The e-lightxs Industrial Ethernet media converters have an extra small housing with a dimension of 80 x 62 x 25 mm.
The flat design of the stainless steel housing offers an extremely high degree of flexibility and safety for all kinds of indoor and outdoor applications.
e-lightxs can either be mounted onto a DIN EN rail or fastened onto the wall. A clip is already included in the scope of delivery, too.
e-lightxs is suitable wherever there is little space, e.g. in small distribution boxes.
In connection with other systems out of the e-light and DragonLine series respectively, individual applications can be realized.
|
|
|
|
|
|
The Iguana Series IRE-321 and IRE-321EC are Industrial 5-port Unmanaged Ethernet Switches with three 10/100 Mbps Ethernet ports, two multi-mode fiber ports and Redundant ring technology. The self-healing technology can recover from any network downtime in less than 300 ms. Modbus/TCP, Modbus/RTU and OPC are supported by IRE-321 Series. SCADA application can monitor status of Ethernet and fiber port with Modbus or OPC protocol. With the optic port, IRE-321 Series transmits data at high speed for long distances up to 2 km with an SC connector. The flammability protected entry-level industrial hardened Ethernet switch is specifically designed in applications where transmission must be protected from electrical exposure, surges, lightning, chemical corrosion and in hazardous locations. The IRE-321EC comes ready with conformal
coating and extended temperature of -30 to 75 degree C. In addition, the Iguana switches offer Ethernet isolation of 1500 Vrms and frame ground for EMS protection which is not a standard feature in most Industrial Ethernet devices.
|
|
|
As the leading supplier of industrial computers worldwide, Advantech has the experience and know-how to offer world-class industrial communication products for PC-based automation. Advantech’s industrial Ethernet Switches and Serial Device Servers not only have the ability to connect sensors and I/O devices from field sites and factories, but also provide an Ethernet backbone to integrate these switches and device servers in real time.
|
|
|
|
|
|
|
The Whale series WME-867-M12 is a highly reliable IP67 Industrial 8-port Managed Ethernet Switch. It has 8 10/100TX M12 ports that support IEEE 802.3/802.3u/802.3x with 10/100M, full/half duplex, and MDI/MDI-X auto-sensing. With its high performance switching device, WME-867-M12 provides redundant self-recovery mechanism in less than 20ms on full load which allows you to establish a redundant Ethernet network to build a back-up ring topology. With powerful network management functions, WME-867-M12 can be remotely configured by Web browser, managed by SNMP and RMON. Event notification can be defined via SNMP trap, Syslog, Relay output or E-mail. Security is enhanced with advanced features like Port based VLAN, Tagged VLAN and IP security. Performance is optimized by Quality of Service and IGMP Snooping/querying. The WME-867-M12 is equipped with a terminal block to provide dual power inputs with reverse polarity protection. Its metal shell robust housing and tightly sealed M12 connectors is specifically designed for vibration-proof & water resistant to secure Industrial Ethernet applications.
|
|
|
The Whale Series WUE-567 Industrial IP-67 Ethernet Switch is a highly reliable and fault-tolerant industrial 5-port unmanaged IP-67 Switch. It has 5 10/100TX RJ45 ports that support IEEE 802.3/802.3u/802.3x with 10/100M, full/half duplex, and MDI/MDI-X auto-sensing. WUE-567 IP-67 switch is designed for use in industrial waterproof & harsh environments. Built with IP-67 connectors, it guarantees a total protection that can withstand a variety of extreme conditions such as high temperature, extreme shock, vibration, dust particles, oil or even liquid immersion. WUE-567 IP-67 switch also has extended temperature and DIN-Rail models available.
