XYZ nanopositioning stage / piezo / compact / frictionless guided
XYZ nanopositioning stage
P-611.3 NanoCube® series

Stroke : 120 µm

- Travel range to 120 µm × 120 µm × 120 µm - Ultra-compact: 44 mm × 44 mm × 44 mm - Resolution to 0.2 nm - Rapid response - Frictionless, high-precision flexure guiding system - Outstanding lifetime due to PICMA® piezo actuators - ...

See the other products
Physik Instrumente
XYZ nanopositioning stage / piezo / high-speed / frictionless guided
XYZ nanopositioning stage
P-733.2, P-733.3 series

Stroke : 100, 10 µm

- Travel ranges to 100 µm × 100 µm in X,Y and to 10 µm in Z - Resolution to 0.1 nm with capacitive sensors - High-speed versions with direct drive - Vacuum-compatible and non-magnetic versions - Parallel kinematics for enhanced dynamics ...

See the other products
Physik Instrumente
XYZ nanopositioning stage / piezo / 3-axis / frictionless guided
XYZ nanopositioning stage
P-561, P-562, P-563 series

Stroke : 300 µm

- Parallel kinematics / metrology for enhanced responsiveness and multi-axis precision - Travel ranges to 300 x 300 x 300 µm - Highest linearity and stability with capacitive sensors - Frictionless, high-precision flexure guiding ...

See the other products
Physik Instrumente
XYZ nanopositioning stage / tilt / piezo / 6-axis
XYZ nanopositioning stage
P-562.6CD

Stroke : 200 µm

- 6 motion axes: 3 × linear, 3 × rotational - Travel ranges to 200 µm linear and to 1 mrad tilt angle - Enhanced responsiveness & multi-axis precision: Parallel kinematics / metrology - Highest linearity and stability with capacitive ...

See the other products
Physik Instrumente
Z-axis nanopositioning stage / piezoelectric / for microscope objectives
Z-axis nanopositioning stage
P-725.xDD PIFOC® series

Stroke : 18 µm

- Fastest settling time under 5 ms with microscope objective - Travel range 18 µm - Scans and positions objectives with sub-nm resolution - Parallel flexure guiding for minimized objective offset - Direct metrology with capacitive ...

See the other products
Physik Instrumente
linear nanopositioning stage / 1-axis / crossed roller
linear nanopositioning stage
ANT95-L series

Stroke : 25 mm - 100 mm
Speed: 0 m/s - 0.5 m/s

Aside from being the world's first nanometer-level positioning system, this ANT95-L Mechanical-Bearing Direct-Drive Linear Stage proves its speed, accuracy, resolution, repeatability, reliability and size over the years ...

See the other products
Aerotech
linear nanopositioning stage / 1-axis / crossed roller
linear nanopositioning stage
ANT130-L series

Stroke : 35 mm - 160 mm
Speed: 0 m/s - 0.35 m/s

The Aerotech ANT130-L series is a high performance drive designed for alignment, inspection, positioning, and measurement stations. The ANT130-L delivers unparalleled nanometer level precision in travels up to 160 mm. The ANT130-L ...

See the other products
Aerotech
rotary nanopositioning stage / motorized / 1-axis
rotary nanopositioning stage
ANT95-R series

The ANT95-R and ANT95-R-PLUS direct-drive rotary stages are efficient and reliable devices that offer impressive in-position stability of 0.005arc-sec, and sub 0.01arc-sec incremental motion performance. These are offered ...

See the other products
Aerotech
rotary nanopositioning stage / motorized / 1-axis
rotary nanopositioning stage
ANT130-R series

Compact and lightweight, the Aerotech's ANT130-R and ANT130-R-PLUS were engineered to deliver optimum performance and reliability with minimal space consumption and portable design. This product features 0.01 arc/ sec resolution and 0.005 ...

See the other products
Aerotech
linear nanopositioning stage / XY / 2-axis / crossed roller
linear nanopositioning stage
ANT95-XY series

Stroke : 25 mm - 50 mm
Speed: 0 m/s - 0.5 m/s

Aerotechs ANT range of stages are the world's first nanometer level positioning instruments that boast a higher than 22 mm travel. The The ANT95-XY crossed-rolled-bearing with linear motor and two-axis stage ...

