Since the creation and patenting of the original DualVee® wheel in 1967, it continues to provide easy to use, easy to install guide wheel components and assemblies. DualVee is ideal for a wide array of applications, from the wash room to the sawmill. These rugged yet economical guide wheels are quiet, ideal in long length applications, and tolerant of harsh environments.
DualVee's recirculating elements are self-contained and isolated from the environment; rolling contact between the wheel and track sweeps debris aside, making it ideal for use in contaminated environments.
DualVee offers three different wheel options; original guide wheels, studded guide wheels, and new integral one-piece guide wheels for lower cost and ease of installation. A wide variety of bushings and journals are available.
DualVee single edge or double edge track with patented mounting shoulder is available in carbon steel or stainless steel, induction hardened or "as formed". Hardened track comes in single lengths up to 20 feet, unhardened in lengths up to 22 feet. Track is easily butt-jointed for longer length applications.
A number of accessory items are also available including wheel covers, lubricators, track plate assemblies and wheel plate assemblies.
|
|
A highly effective system for lower cost and accuracy builds up from a single edge track and matching professional wheels. DualVee components are available in a range of sizes to suit most applications with high temperature and vacuum/clean-room options available to complement existing stainless steel components.
- Track lengths up to 6m with unlimited lengths achievable by butting
- Available drilled or un-drilled to minimise additional engineering
- Ex-stock availability |
|
| The SMITH-TRAX® special duty track wheel bearings are machined from high-alloy steel and are case-hardened for maximum longevity. These bearings manufacturers are fitted with deep-groove ball bearings supplier or tapered roller bearings to handle both high radial and thrust load applications. |
|
Combine the high capacity of Load Runners idler-rollers with high-strengthsteel Load Rails, cut to length and drilled to your specifications. Eliminate design time and sourcing costs for heavy-duty material handling systems.
|
|
Rail rollers are self-retaining, single or double row units with particularly thick-walled outer rings. These bearings manufacturers can support axial forces in both directions as well as high radial forces. The bearing outer rings have a crowned or cylindrical outside surface. Designs with a crowned outside surface are used where there is misalignment in relation to the raceway and edge stresses must be avoided. The track rollers are available with an inner ring, with a stud and with a plastic tyre on the outer ring.
|
|
YTGW Guide Wheels are the main components of the Linear movement system, they can be widely used in the industrial professional robot, cutter, motion track, production flow and so on.
The surface of outer ring is the "W" profile formed by the two "V" with an angle of 90 degrees. The internal or external side face can be matched separately with the concave or protrudable track that both have a "V' profile with the angle of 90 degrees, and also the internal side face can be matched well with the cylindrical track.
Wheels feature the internal design of double row angular contact globe bearing and a thick-walled outer ring, so the wheels can accommodate higher loads.
Wheels are made of the high-quality professional bearing steel, processed by heat treatment and precision grind, and are filled with a long service life, high-grade and multi-purposes grease. Wheels mantle the metal shield or rubber professional seal (suffix X) to prevent the dust. YITONG also can provide the wheels with the concentric or eccentric bushings, as well as the wheels made from the corrosion resistance stainless steel.
|
|
- Industrial roller ø19, Nylon, Slot 5
- Roller ø29, Nylon, Slot 6
- Roller ø39, Nylon, Slot 8-12
- Roller ø47, Nylon, Slot 8-10
- Roller ø58, Nylon, Slot 10 |
|
Wire Professional guides and Straightening Rollers - type A or AT
Field of Application :
The straightening of cables, strips and wires is performed in steps with successive stages until the final product is obtained. To rationalize the handling between the different steps the material is stocked on reels or on bobbins and takes forms which are not natural.
For every production step, it is therefore necessary to carry out the inverse process by taking the material off its support. At that moment, the straightening operation takes place. It may be divided into three steps:
The straightening, consisting of putting the material back into its original shape. The operation is carried out by the first straightening rollers.
The removal of the residual constraint in the material, due to the winding on the bobbin. This operation is performed by the rollers located in the central part of the professional straightener.
The forming of the wire carried out by the last rollers on the straightener, generally placed at an angle of 90°compared to the angle of the first rollers.
|
|
Track wheels with Gothic arch groove - type SG
The function of series SG rollers is same as the series LFR rollers. But they are mainly used in the flat track and in the condition required compact structure. After rollers are installed to the slider, the shaft will be not or seldom over the roller's side planes. |
|
| A LIFETIME BOND must be perfect. With JESA's plastic over moulded ball bearings supplier, the moulded outer and the steel bearings specifications are as one for a lifetime the perfect bond. Our collaborative programs with renowned universities ensures that our products offer cutting edge performance, long life, low noise and constant dissimilar material adhesion. |
|
Guide roller with threaded rod
- Profile in arc of circle for fonctionnemenî on tree
- Lubricated with life and tight
- Composed of a roll of the dice with two oblique lines
- Fixing of the industrial roller by its threaded rod
- Exist in standard version (ref.: FRW) or with eccentric (ref.: FRWE)
- Also Exist in lNOX (ref.: FRW... - VA.FRWE... - GOES)
Another products available: |
|
Roller combined fixed TR---.0200
Roller combined fixed TR---.0250
Roller combined fixed TR---.0300
Adjustable roller combined by eccentric TR---.0350
Roller combined with polyamide TR guidance---.0360
Vulkollan roller - Esparto speed ACE---.3800
Spherical roller of cam KR---.1810
Cylindrical roller of cam KR---.1910
Cylindrical suppliers of bearings assembled on axis SR---.3---
Cylindrical rollers SR---. ---
Radial roller TR---.0400
Adjustable roller combined with threaded rod TR---.1300
Roller with strong load capacity MR. ---.0610
Fixed combined roller of precision Pt---.0260
Combined roller of adjustable precision by eccentric Pt---.0365
Roller combined with ball TR---.4100
Roller with head of support for high temperature TR---.019-
Eccentric roller BQ---.1012
Chrome roller with synthetic guidance TR---.0380
Roller STAINLESS with synthetic guidance TR---.0390 |
|