|
|
|
Ethernet Direct offers Moose Series Industrial Modbus over TCP Solutions whcih include industrial switches and gateways. In industrial applications, a fault-tolerant Ethernet network protects the system from downtime which will cause a great amount of losses in production. In SCADA applications, it is important that a device can monitor the status of Ethernet and fiber ports with Modbus or OPC protocol. This is the design concept of Moose Industrial Modbus Ethernet Switches. The MRM Managed Modbus Ethernet Switch supports Modbus/TCP protocol to read port status. It comes with extended temperature and conformal coating options. MRM Managed Modbus Ethernet Switch supports Modbus/TCP, Modbus/RTU and OPC protocols to provide majority of applications with seamless process. When these devices are placed into a redundant ring application, its redundant ring technology detects and recovers a fiber or copper link failure in milliseconds.
|
|
|
IAR-7002-WA/WA+ is a reliable 802.11b/g WLAN Access Point with 2 ports 10/100TX ports router where ETH1 for LAN ETH2 for WAN. It supports LLDP for topology discovery and STP for wireless/wired redundant connections. It also supports 802.1X and MAC filter for security control. It could be configured to operate in 3 modes of routing function: Dynamic/Static IP route, PPPoE authentication, and Modem (56K/GPRS/3G/3.5G Modem) dial up. In the mode of Modem dial up, it support both traditional 56K modem and GPRSG/3G/3.5G Modem with USB interface. Users can set up WLAN environment to fulfill demands of various applications rapidly by dialing up cellular modems. In addition, IAR-7002-WA+ also provides PD feature on ETH2 which is fully compliant with IEEE802.3af P.O.E PD specification. This feature extends the layout up to 100 meters. Therefore, IAR-7002-WA/WA+ are one of the best solution for applications of wireless communication
|
|
IES-1080/1062 series are unmanaged Ethernet switches with 6x10/100Base-T(X) & 2x100Base-FX, 1000Base-T, 1000Base-SX or 1000Base-LX ports. IES-1080/1062 series support redundant power input, relay output alarm, and surge protection. The wide operating temperature range from -40XC to 70XC can satisfy most of operating environment.
|
|
|
|
|
|
Worlds fastest Redundant Ethernet Ring: O-Ring (Recovery time < 10ms over 250 units of connection)
Open-Ring support in open architecture (recovery time is depended on the other vendors ring technology)
O-RSTP support applications of complex topology with optimized RSTP technology
RSTP/STP(IEEE 802.1w/D)
IES-3080/3062 series are managed Redundant Ring Ethernet switches with 6x10/100Base-T(X) & 2x100Base-FX, 1000Base-T, 1000Base-SX or 1000Base-LX ports. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 10ms over 250 units of connection), Open-Ring, O-RSTP and RSTP/STP (IEEE 802.1w/D) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. Another Open-Ring technology is also supported which can be applied for other vendor's proprietary ring. IES-3080/3062 series can be managed centralized and convenient by a powerful windows utility X Open-Vision. In addition, the wide operating temperature range from -40XC to 70XC can satisfy most of operating environment. Therefore, the switch is one of the most reliable choice for highly-managed and Fiber Ethernet application.
|
|
ORing offers a wide variety of managed or unmanaged switches to fit different networking environment. ORing’s new industrial Slim Type unmanaged Ethernet switches, IES-1000 slim type series, are more light, more skinny, and thus IES-1000 series is more convenient for the end users to deploy the networking environment by saving space! Further, ORing’s IES-1000 slim type series has a special separate power alarm design operated by a DIP switch.
The skinny dimensions and special power alarm design makes IES-1000 slim type series meets the demands of a variety of applications, such as power substation automation systems, intelligent transportation, telecommunication, etc., which facilitate the deployment of mission-critical applications across networks in the most cost-effective way.