See the other products
Aerotech
linear nanopositioning stage / motorized / 2-axis / high-speed
linear nanopositioning stage

piezo nanopositioning stage / vertical / 1-axis / fine focus
piezo nanopositioning stage
NZ200

... than an objective collar, the NanoScan Z can complete all its movements within 10 ms. Compatible with Prior’s H117 and HLD117 stages for a wide range of inverted microscopes, the NanoScan Z has a wide range of inserts ...

piezo nanopositioning stage / vertical / 1-axis / fine focus
piezo nanopositioning stage
NZ400

... much faster than an objective collar and can complete all its movements within 20 ms. Compatible with Prior’s H117 and HLD117 stages for a wide range of inverted microscopes, the NanoScan Z has a wide range of inserts ...

piezo nanopositioning stage / vertical / 1-axis / fine focus
piezo nanopositioning stage
NZ200F

... faster than an objective collar, the NanoScan Z can complete all its movements within 20 ms. Compatible with Prior’s H101F stages for a wide range of upright microscopes, the NanoScan Z has a wide range of inserts available, ...

piezo nanopositioning stage / vertical / 1-axis / fine focus
piezo nanopositioning stage
NanoScanZ 100

Stroke : 100 µm - 400 µm

... than an objective collar, the NanoScan Z can complete all its movements within 10 ms. Compatible with Prior’s H117 and HLD117 stages for a wide range of inverted microscopes, the NanoScan Z has a wide range of inserts ...

XY nanopositioning stage / piezoelectric / 2-axis
XY nanopositioning stage
PXY Series

The PXY Series by Piezosystem Jena is an XY nanopositioning stage which is used to compromised piezo electric actuators into a flexure hinges systems. With these assembly, it enables the unit to work ...

XY nanopositioning stage / motorized / 2-axis
XY nanopositioning stage
ScanXY 40

The Scan XY40 piezoelectric actuating podium can cover a range of 40 microns for each axis. The nano-dimensional piexo podium is engineered to meet the demands of 2D monitoring devices. The high performance monitoring podiums can present ...

linear nanopositioning stage / motorized / single-axis / high-speed
linear nanopositioning stage
NanoX 240 SG

The one-axis linear positioning stage nanoX 240 SG is a development within the ultra fast nanoX®line offered by piezosystem jena. Highest positioning accuracy, stability, linearity and reproducibility are achieved in ...

linear nanopositioning stage / motorized
linear nanopositioning stage
VZMM series

Stroke : 5 mm - 80 mm

REFERENCE VZMM4,5D005 DESCRIPTION Mini slider with high precision balls guiding, adjustable stroke by stopper or hydraulic shock absorber, magnetic detection

XY nanopositioning stage / motorized / 2-axis / high-speed
XY nanopositioning stage
PPS2020

Stroke : 0 mm - 200 mm
Speed: 0 m/s - 0.5 m/s

... accuracy = 200 nm Acceleration = 10 m/s² Payload = 5 kg Nano to Macro describes the positioning range for the nano positioning system PPS2020. Resolutions down to 2.44 nm with exclusive dynamic motion parameters up ...

rotary nanopositioning stage / motorized / compact / crossed roller
rotary nanopositioning stage
FBR series

Nanomotion FBR Series Rotary stages provide the most compact footprint for precision rotary motion. A 60mm diameter ceramic ring surrounds a precision crossed roller rotary bearing with a non-contact optical encoder. ...

goniometer nanopositioning stage / tilt / motorized
goniometer nanopositioning stage
FBG series

Nanomotion FBG series goniometer stages provide tilting motion about a pivot axis above the stage. The stage design provides the ability to couple two axes together to tip and tilt around ...

linear nanopositioning stage / piezoelectric / backlash-free / integrated recirculating ball bearing guide
linear nanopositioning stage
NHL 84 serries

Stroke : 70, 170, 45, 120, 270 mm
Speed: 0.01 m/s

... the linear stages of the new OWIS positioning generation perfect for use in applications requiring the highest precision for very high loads and long travels, which a common nanopositioning system could ...

See the other products
OWIS
linear nanopositioning stage / piezoelectric / 1-axis / integrated recirculating ball bearing guide
linear nanopositioning stage
NHL 124 series

Stroke : 230, 80, 290, 130 mm
Speed: 0.01 m/s

The NHL nano-hybrid linear stages is a kind of spindle drive that can hold extreme quantities and high level of torque. It has a diameter of 290 mm that allows accurate positioning in nanometer range, and it also has ...

See the other products
OWIS
linear nanopositioning stage / piezoelectric / compact
linear nanopositioning stage
NPX Series

The NPX Series consists of space saving and long travel linear stages which are piezo-based that offers nanometer resolution motion from 1 up to 3 axis. It is perfect for nanopositioning of small components ...

linear nanopositioning stage / motorized
linear nanopositioning stage
NT...V

Stroke : 10 mm - 120 mm

The IKO Nano Linear NT...V compact linear motor table possesses and impressive functional beauty through the arrangement of magnets and scale for the optical linear encoder to the movable steel table, and the stator coil and head for ...

See the other products
IKO Nippon Thompson Europe
linear nanopositioning stage / motorized
linear nanopositioning stage
NT...H

Stroke : 25 mm - 65 mm

The Nano Linear NT...H is a magnet positioning table that has a direct drive. It has magnets and also an optical linear scale that are incorporated into the moving table that is made out of steel. Then there are the stator ...

See the other products
IKO Nippon Thompson Europe
rotary nanopositioning stage / 1-axis / open-center / ball screw
rotary nanopositioning stage
KDT180-DC

Stroke : 60 mm

The item has Anodized surface with without backlash preloaded direction, made of stainless steel, without backlash ball screw (distance across 5mm/ pitch 1mm), 24v DC stepper engine, Rotary encoder (512 beats for every revolution), Gearbox ...

