unit unipos 820-W-/WH:
- CNC-Controls + PLC
- max. 64 axes with 8 NC-channels (SERCOS/Analog)
|
|
The XLe compact (96x96x57) all-in-one controller comes with a 128x64 LC-Display and has full monochrome graphics capabilities. It is equipped with built-in I/O coupled with the dual protocol capabilities and optional internal telecommunication modules.
The OCS with its full IEC61131-3 integrated development environment for logic, HMI design, networking and I/O configuration is a very capable PLC with full graphics capability. The operator interface used in the XLe series is a high visibility graphics monchrome LC-Display with blue LED backlight offering excellent readability to the user in the most difficult conditions.
~ Cscape™: All Units are programmable with a Free Software ~
|
|
Microvision Plus (3 axis interpolated controller)
All the power of a numeric controller with ISO programming in a cheap structure based on a RISC 16 bit processor. Monochromatic 5” display can be touch screen which improves navigation making it more user friendly. Drivers can be connected to the controller either through analog +/-10 V. signals or digital PWM or Step / Direction. Besides a considerable number of I/O “on board” many other devices can be added or remoted using the 2 available CANopen serial ports.
|
|
From the monitoring-for-function of the sensors to self-monitoring Control Units, Mayser supplies the right Control Unit for every safety system. Acting as a link between the sensor and the machine control, it analyses the incoming signals and immediately triggers the required measures.
In cooperation with the Elge GmbH company, we can also supply Control Units for special safety systems and other applications.
|
|
Engine Controller – EC-1
Compact engine controller with optional J1939 engine communication. The integrated communication makes remote control possible and with an optional GSM modem, the EC-1 can forward SMS/text messages.
Features include:
- Engine control
- Engine monitoring
- Multi-language display
- Engine CAN bus communication
- 6 configurable binary inputs
The EC-1 is an attractive alternative for key starters if you require extra communication such as engine communication or remote communication
|
|
|
The main engine is considered the lifeline of the ship. The WE22 constantly monitors and optimally controls the main engine.
|
|
The Keystart range provides manual start/stop and automatic fault protection for generators, pumps and other engine-driven applications:-
* Simple, compact design
* 92 x 92 mm or 68 x 68mm DIN panel cut-out
* Security keyswitch
* Fuel, starter and timed preheat control outputs
* LED and icon indication of preheat, fuel on and fault conditions
* Overspeed shutdown option, with link-selectable input source (magnetic pickup or AC generator)
|
|
|
|
|
|
Engine monitoring system Watch-free system model : WE500
- Larger screen size
The LCD screen size is enlarged from 12.1" to 15". The image resolution is enhanced from 800 x 600 pixels (SVGA) to 1024 x 768 pixels (XGA). The number of display colours is also increased from 12 to 16,777,216. Furthermore, two larger size of LCD displays can be connected externally as an option.
- Mimic screens are made available
- Remote control for pumps and valves
Mimic screens provide remote control for pumps, valves and other kind of devices.
- Hardcopy function is added
Hardcopy is available by using a printer comes standard with the system
- Trend analysis display feature is enhanced
All analogue measurements can be viewed anytime as trend diagrams for continuously sampling of them.
- Download feature is provided
Connecting a purpose-built PC to the system allows monitoring points to be added, deleted or changed on site.
- The all-in-one configuration and the dual hot standby capability are inherited
High serviceability and reliability of the system are contributed. The compact design with 700 mm width (80 mm wider than WE300HG) can minimize the installation space.
|
|
|
|
|
|
Combustion Control and Monitoring Systems
Combustion and emission control, why?
In 1997 with the Kyoto's Conference and its regulations, the Governments decided to pay more attention to the CO2 flue gases reduction.
The European target for CO2 reduction is 8% compared to the year 1990 values.
Ascon is one of the leaders of this new conscience of environmental effects, managing, energy and financial saving.
Four guide lines have been defined: energetic renewable resources , diffusion of implementations to improve the final energy use, electrical energy production, and urban road traffic reduction.
One of the most important steps is to improve the plants efficiency by means of the continuous control of the flue gases oxygen content.
This type of control enables:
combustion efficiency optimisation by means of the control of the air/fuel ratio (energy saving);
check of correct plant working under different operating conditions, simple identification of possible anomalies and then relevant corrections (safety);
reduction of Nitrogen oxide pollution (to reduce environment impact).
Remember, a correct combustion means: economy, safety, cleaning.
Clean Combustion = Energy and money saving
At present each moderate investment on this matter enables a considerable energy saving with the consequent money surplus which means a quick pay-back of the investment and more.
|
|
Users of conventional universal display units can have difficulty in making use of their device´s options menu. Special applications require many more functions that are often not available with conventional units.
KRAL BEM 300 to 500 electronic units enhances the KRAL Volumeter performance.
Your advantages:
- Two-channel, i.e. differential measurement.
- Temperature and pressure pulse compensation.
- Measurement conversion.
- 7 point linearization.
- Limit value for a relay output, i.e. regulation of a bypass valve.
- Threshold value for signal suppression.
- Clear and easily readable display.
- Accurate handling by the use of a clear menu structure.
- Multiple mounting options. (KRAL Volumeter, wall, pipe, control panel).
|
|
At ITT Water & Wastewater we produce practical and easy to use monitoring and control systems for many different pump and mixer applications. Our systems offer reduced operational costs, total overview, less report handling and better environmental control.
As well as supplying the hardware, such as pump controllers, sensors, electrical start equipment and cables, we also have software for running the system. The ITT Water & Wastewater AquaView SCADA system provides precise and effective monitoring and control.