|
|
DragonLine 5x10/100TX (Slimline)
Technical data
RJ-45 port support Auto MDI/MDI-X Function
Store-and-Forward Switching Architecture
Back-plane (Switching Fabric): 1.0Gbps
2K MAC Address Table
IP-30 Protection
DIN Rail and Wall Mount Design
Wide-range Redundant Power Design
Power Polarity Reverse Protect
Overload Current Re-settable Fuse Present
Provides surge protection 3000 VDC for power line
Supports 4000 VDC Ethernet ESD protection
|
|
DragonLine 8x10/100TX + 2x100FX Industrial Ethernet Switch (Managed/Ring)
Technical data
RJ-45 port support Auto MDI/MDI-X Function
Store-and-Forward Switching Architecture
Back-plane (Switching Fabric): 2Gbps
1Mbits Packet Buffer
8K MAC Address Table
Input Power Isolation design for Telcom application, Pass Hi-Pot test~1.5KV
Wide-range Redundant Power Design
Power Polarity Reverse Protect
Ring, Dual Homing, and Couple Ring Topology
Provides redundant backup feature and the recovery time below 300ms
VLAN
Port Trum with LACP
Bandwidth Control
Supports IEEE802.1ab LLDP
Port Mirror: Monitors traffic in switched networks
IGMP with Query mode for Multi Media Application
System event log
Quality of Service: Port based/Tag based, IPv4 ToS, IPv6 Different Service
|
|
DragonLine 10/100 TX to 1xFX Industrial Ethernet Media Converter (PoE)
Technical data
RJ-45 port support Auto MDI/MDI-X Function
Embedded 1 port PoE Injector Function
Store-and-Forward Switching Architecture
Built-in Link Lose Forwarding Technology
IP-30 Protection
DIN Rail and Wall Mount Design
DC 48V Redundant Power
Overload Current Re-settable Fuse Present
Provides EFT protection 3000 VDC for power line
Supports 6000 VDC Ethernet ESD protection
|
|
DragonLine 16x10/100TX + 2x10/100/1000T/ Industrial Ethernet Switch (Gbic/SFP)
Technical data
SFP(Mini-GBIC) supports 100/1000 Dual Mode
Store-and-Forward Switching Architecture
Back-plane (Switching Fabric): 7.2Gbps
1Mbits Packet Buffer
8K MAC Address Table
Wide-range Redundant Power Design
Power Polarity Reverse Protect
Overload Current Protection
Provides EFT protection 3000 VDC for power line
Supports 4000 VDC Ethernet ESD protection
|
|
Korenix JetCard 2105/2205 Ethernet Switch Cards are flexible and high performance Universal PCI/PCI-104 cards, equipping IPC devices with various Ethernet management features. The easy-to-install drivers that come with JetCard allow users to easily set up specific complex systems. Combined with 1.5KV Hi-pot isolation protection and overload current/voltage protection, JetCard 2000 series are the best choice for a reliable and cost-effective embedded networking solution in severe industrial environments.
* Support 32 bit PCI/Universal PCI bus
* 5 ports RJ45 Ethernet Switch
* IEEE 802.3 10 Base-T and 100 Base-Tx compatible
* Full or half duplex at 10/100 Mbps
* IEEE 802.3u Auto-Negotiation supported
* IEEE 802.1Q VLAN supported
* QoS supported
* 1.5KV Hi-pot isolation protection
* -25~70oC operating temperature for hazardous environment
application ( JetCard 2105-w/JetCard 2205-w: -40~80oC)
|
|
The JetCon 3401G, the industrial Gigabit Ethernet media converter, is equipped with a rugged aluminum alloy case with IP-31 grade ingress protection against
damages of solid objects or dust. With the excellent characteristics of heat dissipation, JetCon 3401G is capable to perform better than ordinary Gigabit Ethernet media converters which are enclosure by steel metal with various of heat dissipation holes.
Unlike those with a single power input, the real time redundant power backup on JetCon 3401G leads to the functionality of a real Industrial Gigabit Ethernet Media Converter with the non-stop transmission.
