Electromagnetic, electromechanical and electronic sensors for controlling the level of all kinds of fluid.
Output with ON/OFF, SPDT or continuous signals
|
|
These compact transmitters feature the rugged durability of stainless steel or brass construction. The XM-800 series provides analog output, and can be combined with Gems Digital Bargraph Display and Level Cube Receivers described in this catalog.
Completely electronic, Gems Liquid Level Transmitters provide reliable and durable remote tank gauging. A wide variety of material combinations provide compatibility for most small to mid-size tanks in both process and OEM applications; for deeper tanks (to 18 feet) look to Gems 36000 and 66000 Series.
Gems experienced engineering and sales staff can provide customized solutions for applications not satisfied by the standard transmitters shown in this catalog. Do not hesiatate to contact Gems if you require a configuration not shown here.
|
|
Level Monitoring
Level Measurement
|
|
|
The Barksdale Tank Level Indicating Systems are sensors for remote indication level of liquid media. They operate according to the float principle with magnetic trans-mission (Permanent magnet, Reed switch and resistor chain). The liquid level is indicated on indicating instruments connected to the sensor.
|
|
Continuous level sensors designed with potentiometric output signal, 3 adjustable alarms or 4/20mA converter. Brass stem and NBR float or stainless steel AISI 316 executions. Contact distance 10 or 15 mm. G1 1/4" - G2" thread connection of Ø52 - Ø92 flange in aluminium or stanless steel.
Executions approved for hazardous areas (EX zones) are also available.
|
|
Level sensor MG
Characteristics
Level sensor output 4 - 20mA or Vertical installation
Resistance output in three-wirepotentiometer circuit
Simple operating principle: Reed switch resistance measuring chain
Temperature range: -30°C to 150°C IP66 protection
12 mm accuracy grid Electrical connection: Connecting box coupler plug or cable
Areas of application:
The level sensors are ideal for industrial use because of their extreme reliability and robust mechanical construction.
They operate safely and reliably even under harsh service conditions and can be used in the following industries, among others:
Plant construction, Food industry, Biochemicals, Engineering
Chemicals, Offshore, Energy systems, Petrochemicals, Natural gas, Shipbuilding, Power stations, Pharmaceuticals etc.
|
|
KONTINUIELICHE LEVEL MEASUREMENT
- capacitive level probes for liquids and bulks in
High-grade steel or plastic one, exit 4-20mA, for vertical installation, for
aggressive media, remarks with removable head and
exchangeable or shortenable probe staff
- Niveausonden with float principle, for liquids, exit 4-20mA
or resistance signal, Kundensprezifi remarks, in high-grade steel
or plastic ones
Level border conditions: Capacitive contactors,
optical contactors,
Float switch
|
|
|
|
|
|
|
WEKA tank level indicators are suitable not only for general liquid level measuring applications, but are also a cost-effective means of detecting interface levels between dissimilar liquids. These sensors are unaffected by temperature and pressure, and provide a stable and linear signal output, even with the existence of liquid agitation or the presence of a foam layer. Their ruggedness meets the requirements of the toughest operating conditions, including military applications. They are available in different configurations to so that an optimum solution can be offered for any level measuring range. With only one moving part, these sensors are simple, reliable, virtually maintenance-free, and easy to service, if such a need arises. WEKA has unique capabilities in precision fabrication of stainless steel and other specialized corrosion-resistant metals. This, together with our large selection of float designs, allows us to offer level measuring solutions precisely tailored to your needs.
|
|
| ... products without technical information |
| |
Mainly based on the float switch design, these controllers help to monitor the liquid level (as combined units they monitor both liquid level and temperature) in oil reservoirs of fluid power and lubrication systems.
Attached to the tank top cover, they penetrate directly into the hydraulic fluid or the lubricant.
Each of the following series offers particular features and details culminating in the extreme density of functions offered by the Multiterminal.
Level switch Fluidcontrolterminal series
High number of functions reduces requirements for installation, space and cost
Adjustable level contacts
Connecting flange according to DIN 24 557 part 2
Directly attached electronic contact thermometers optional
The FC terminals offer the functions of tank breathing, level/temperature control, filling and topping up and oil sampling in a very compact design.
|
|
Level measurement instrument in stainless steel 1.4571
with integrated temperature sensor
TN 210
Characteristics:
Analog level signal 4-20 mA, two-wire transmitter
Max. 4 level switches (bistable) pnp-output. Control elements: reed contacts or magnet sensors
Analog temperature signal 4-20 mA, two-wire transmitter
Temperature switches: pnp-output or thermostat for switch action
Advantages:
Reductions of costs: max. 4 different measurements in one measuring instrument
Economy of time, of storage costs, of assembly costs etc.
Areas of application:
IMB combined measuring instruments are suitable even for rough environments and are applicable in the following industries:
plant engineering, off-shore, machine construction, power plants, chemical industrie, ship-building, biochemical industrie, food industrie, petrochemical industrie, pharmaceutics etc.
|
|
