Benchmark microscope for field inspection of fibre optic connectors for contamination or damage. Available in 200x, 400x and 200-400x zoom versions with adapters for all popular connector types the PriorSpec II offers a high degree of flexibility along with the highest image quality of its class.
|
|
The VDM-E/Z™ is available with two interchangeable optics options:
- Patented Extended Depth of Field (EDF) Objective with on-axis lighting
- Zoom Objective with fiber optic ringlight and add-on lenses
The system is complete with fiber optic lighting and is available with a number of options to enhance its versatility. When inspecting small parts from any angle, VDM is the effortless clear choice.
|
|
The StarLite GX is the newest design in a complete non-contact inspection system with interactive measurement capabilities at your fingertips. It is everything you need for accurate video measurement.
Interactive Measurement at your fingertips
StarLite GX - fast, accurate and repeatable results you expect from a measurement system.
StarLite GX is designed for ease of use, with ergonomic controls, and innovative full-featured software. Increase your productivity with optional front panel controls - motorized zoom, XYZ zero set, enter point button, skew alignment, and an inch/millimeter switch.
eGx metrology software guides users through measurement routines with graphical icons, and unique tools for fast results on a manual measurement system.
|
|
|
The Hi-Eye versatile video microscope is a self-contained unit with motorized zoom lens, autofocus, high-resolution CCD camera, integrated color LCD monitor for excellent image quality across the magnification range. Its flexible articulating arm is easily mounted to any work table.
|
|
BINOCULAR OBSERVATION HEAD
- Binocular siedentopf head rotatable at 360° inclined at 30°.
- Diopter adjustment ring on ocular tube. Interpupillary distance from 55mm to 75mm.
EYEPIECE
- EWF 10X FOV 18mm
OBJECTIVES
- E-Plan Achromatic 4X
- E-Plan Achromatic 10X
- E-Plan Achromatic 40X(S L)
- E-Plan Achromatic 100X Oil(S L)
MECHANICAL BODY
- Co-axial focusing system. Pre-focusing lever & tension adjustment ring.
- The slow motion has 1Div=0.002mm.
- Quadruple nosepiece revolves on ball bearing.
- Mechanical stage size 125mm X 135mm having low positioned co-axial controls on ball bearing.
- Built-in-base illumination system with 6V-20W halogen bulb and power supply.
- Cross movement 55mm X 75mm.
SUB STAGE CONDENSER
- Abbe Condenser N.A.1.25 swing out filter holder, Iris Diaphragm.
BLUE FILTER
- Styro Foam Molded Pack.
|
|
|
|
|
|
OBSERVATION HEAD WITH LCD SCREEN
Binocular observation head inclined at 30° rotatable at 360°. 8 inch LCD Screen. Built-in-digital camera with RCA, S-Video & USB-2 output with 3.1 Mega Pixel Resolution Internal media card reader/writer.
EYEPIECE
- Wide field eyepiece 10X (Paired) FOV 18mm
OBJECTIVES (INFINITY CORRECTED)
- M Long Working Distance Plan Achromatic 5X
- M Long Working Distance Plan Achromatic 10X
- M Long Working Distance Plan Achromatic 50X ( S L )
- M Long Working Distance Plan Achromatic 80X ( S L ) Dry
MECHANICAL BODY
- Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
- Reverse Angle quadruple nosepiece on ball bearing.
- Mechanical stage is 242mmX172mm.
- The Mechanical stage has low positioned co-axial controls on ball bearing guide ways.
- Hand rests on both sides.
ILLUMINATOR
- The Epi illuminator has 12V-30W halogen lamp, adjustable brightness.
POLARIZING OUTFIT
- Analyser rotatable 360o. Polarizing & Analyser can be slided in/out of the optical path.
|
|
|
|
|
|
TRINOCULAR OBSERVATION HEAD
- Siedentopf observation head inclined at 45o .
- Diopter adjustment ring on ocular tube.
- Interpupillary distance from 50mm to 75mm.