*Converts 10/100/1000TX to Gigabit Fiber
*Flexible SFP Fiber transceiver design
*Auto Fault Detection and Alarm
*Fault Alert for port and power
*Two way Link loss forwarding
*Power redundancy with wide range input
*IP-31 grade protection with wide range operating temperature
*1.5KV Hi-Pot testing passed
|
|
CM-011-ST (CM-ST100L)
100FX(ST, Multi Mode) to 10/100TX, LLF, LFP
CM-011-SC (CM-SC100L)
100FX(SC, Multi Mode) to 10/100TX, LLF, LFP (Agilent)
CM-011-SC60 (CM-SC100L-SC60)
100FX(SC, Single Mode, 60km) to 10/100TX, LLF, LFP
CM-011-SC30 (CM-SC100L-SC30)
100FX(SC, Single Mode, 30km) to 10/100TX, LLF, LFP
CM-A1000L-GB
LLF + LFP, 10/100/1000 Base-Tx to Mini-GBIC Media Converter
|
|
|
IMC-1021FX are industrial media converters provide media conversion between 10/100BaseT(X) and 100BaseFx. IMC-1021FX series are rigid IP-30 housing design and supporting an operating temperature of -10 to 60?C, and an extended operating temperature (T models) of -40 to 70?C. Therefore, the IMC-1021FX are reliable media converters and can satisfy most demand of operating environment.
|
|
|
|
|
|
|
Our scope of services regarding electronic systems and communication components for fiber optic technology ranges from RS232, RS422 and RS485 to TTY fiber optic converters. Apart from that, our d-light systems offer solutions for the connection of Profibus, Profibus redundant and Modbus-Plus. Our series e-light and DragonLine consist of both managed and unmanaged Industrial Ethernet switches, partly with PoE (Power over Ethernet) functionality. With DragonLine we cover numerous applications concerning Ethernet and Gigabit-Ethernet. The systems of our io-light series transmit switch, control and analogue signals via fiber optics. Furthermore, we offer optical amplifiers and CAN fiber optic converters. Among that, we also offer compact splice boxes and hybrid splice boxes. POF, HCS and multimode or singlemode fiber optics are unsusceptible to electrical and magnetic interferences. Other performance features are the potential separation of transmitter and receiver and ranges of up to 100 km between two fiber optic systems. Apart from SC and ST as optical connection types, E2000 is also available.
|
|
DragonLine 4 Slot Modular Chassis Switch (Managed/Ring)
Features:
- 4 slots for 8 ports 10/100TX, 8 port 100FX and Gigabit uplink module
- Port Based VLAN /802 .1Q VLAN
- Confirms to IEEE802.3u 10BASE-T, 802.3u 100BASE-TX/FX, 802.3ab 1000BASE-T, 802.3z Gigabit fiber
- IEEE802.3x Flow control
- High back-plane bandwidth 8.8Gbps
- I- EEE802.3ad Port trunk with LACP
- Stack management via one IP address, easy management by Web GUI
- Broadcast storm filter
- IGMP support for Multi Media application
- IEEE 802.1p class of service
- Port mirror / Port security
- DHCP client
- Port bandwidth control
- IEEE 802.1d Spanning tree protocol
- Supports GVRP function
- Web/ SNMP / Telnet / CLI management
- Option Module for slot:
- 2 x Gigabit SX module
- Gigabit copper+ Gigabit SX module
- 2 x Gigabit copper module
- 8 ports 10/100TX module
- 8 ports 100FX module
- IEEE 802.1x user authentication
|
|
The series e-light² EL100U2 are 8 port unmanaged Industrial Ethernet layer 2 switches with auto negotiation and auto MDI/MDIX.
The EL-100U2 series contains unmanaged 7/8 port switches for 10/100MBit/s optionally with up to eight RJ45-Ethernet-ports and up to three optical ports which work with POF, HCS, and multimode or singlemode fiber optics. Additional features are auto negotiation, MDX/MDIX and redundant power supply.
The ruggedness to electrical and magnetic interferences, the potential separation of transmitter and receiver as well as ranges up to 40km between two fiber optic systems are important performance features of the transmission with POF, HCS and multimode or singlemode fiber optics. LEDs and potential free contacts of a differential relay signalize defective states.
