207-000 6-18mm f/2.8 3:1 Miniature Zoom Lens
Smallest optical zoom lens with focus tracking available in the market place. High resolution images suitable for broadcast and machine vision applications.
|
|
|
Typical requirement for lenses and optical systems in civilian and military security and surveillance applications are for compactness, high performance and versatility. The Resolve Optics team has worked with a growing number of security focused organisations to provide novel, high performance solutions including miniature surveillance lenses, CCTV lenses and optics for ultra-high speed imaging systems, night vision systems and thermal imagers.
|
|
Honeywell offers world-class lenses for both indoor and outdoor performance.
- Day / Night Vari-Focal Lenses - Aspherical Design, DC Auto Iris, IR Corrected Lens
- System Series Vari-Focal Lenses - Aspherical Design, DC Auto Iris / Manual Iris
|
|
|
|
|
|
Product Highlights
Specifications
Format Size 1/2"
Focal Length 3.5-10mm
Iris Range F1.6-360
Mount CS
Horizontal Angle 1/3" 78.8°-28.1°, 1/2" 108.3°-73.2°
Features
Kowa is the first lens manufacturer introducing a new generation of HD-Multi-Megapixel Day & Night CCTV lenses for IP-Day & Night cameras with more than 3 Megapixel resolutions.
The outstanding performance of the new HD-Multi-Megapixel Day & Night series is achieved due to a special mechanical design and the usage of aspherical lens technology. By using XD-glass (eXtra low Dispersion) and special coating technology these lenses provide crisp colour images in day time and crisp black & white images in night time (IR light) without refocusing. This advanced optical design easily corrects colour aberration and contributes to the birth of this excellent HD-Multi-Megapixel Day & Night series.
The HD-Multi-Megapixel Day& Night varifocal lens series is designed for 1/2" sensors with 2 different models. LMVZ3510-IR covers a focal range between 3,5 – 10mm with an maximum angle of view of 108° whereas LMVZ9020-IR covers a focal range between 9 – 20mm.
Kowa’s advanced HD-Multi-Megapixel Day & Night series will pave the way for High End IP-Megapixel applications in outdoor environment.
LMVZ3510-IR and LMVZ9020-IR are guarantee for HD-Multi-Megapixel resolution during day time and night time with a minimum focus shift.
|
|
Product Highlights
Kowa offers a huge variety of IR-corrected lenses.
Latest development includes IR-corrected lenses for 5MP cameras.
Features
* 1/3" 3-8mm
* F1.0
* Aspherical lenses
* XD-Glass
* most compact in class (43.5x33x42)
|
|
|
|
|
|
Resolve Optics Ltd. has established an international reputation for custom design and manufacture of optimised single and multiple element lenses, zoom lens and beamsplitters that operate in the Infrared (IR) region (1-14 microns).
To realise the potential of technological advances in many industries the need for very high performance, high-resolution or large format Infrared lenses and lens systems that meet the exact needs of customers has risen dramatically. As the requirements for no-compromise IR lenses and lens systems has increased so have the proportion of applications that cannot be adequately solved by 'off-the-shelf' solutions.
Over the last 20 years Resolve Optics Ltd has successfully developed many innovative, high performance custom lenses for customers seeking to source no-compromise IR components for their thermal camera, sensor or instrument system. Drawing upon an experienced team of optical designers - Resolve Optics Ltd. is able to quickly gain an understanding of the basic physics of the technology associated with each customer's product enabling a novel, optimised and affordable solution to be proposed.
|
|
Product Highlights
Features
This large format lens has an IR corrected design with broad band coating. It is available in either F-mount or P-mount (M42X1).
Examples of applications include:
NIR Area Scan Inspections (Machine Vision)
2CCD Camera Applications (Visible + NIR)
Quadra-Linear (4 Lines-R, G, B, + NIR)
Color Line Scan Applications (Machine Vision)
Day/Night License Plate Recognition (ITS)
Specifications
Format Size 43.3mm
Focal Length 50mm
Iris Range F1.9-F16
Mount F-mount or P-mount
IR Corrected Design 400-1000nm
|
|
New Macro Lens VI with Macro Switch:
0x to 50x Magnification with macro switch and integrated illumination.
By changing the macro switch, the lens can be used as a macro lens under the range of 0x to 5x and as a zoom lens under 5x to 50x.
- Working Distance (WD) : 0mm to 59mm
- Field of View (H) : 0 to 59mm and 59mm to 6.1mm.
|
|
Product Highlights
These zoom lenses are extremely useful in production processes, such as character recognition, pattern matching, measurement, and inspection.
Features
Focal length 18-108
Image Size 2/3"
F-Stop 2.5
Distortion W:-0.7%/ T:0.1%
|
|
Product Highlights
Features
This series of megapixel lenses offers super high resolution and utilizes the floating mechanism system. The new wide angle 5mm megapixel lens will pave the way for new possibilities in machine vision systems.