Each control system comes with a host of well-thought-out functions. Good examples are comprehensive pump control functionality, advanced supervision of pump condition, accurate flow calculation and cleaning functionality. All functionalities are based on international experience in municipal wastewater.
|
|
The Universal Power Cell uses Hall Effect sensors that are not affected by odd waveshapes or frequencies. Also, no Voltage or Current Transformers are used.
The UPC is field scalable to match your pump motor. Complete information at loadcontrols.com.
The PMP-25V Pump Load Control takes the 0-10 volt load signal from the UPC, displays the Pump Load, and has the Set Points, Timers and Relay and Analog Outputs.
|
|
|
|
|
|
|
VM20 is a modular, multipurpose measuring and test system for grinding machines easily programmable by the user. Available as independent unit or for rack-mounting, equipped with local hardware or remote operator panel as well as with Windows Software panel, digital I/O logic interfaces, Profibus and RS232. The wide range of grinding wheels balancing devices, with or without embedded acoustic sensors, applicable on single or multiple grinding wheels or long grinding wheels, allow to automatically and rapidly reduce vibrations which generally cause errors and imperfections on worked surfaces. The wide range of AE transducers configuration available, with assembly both on rotating and stationary machine components, can be used to monitor the machine conditions, through FFT analysis, and to determine the grinding wheel position when it contacts the piece to be worked or the tool-dresser. During working, diameter and roundness gauges, as well as the pieces positioning gauges, allow to achieve a constant production quality together with a cycle time improvement, thanks to correct feeding speeds for roughing-out and finishing.
|
|
The CoMo Injection process monitoring system Type 2869A allows zero-defect injection molding production by analyzing the cavity pressure curve.
A bright 12.1" color touch screen monitor Type 5629A3 makes operation of the CoMo Injection system even quicker and easier, and accelerates communication with the system. The new IP Setup Program now being supplied with the system allows simple automatic detection and configuration of CoMo Injection units installed in production.
Version 2.0 of CoMo-MIS Type 2829A…, the database system for storing measured and calculated process data, is now also available in the four languages mentioned above.
All of the CoMo Injection and CoMo-MIS systems that have already been installed can be updated with the latest version. The IP Setup Program works with all CoMo Injection units equipped with Version 1.2.
|
|
|
|
|
|
The CoMo Logic is a y(t) control monitor with three real-time thresholds and elementary post-cycle curve analysis function. The following operating modes are available: 'GRAPHIC’ for displaying the y(t) signal characteristics, ‘TREND’ for displaying the last 118 peaks of the cycle and ‘PEAK’ with numerical display of the cycle peak.
By their web server functionality, CoMo Net and CoMo View are directly connected to the TCP/IP world. Many functions and information can be operated and viewed via familiar browser functions from any point worldwide, of course protected by security precautions and access authorization. A central storage of quality data from larger, complex production lines is significantly simplified and a cost advantageby use of an existing network structure . Also remote maintenance and diagnosis enable fast, qualified and cost-effective on-site help during servicing.
The dependent measurands, for example press force and displacement are recorded and their functional dependence is evaluated. The evaluation result can reject bad parts for reworking or classify production into different tolerance classes.
The CoMo View is equipped with an integrated 5,7" Touch Color-Display of 320x240 pixels. Possible connection of piezo, strain gauge and voltage output sensors as well as potentiometric displacement and angle sensors make this two channel control monitor versatile for most any application. Real-time capability is given via digital I/Os and a fast export of process data and measured curves add significantly to a safe process monitoring even at high cycle rates.
|
|
Modern automation, control and remote control systems have become essential for optimized and secure control and monitoring of processes regarding energy distribution and industrial networks.
Depending on the specific field of application, different requirements have to be met by the devices regarding
- Various intputs and outputs
- Process signals
- Environmental conditions
- Communication and transmission technology
- as well as essential logical functions
|
|
For Maximum Combustion Efficiency Through Complete Mixing Of Fuel Gas And Air.
Selas Combustion Controllers equipped with PosiMix® Mixing Valves are precision premix systems for blending fuel gas and air. They are suitable for most fuels, mixing them with room air and compressing the mixture to deliver a precise, preset gas/air ratio at uniform pressure to the burners.
FEATURES & BENEFITS
Completely self-contained
Capacities available from 500 to over 150,000 cfh of mixture
Output pressure to 6 psi
Precise gas/air ratio maintained over a wide turndown
Available with automatic ratio control
Low installation cost - single pipe delivery system for one or more control zones
For use with any clean commercial fuel gas containing less than 40% hydrogen
Rugged - provides years of trouble-free operation
Low maintenance
|
|
|
Bray Controls is proud to offer the Brayline series 50 Valve status Monitor, the future of valve position signaling. Bray's extensive field experience, research and development has produced the finest multipurpose switch/control monitors for industrial plant automation.
|
|
Freelance 800F - The compact solution ABB's Freelance 800F control system combines easy engineering with an open, modern system architecture. Freelance 800F is proven in more than 14,000 applications - in all industries.
The compact control system allows the integration of all common fieldbuses, leaving the user to select any they wish - whether FOUNDATION Fieldbus, PROFIBUS, or HART.
The system was and will be continously improved and enhanced to meet our user's needs. Customers choosing Freelance 800F can rest assured that ABB will support them in the long term.
The new AC 700F controller has just been released. In addition, new Information Management functions are available via PGIM 800F, our new Information Mananagment option.
|
|
|
|