Apart from ST and SC as optical connection types, E2000 is also available. All systems feature communication with two fibers or a single fiber by BIDI technology with SC connection.
|
|
|
IES-2060/2042FX is lite-managed Redundant Ring Ethernet switches with 6x10/100TX ports or 4x10/100TX and 2x100Base-FX ports. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 10ms over 250 units of connection) and RSTP/STP (IEEE 802.1w/D) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. IES-2060/2042FX can be managed centralized and convenient by a powerful windows utility X Open-Vision. The wide operating temperature range from -40 to 70oC can satisfy most of operating environment. Therefore, the switch is one of the most reliable choice for easy managed and Fiber Ethernet application.
|
|
|
IES-2050 is a lite-managed Redundant Ring Ethernet switch with 5x10/100TX ports. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 10ms over 250 units of connection) and RSTP/STP (IEEE 802.1w/D) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. IES-2050 can be managed centralized and convenient by a powerful windows utility Open-Vision. The wide operating temperature range from -40 to 70oC can satisfy most of operating environment. Therefore, IES-2050 is one of the most reliable choices for industrial networking application..
|
|
e-light2M is a 8 port switch that features ring function based on the Pathfinder Ring (P-Ring) with a recovery time of less than 300ms.
e-light2M is available with up to 4 flexibly configurable FX-ports and up to 6TX-ports. The Fast Ethernet switches with their industrial design are useable in a wide temperature range of -30°C to +75°C and are suitable for both DIN rail mounting and wall fastening.
The e-light2M management highlights are amongst others: Web Management GUI, Port Mirroring, DHCP Client, IGMP, SNTP, SMTP, port and tagged based VLAN, SNMP in connection with Web Management and RMON, quality of service as well as an alarm relay output for system events. e-light2M is suitable for POF, HCS, multimode and singlemode and allows ranges of up to 100km.
|
|
|
|
|
|
JetNet 4706, an improved and strengthen manageable industrial PoE switch, it is designed for industrial PoE applications such as IP surveillance or wireless access points. It supports intelligent PoE control and schedule management; each of the four PoE ports can be configured in a weekly schedule by hourly basis and PoE on/off can be remote controlled via SNMP and Web. JetNet 4706 is compliant to both IEEE 802.3af PoE as well as the pioneer standard of IEEE802.3at PoE Plus design for boosting PoE delivery up to 30W in each of the four PoE ports. JetNet 4706 can auto-detect 24V & 48V power input and deliver 24V & 48V PoE output allows more applications where 48VDC is not an option.
*Four 10/100 TX Power over Ethernet ports and two redundant
10/100 TX uplink ports
*DC 24V Power Input for DC 22V output through Ethernet
(Non-standard PoE)
*DC 48V Power Input for IEEE 802.3af 48V PoE output (IEEE 802.3af)
*Up to 30W per port for High Power solution by Power Input DC 55V
(IEEE 802.3at)
*UP to 100W for total power budget
*Support IEEE 802.3af for PoE detection and PoE classification resistors
*PoE control and schedule by hour/weekly basis
*Auto-detect Powered Device status for device auto-reset (LPLD)
*Patented Rapid Super Ring technology (RSR), back up system recovery time less than 5ms
*SNMP v1/v2c/v3, IGMP snooping v1/v2/v3, RMON, LACP, VLAN, QoS
*Network security by IP/MAC address, SSL and SSH
*Built-in hardware watchdog timer for system auto-reset
*Aluminum rugged enclosure with IP-31 grade protection
*Forced mode Powering
*Wide operation temperature: -25~60oC
Also we have Industrial 6-port Web-Managed PoE Plus Switch JetNet 3706
|
|
LPES-2224C
24 Port 10/100 PoE SNMP power management switch
+ 2 Giga combo with 200W AC power + 1 DC redundant input
LPES-2208C
8 Port 10/100 PoE switch ( 8 PoE injectors)
POE-UPWM
400W UPS DC power unit with AC/DC output
POE-2400M Midspan Hub
24 Port 10/100 PoE SNMP Midspan Hub with 200W AC power
+ optional RPS - Powerdesign chipset
POA-100
802.3af standard PoE One Port Injector
autodetect for non-802.af - devices
POS-100S
PoE power data-splitter with 1 cable 4 dipswitch to adjust voltage (5/7.5/9/12V)
|
|
|
|
|
|
|
IPS-2042TX/2042FX are lite-managed Redundant Ring Ethernet switches with 4x10/100TX ports with PoE PSE function and 2x10/100TX or 2x100Base-FX ports. IPS series support Power over Ethernet, a system to transmit electrical power, along with data, to remote devices over standard twisted-pair cable in an Ethernet network. Each IPS switch has 4X10/100TX PSE (Power Sourcing Equipment) ports. PSE is a device (switch or hub for instance) that will provide power in a PoE setup. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 10ms over 250 units of connection) and RSTP/STP (IEEE 802.1w/D) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. IPS-2042TX / 2042FX can be managed centralized and convenient by a powerful windows utility X Open-Vision. The wide operating temperature range from -40 to 70oC can satisfy most of operating environment. Therefore, the switch is one of the most reliable choice for easy managed and Fiber Ethernet application.