EYEPIECE
- Wide field eyepiece 10X (Paired) FOV 22mm
OBJECTIVES (INFINITY CORRECTED)
- M Long Working Distance Plan Achromatic 10X WD 11mm
- M Long Working Distance Plan Achromatic 20X WD 9mm
- M Long Working Distance Plan Achromatic 50X WD 3.8mm
- M Long Working Distance Plan Achromatic 80X ( S L ) Dry
MECHANICAL BODY
- Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
- Reverse Angle quadruple nosepiece on ball bearing.
- Mechanical stage is 242mmX172mm.
- The Mechanical stage has low positioned co-axial controls on ball bearing guide ways.
POLARIZING OUTFIT
Analyser rotatable 360o. Polarizing & Analyser can be slided in/out of the optical path.
ILLUMINATOR
- Epi-Koehler’s illumination. Aperture iris diaphragm and field iris diaphragm 12/30W AC 85-230V. Adjustable brightness. Filter wheel fixed in light path with blue, green & yellow filter
|
|
| ... products without technical information |
| |
|
Benchmark microscope for field inspection of fibre optic connectors for contamination or damage. Available in 200x, 400x and 200-400x zoom versions with adapters for all popular connector types the PriorSpec II offers a high degree of flexibility along with the highest image quality of its class.
|
|
| ... products without technical information |
| |
The VDM-E/Z™ is available with two interchangeable optics options:
- Patented Extended Depth of Field (EDF) Objective with on-axis lighting
- Zoom Objective with fiber optic ringlight and add-on lenses
The system is complete with fiber optic lighting and is available with a number of options to enhance its versatility. When inspecting small parts from any angle, VDM is the effortless clear choice.
|
|
It allows quick and precise setting of specimen and microscope, and hence provides comfortable operation.
SPECIFICATION
- Sensor : 3.15 Megapixel Color, CMOS, 1/2"
- Active area : 6.55 × 4.92 mm
- Sensor resolution : 2048 × 1536 Pixel
- Pixel size : 3.2 ¼m × 3.2 ¼m
- 3 × 10 Bit RGB
- Pixel clock : 36 MHz
- Dynamic range : 58 dB (at 10 ms exposure time)
- Max. exposure : 3 s
- Max. frame rate : 35 fps (682 × 512)
- Image resolution : 2048 × 1536
- Binning : 1024 × 768 (2x) und 682 × 512 (3x)
- Digital Interface : IEEE1394a Firewire
- IR-Cut-off filer : fixed in C-Mount
- Optical Interface : C-Mount (0.5× TV Adaptor recommended)
APPLICATIONS
- Life Science
- Pathology
- Histology
- Cytology
- Live Cell Imaging
- Strong Fluorescence
- Documentation / Archiving
- Material Science - Metrology
- Mineralogy
- Manufacture / Semiconductors
- Plastic & Polymers
- Agriculture & Food Science
|
|
|
|
|
|
The software provides simplest, accurate and user-friendly platform to measure length, width, height, thickness, perimeter, radius, angle, minor axis and major axis, area, etc. on an object captured from any source. Creates customized reports with images, date and text.
IMAGE EDITING
- Cut, Copy, and Paste.
- Selected copy by free hand AOL controlled by four arrow keys available on keyboard or mouse with zoom preview.
- Crop, duplicate, restore
- Resize
- Compression
- Conversion to other format BMP, JPG, TIF, PNG, GIF & PSD
- Flood fill or spray with selected color at selected portion.
- Grid creation; 5X5, 10X10 & 100X100 lines.
- Drawing tool curve, line, square, and circle with node control and provision to change color & thickness of the line
- Write text in any color or font.
- Pointer to place on an object in four directions with provision to change its color & thickness.
- Eraser works only on line, arrow or on any drawing tool.(not on original image)
- Camera Lucida
- Montage feature to merge stored image together. Useful to Merge different focuses of same image.
- Image stitching.
- Highlighter.
- Pixel by Pixel Correction by key board.
- Multiple image folder with Search facility.
- Filter application on selected area.
|
|
|
|