Specifications
Format Size 2/3"
Focal Length 5mm
Iris Range F2.8
Mount C
Distortion 0.5%
|
|
|
Extremely Compact design, high resolution, radiation resistant non-browning zoom lens. All Resolve Optics radiation resistant non-browning lenses are made from 100% radiation hard materials. Special glass is used to avoid browning or discoloration when exposed to radiation.
|
|
UV-Zoom lens developed for spent nuclear fuel inspection.
Resolve Optics Ltd was selected by Channel Systems Inc. (Pinawa, Canada) to design and develop a novel high performance ultraviolet transmitting Zoom lens with a focal length of 80 - 200 mm for use in their Digital Cerenkov Viewing Device (DCVD).
|
|
|
Designed to double the field of view throughout the zoom range of any zoom camera. This Adapter is attached to the prime lens via the M37 filter thread.
|
|
Product Highlights
Features
* Wide Angle
* High Resolution
* Extra low distortion of only 0.4%
* Excellent corner brigntess
Specifications
Format Size 1/2"
Focal Length 3.5mm
Iris Range F2.4-F16
Mount C
Field of View 82.4° - 66.9°
|
|
Zoom Lens (50x to 400x) MXG-5040RZ with Automatic Calibration Select system (ACS) for 3D Digital Video Microscope Hirox:
50x to 400x Zoom Lens.
Non Contact Snap on Straight-View Adapter is included (AD-5040HS).
- Working Distance: 54mm
- Field of View : from 6,1 to 0,78 mm.
- Depht of field : from 13,3 to 0,25 mm.
|
|
Co Axial MXG-10C Zoom Lens (35x to 7000x) with Automatic Calibration Select system (ACS) for 3D Digital Video Microscope Hirox:
ACS Metal Micro Scope Type.
35x to 7000x Magnification (according to objective)
- Working Distance: 34mm to 3,4 mm (depends on objective)
- Objective Lens not included
|
|
20x to 160x Zoom Lens for 3D Digital Video Microscope Hirox Auto Calibration Select system (ACS):
Optical zoon with Diaphragm and focus ring.
Contact, Non Contact and variable lighting Adapters are included.
- Working Distance: 44 mm.
- Field of view: from 14,5 to 2,00 mm.
- Depth of field: from 13,3 to 0,25 mm.
|
|
|
ROLYN has a complete line of lenses suitable for photographic work. We handle several manufacturer's lines, with many lenses available from stock and many others available on special order.
|
|
ML-Z01515DM
High resolution, telecentric, super low magnification motorised 10:1 zoom lens.
Magnification range of 0.15X to 1.5X at a WD of 219mm.
ML-Z0220D
High resolution, telecentric, low magnification 10:1 zoom lens.
Magnification range of 0.2X to 2.0X at a WD of 173mm.
Available with integrated coaxial episcopic illumination.highly automated manufacturing equipment. Applications include visual inspection, alignment and character recognition
|
|
Board Lenses for CCD and CMOS Cameras:
Samples are immediately available. Lenses have M12 X 0.5P thread mount and can be easily repackaged to meet customer needs. Westech can always design a lens to meet exact requirements including glass - plastic hybrids. We have in-depth experience with high volume-high performance optics and can provide stock and custom lenses - quickly and inexpensively.
|
|
High Performance CCD Lens Assemblies :
These CCD/CCTV lens designs offer higher MTF response needed for today"s megapixel cameras. Each lens has an adjustable iris and focus.
|
|
High Performance CCD Lens Assemblies :
These CCD/CCTV lens designs offer higher MTF response needed for today"s megapixel cameras. Each lens has an adjustable iris and focus.
|
|
|
Navitar is the largest manufacturer in the world for aftermarket projection lenses. We make a lens to fit almost every projector on the market and we’re busy developing new ones every day. Our large selection of lenses includes a variety of zoom, long-throw and wide-angle replacement lenses. No matter what your application, screen size, or projection distance we have a replacement lens that will give you the image size you need.
|
|
|
|
|
|
|
Navitar ScreenStar wide-angle and long throw conversion lenses are the latest advance in DLP and LCD video projector accessory lenses. With lens options that let you increase your picture size or increase your throw distance by 20-50%, anything is possible. Our wide-angle conversion lenses provide a 25-50% larger image from the same projection distance or allow you to maintain the same size image while moving your projector closer to the screen. Our telephoto conversion lenses allow users to place the projector 20-50% farther away from the screen and maintain the same image width or reduce your picture size while projecting from the same distance. Navitar's Mini ScreenStar lenses are designed to be used with small profile, low cost projectors with panel sizes 0.8" or smaller. The new HD ScreenStar wide angle conversion lenses are specially designed to match the performance of HD projectors, provide a 25-50% larger image or allow you to maintain the same size image while moving your projector closer to the screen.
|
|
|
We offer micro lenses accourding to your specification (field of view up 150 degrees). They can be used, e.g. with a CCD-Chip, for medical applications.
|
|
|
Corning tropel has developed a family of semi-custom DUV micro objectibves with high numerical apertures and long working distances suitable for many different OEM applications includingIIL
|
|