|
|
DragonLine 4x10/100TX + 1FX Industrial Ethernet Switch (PoE)
Technical data
RJ-45 port support Auto MDI/MDI-X Function
Power over Ethernet
Store-and-Forward Switching Architecture
Back-plane (Switching Fabric): 1 Gbps
1K MAC Address Table
IP-30 Protection
DIN Rail and Wall Mount Design
DC 48V Redundant Power
Power Polarity Reverse Protect
Overload Current Re-settable Fuse Present
Provides EFT protection 3000 VDC for power line
Supports 4000 VDC Ethernet ESD protection
|
|
|
|
|
|
|
The Cobra series CME-822E is a highly reliable and fault-tolerant Industrial 10-port Managed Power over Ethernet Switch. It supports eight PoE injector ports classified as power source equipment (PSE). CME-822E offers state of the art design with eight 10/100 Mbps Ethernet ports and two small form pluggable (SFP) ports that supports Gigabit SX or LC depending on your existing network structure. The innovative SFP fiber slot design provides user the flexibility to insert different fiber modules, either multi-mode or single-mode at various distances, whether you require typical 10km or overhaul 40 km, 80 km and 120 km distances. With its high performance switching device, CME-822E provides redundant self-recovery mechanism in less than 10ms on full load which allows you to establish a redundant Ethernet network to build a back-up ring topology. Dual homing and Ring coupling are supported to add reliability by allowing a device to be connected to be network by way of two independent connection points. CME-822E offers powerful network management functions including SNMP, SMTP, SNTP, Quality of Service, Class of Service, IGMP, Snooping, LACP, DHCP, VLAN, RMON, Port Trunk, Port Mirror, User Authentication (Radius) and IP Security. The CME-822E is equipped with a terminal block to provide dual power inputs with reverse polarity protection. Its IP-30 housing protection, wide operating temperature of -40 to 80 and DIN-Rail mounting is suitable for an industrial environment. The CME-822E is a plug-and-play solution for your Power over Ethernet applications.
|
|
JetNet 3705-24V is an Industrial 5-port PoE switch, designed to fulfill the specific needs of transportation system networks. JetNet 3705-24V integrates Korenix patented 24V vehicle PoE technology – the 24V to 48V power booster for making the deployment of standard PoE IP cameras feasible on buses, railcars, ships, harbors, etc.
Combined with rugged fan-less design, including vibration resistance and -40~60℃ wide operating temperature, JetNet 3705-24V overcomes the harsh conditions and ensures network reliability on all types of public moving vehicles.
Key features of JetNet 3705-24V are:
* 5 Ports 10/100 TX Industrial Switch with 4 PoE Injectors
* Korenix Patented Built-in DC 24 to 48V Booster for rail, bus, transit transportation
* Embedded 4-port IEEE 802.3af PoE, delivering 15.4W per port
* -40~60℃ wide operating temperature for hazardous environment
* Redundant 24/48 VDC power inputs with overload current protection
|
|
|
|
