The EDLM (3 color LED) and EDWM (5 color LED) are innovative LED signal towers with pressure and flame-proof housing designed specifically for use in potentially flammable and explosive atmospheres, such as chemical, petrochemical, mineral/natural gas production, food industries and combustible dusts.
* Zone1, 2 (II2G Ex d IIC T6) and Zone21, 22 (II2D Ex tD A21 IP66 T80C)
certified.
* Available in 3 color LED (EDLM) and 5 color LED (EDWM) style.
* Super bright LEDs provide long service life, maintenance-free operation.
* Flashing and/or continuous lighting
* Wall mount, flush mount and horizontal mount possible with supplied
mounting
@@ brackets.
* IP66
|
|
The MP series super slim 30mm silver color body signal tower is ideal for small devices.
* Size: 30mm diameter.
* Short body length type is also available (MPS).
* Available in 24V AC/DC.
* Colors available: red, amber, green, blue and clear/white.
* LED modules are interchangeable and stackable after purchase (up to 5 modules).
* NPN or PNP open collector compatible.
* Water and dust-tight IP65 construction.
* Units are shipped completely pre-wired and pre-assembled.
|
|
The LCE series offers the latest in LED technology.
Versatile and energy efficient.
* Size: 40mm diameter.
* Available in 24V AC/DC and "Free-Voltage" 90-250V AC versions.
* FB types include two selectable, single-tone intermittent alarms with adjustable volume to 85dB at 1m.
* Colors available: red, amber, green, blue and clear/white.
* LED modules are interchangeable and stackable after purchase (up to 5 modules).
* Units are shipped completely pre-wired and pre-assembled.
* Pole mount versions include 300mm steel pole and mounting bracket (SZ-012) with nuts and washers.
* NPN or PNP open collector compatible (24V type), and NPN open collector compatible (90-250V type).
* LCE-FB & LCE-FBW: Meet IP54
LCE-W: Meets IP65.
* Optional mounting brackets available.
LCE-U type
* Available in 24V AC/DC only.
* Silver color body.
* Versatile and flexible 3 meter jacketed cable.
|
|
The LME series offers the latest in LED technology.
Versatile and energy efficient.
* Size: 60mm diameter.
* Available in 24V AC/DC, 100V AC and 220V AC versions.
* FB types include two selectable, single-tone intermittent alarms with adjustable volume to 90dB at 1m.
* Colors available: red, amber, green, blue and clear/white.
* LED modules are interchangeable and stackable after purchase (up to 5 modules).
* Units are shipped completely pre-wired and pre-assembled.
* Pole mount versions include 300mm steel pole and mounting bracket (SZ-013) with nuts and washers or 300mm aluminum pole and plastic top mount bracket.
* NPN or PNP open collector compatible (24V type), and NPN open collector compatible (100V AC or 220V AC types).
* LME-FB & LME-FBW: Meet IP54
LME-W: Meets IP65.
* Optional mounting brackets available.
LME-U type
* Available in 24V AC/DC only.
* Silver color body.
* Versatile and flexible 3 meter jacketed cable.
|
|
|
|
|
|
Get the attention you need with LKEH series signal tower with voice message/audible alarm hybrid unit.
* Available in voice message type (LKEH-FV) and 32 pre-recorded sounds type (LKEH-FA/FC/FD/FE)
* Size: 100mm diameter
* Available in 24V DC, 100V AC and 220V AC versions
* Volume is adjustable from 0 to 105dB at 1 meter
* Continuous or flashing light
* Colors available: red, amber, green, blue and clear/white
* LED modules are interchangeable and stackable after purchase (up to 4 modules)
* Units are shipped completely pre-wired and pre-assembled
LKEH-FV (Voice synthesizer)
* Voice message or sound data is field-programmable with SD card (SD card is sold separately)
* Total recording time of 64 seconds (64kbit/s) can be divided up to 5
channels by bit input or 31 channels by binary input
LKEH-FA/FC/FD/FE (32 pre-recorded sounds)
* 32 sounds are pre-recorded in one unit. 4 sound types are available
* Select one sound group to play back 8 sounds by bit input or 32 sounds can be played back by binary input
Available by Special Order
* PNP open collector transistor type
|
|
The LU7 series versatile modular system signal tower light is perfect for OEMs that offer the light in different color combinations for their machine design.
