CIP self-priming pump adopts acid-resisting stainless steel (AISI 316) in valve body, which has unique acid and alkali resistance, and comply with sanitary requirements for foods.
As a positive displacement pump, its features are superior to centrifugal pump since it suction liquid mixed with air or foams and even merely air. It is widely used to suction material with liquid level below the pump, For instance in the milking room, it suctions milk from the milk barrel. It can also be used in automatic CIP cleaning system as return flow pump in cleaning tank. The mechanical sealing is the build-in influx type, and the temperature of suctioned materiaI is no higher than 100℃.
|
|
Specifically designed to overcome the challenges of reliable and accurate pumping at high-volume capacities. Every revolution of the 420 pumps more than 1½ gallons; the 520, more than 2 gallons. Ideally suited for tomato, vegetable and pet food industries and for chemical/industrial applications.
- Rotor/shaft connection sealed from the product zone
- 316L stainless steel pump body
- Exclusive, non-galling Waukesha "88" alloy rotors;
316L stainless steel rotors optional
- Bi-directional flow
- Mechanical seals standard; O-ring seals or variety of
standard commercial seals optional
- Seal replacement from the front without removing
pump body
- Maximum pressure: 150-200 psi (10.3-13.8 bar)
- Temperature range: -40° F. (-40° C.) to 300° F. (149° C.)
|
|
Moyno 1000 Pumps
Economical, high-efficiency Moyno 1000 pumps offer an unparalleled combination of features other positive displacement pumps cannot match.
|
|
Waukesha Cherry-Burrell's traditional "Can-Do Pump." Versatile in application, its reliability has made it the industry standard worldwide for more than 50 years.
- Easy cleaning and disassembly
- Flexible, three-way mounting
- Field interchangeable single and double "O" ring and mechanical seals
- Exclusive, non-galling Waukesha "88" alloy rotors
- 3-A and BISCC approved
- Maximum pressure: 200 psi (13.8 bar)
- Temperature range: -40° F. (-40° C.) to 300° F. (149° C.)
|
|
|
|
|
|
Salient Features
* Positive displacement, inherently self-priming and capable of handling entrapped gases.
* Inherently non clogging and capable of handling high percentage of solids.
* Continuous pulsation free flow with minimum turbulence and low internal velocity within the pump.
* Doubled sealed articulation joints for longer service life of critical components.
* Temperature range upto 120OC.
* Simple maintenance, sturdy construction, no valves needed which would impede the flow.
* Low NPSH, higher suction with up to 8.4 meter of water column and capable of developing high pressure up to 24 bar even at low pump speed .
* Efficiently handles Non-Newtonian media, slurries and fibrous contents up to 1 million centipoise.
* Capability of variation in flow rate by just changing the pump speed.
* Capability to work on uneven/inclined surfaces.
* Elimination of gearbox.
* Simple construction and high reliability of operation.
* Energy conservation and minimum installation space requirement.
|
|
|
The Seraphin skid prover system is made up of a precision volumetric stainless steel Prover connected to a pump-off system and mounted on skid. The prover drain valve is plumbed to piping that can be routed via butterfly valves to a gravity drain or to the pump. A manual hose reel, with hose and nozzle, is connected to the pump. The hose is used to route the petroleum to an above ground storage tank or up into a tank truck.
|
|
|
|