See the other products
Steinmeyer Mechatronik GmbH
linear nanopositioning stage / 1-axis / open-center / ball screw
linear nanopositioning stage
KDT310-DC series

Stroke : 100 mm
Speed: 0.03 m/s

The KDT310-DC is an XY stage manufactured by Steinmeyer. It is driven by a motor with a voltage rate of 24V DC. The unit features an anodized surface, and stainless steel bearings. It can prevent backlash through the ...

See the other products
Steinmeyer Mechatronik GmbH
linear nanopositioning stage / piezoelectric / 1-axis / compact
linear nanopositioning stage
PSX100.AL.CS

Stroke : 0 µm - 100000 µm

The PSX100 stages are designed to seemlessly integrate into metrology applications, nano-motion machines, optical alignment, laser measurement, x-ray metrology, nano-automation, and research applications. The unique internal ...

See the other products
InsituTec
linear nanopositioning stage / piezoelectric / 1-axis / compact
linear nanopositioning stage
PSX20.TI.CS

Stroke : 0 µm - 25 µm

The X20 is a precision metrology stage designed for high bandwidth automation applications that require 1 nanometer in <1 ms settling times. Examples of applications include pico-scale metrology, nano-magnetic research, ...

See the other products
InsituTec
linear nanopositioning stage / motorized / 1-axis / open-center
linear nanopositioning stage

Stroke : 50 mm - 450 mm

... Nano Precision™. With nanometer straightness and flatness you can be assured that your point precision is True Nano™. This stage family comes with enclosed or open center versions from 50mm travel to 450mm travel. Standard ...

linear nanopositioning stage / 1-axis / sliding
linear nanopositioning stage

Stroke : 18 mm - 400 mm

... servo motor stages since 2001. The ceramic motors have been used in demanding high precision systems especially in vacuum environments. ALIOs piezo motor stage family has travel from 18 mm to 400 mm and ...

linear nanopositioning stage / motorized / 1-axis
linear nanopositioning stage
OP series

Stroke : 65, 100, 30 µm

... nanopositioners are very robust, compact and can be used for different applications, offering combination of individual single axis stages into multi-axis systems. They feature a range of motion from 30, 65 to 100 micron. ...

See the other products
Mad City Labs Inc.
linear nanopositioning stage / motorized / 1-axis
linear nanopositioning stage
OPH series

Stroke : 100, 30, 50 µm

... range of applications. The additional 1.3 inch diameter aperture via the stage makes the Nano-OPH helpful for accurate motion in optical experiments. Individual single axis stages may be integrated ...

See the other products
Mad City Labs Inc.
linear nanopositioning stage / piezoelectric / 1-axis / with sub-nanometer resolution
linear nanopositioning stage

Stroke : 80 µm - 2000 µm

... flexure-guided piezoelectric actuators and stages are linear actuators for precision motion control and positioning applications. Our piezo actuators can be custom designed for specific micropositioning, nanopositioning, ...

See the other products
DSM
Z-axis nanopositioning stage / vertical / piezoelectric / 1-axis
Z-axis nanopositioning stage
Model ZSA-1000C

Stroke : 1 mm

DSM’s nanopositioning piezoelectric ZSA-1000C stage features flexure-guided motion over a 1mm vertical travel range for scanning, metrology, and inspection processes. The stable and stiff kinematic design ...

See the other products
DSM
linear nanopositioning stage / piezoelectric / 1-axis / 3-axis
linear nanopositioning stage
HS1 series

Stroke : 30 µm - 70 µm

The HS1 is a compact nanopositioner which can be combined to form 2 or even 3-axis nanopositioning systems. It is offered with 30, 50 or 70µm of range of motion and it can also be proposed with an aperture (see HS1-Aperture). This ...

See the other products
PIEZOCONCEPT
linear nanopositioning stage / 3-axis / compact / high-speed
linear nanopositioning stage
HS1 APERTURE series

Stroke : 30 µm - 70 µm

The HS1 Aperture is a compact nanopositioner which can be combined to form 2 or even 3-axis nanopositioning systems. It is offered with 30, 50 or 70µm of range of motion and has a central aperture of 33 mm, making it ...

See the other products
PIEZOCONCEPT
linear nanopositioning stage / XYZ / piezoelectric / 3-axis
linear nanopositioning stage

When using the piezo stage, the laser beam stay put into a position; the sample is moved across the beam. The XYZ PZT is an actuated linear nanopositioning stage of exceptional resolution ...

XYZ nanopositioning stage / XY / piezoelectric / single-axis
XYZ nanopositioning stage

Stroke : 6, 30, 12 mm

... piezo driving technology, we are offering linear stages, rotation stages and actuators for 1-axis and multi-axis positioning. A customized system can be achieved by combining serval piezo driven stages ...
