Honeywell Hour Meters / Monitors
Universal Application. Singular Performance. You'll find Honeywell hour meters where quality, performance and rugged construction are needed. Track and record elapsed time more effectively and efficiently (hours or tenths of hours). Log equipment running time to assure proper maintenance of expensive machines or systems or track warranty programs. Often eliminate the guesswork with elapsed hours for better machine resale value, or logging actual time on your rental products.
Honeywell's Hobbs hour meters offer:
-Multiple power, display, shape and data options
-Analog or LCD displays
-ac, quartz dc or Diochron product families
-Shock and vibration resistance
-Noiseless performance
|
|
Electromechanical and electronic Preset hour meters for:
- Machines
- Medical equipment, e.g. respirators
- Vehicles of various types
- Generators
- Small machines & instruments
- Control panels
Electronic Time relays for:
- Industrial applications
- Automation and machines
- Vehicles, mobile plant
|
|
LH2H - hour meter (digital)
- Operation Voltage: built-in battery; 4.5V DC - 30V DC, 24V AC - 240V AC
- Output: no output
- Display: 7 digits; day / hour; hour; hour / min. / sec.
- Battery life: 10 years
- Reset: yes / no
- Size: 48 x 24 x 54.4mm
Key Points:
- Industry first, bright, 2-colour back light
- Easy-to-read display
- Battery replacement easy
|
|
700 Series
Highly reliable solid-state hour meters and counters that offer an unprecedented combination of patented technology, performance, reliability and value. Ideal for a wide variety of industrial and commercial applications, including scheduled maintenance, warranty and leasing - for medical equipment, transport and industrial vehicles and other industrial equipment.
- Model 700: 2-wire hour meter, displays only when powered. AC/DC.
- Model 701: 3-wire hour meter; has provision for continuous display. AC/DC and DC.
- Model 703: Pulse counter. AC/DC and DC.
- 6-digit LCD, 5 mm or 7 mm digits (7 mm with optional backlighting).
- Non-volatile EEPROM memory.
- Wide voltage ranges minimize worldwide stocking requirements.
- Wide range of case styles to fit in all types of standard hour meter/counter cutouts.
|
|
4H37-2
Hour Meter
7 digit hour meters for AC or DC operation in a standard DIN housing with panel clip mounting.
The 4H37 hour meters display to a resolution of hundredths of an hour (36 second intervals). The AC model shows a rotating red striped wheel to indicate that it is operating.
• 7 digit 4mm white on black for hours, red on black for decimal.
• Standard 24 x 48 DIN case.
• Panel clip mounting.
• Available with sealed window to IP65 to special order.
• DC or AC (50 or 60Hz).
• Synchronous motor drive for AC model.
• Stepping motor drive under crystal control for DC model.
• Isolation protection to VDEO435.
The AC unit normally operates on 230VAC 50Hz but other voltages, and 60Hz, are available to special order. It is supplied in a black case with grey available to special order.
Electrical connection is via screw terminals but a version having flat 0.8 x 6.3mm pins is also available to special order.
|
|