* Size: 70mm diameter.
* Available in 24V DC and Free Voltage 90-250V AC versions.
* Colors available: red, amber, green, blue and clear/white.
* LED modules are interchangeable and stackable after purchase (up to 5 modules).
* FB types include flashing circuit and two selectable, single-tone intermittent and continuous alarms with adjustable volume up to 90dB at 1m.
* NPN or PNP open collector compatible (24V type), and NPN open collector compatible (90-250V type).
* Water and dust-tight IP65 construction.
* Color of terminal block in base unit corresponds to the lens color for quick wiring.
* Pole mount is also possible. (Optional mounting parts sold separately)
* MP3 sound module (LU7-V1) and LED strobe flashing module (LU7-XE) are also available.
Available by Special Order
* Silver and black color body type.
|
|
The LU5 series versatile modular system signal tower light is perfect for OEMs that offer the light in different color combinations for their machine design.
* Size: 50mm diameter.
* Available in 24V DC.
* FB types include two selectable, single-tone intermittent and continuous alarms with@volume up to 85dB at 1m.
* Colors available: red, amber, green, blue and clear/white.
* Pole mount is also possible. (Optional mounting parts sold separately)
* LED modules are interchangeable and stackable after purchase (up to 5 modules).
* NPN or PNP open collector compatible.
* Water and dust-tight IP65 construction.
Available by Special Order
* Silver color body type.
|
|
The PHE-3FBE1 series PC controllable LED signal tower light through the serial RS-232C connection is suitable to supervise your personal computer, server and / or workstation.
* Size: 40mm diameter (signal tower light)
* Connect with RS-232C cable directly to your PC, or by USB with converter.
* Two selectable single-tone, intermittent alarms with adjustable volume to 85dB at 1m.
* Reset switch can resume the system to the original status.
* Comes with standard light configuration: red / amber / green.
* RS-232C straight-through cable, AC adaptor required.
|
|
Warning light, buzzer and E-mail report to network manager immediately when network event occurs!
* Ethernet 10BASE-T/100BASE-T correspondent (selected automatically)
* HTTP, RSH, SMTP and SNMP protocols correspondent.
* Ping function monitors the health status of (up to) 16 IP devices.
* RSH and SNMP correspondent, and possible to cooperate with commercial
network management software.
* Reset switch can resume the system to the original status.
* Standard light configuration: red / amber / green.
* AC adaptor included. (for input voltage of 90-250V AC, Type A plug)
* Signal Tower Diameter: 25mm (NHE-3FB-RYG)
40mm (NHC-3FB-RYG)
60mm (NHM-3FB-RYG)
|
|
The WE series are Ultra-Slim wall mount signal lights that offer seamless integration with equipment.
* Ultra-slim 37.5mm profile.
* Available in 24V AC/DC.
* Body color is available in ivory white (WEP) and chrome plated (WE).
* FB types include flashing circuit and two selectable, single-tone intermittent alarms with volume to 90dB at 1m.
* LED colors available: red, amber, green, blue and clear/white.
* Units are shipped completely pre-wired and pre-assembled.
* NPN or PNP open collector compatible.
* WE and WEP: Meet IP65
WE-FB and WEP-FB: Meet IP54.
|
|
The WME series wall mount LED signal tower light offers seamless integration with most equipment.
* Size: Width 70mm, Depth 80mm
* Available in 24V AC/DC and "Free-Voltage" 90-250V AC versions.
* FB types include flashing circuit and two selectable, single-tone intermittent alarms with large volume up to 90dB at 1m.
* Colors available: red, amber, green, blue and clear/white.
* LED modules are interchangeable and stackable after purchase (up to 5 modules).
* NPN or PNP open collector compatible (24V type), and NPN open collector
compatible (90-250V type).
* Water and dust-tight IP54 construction.
* Units are shipped completely pre-wired and pre-assembled.
|
|
The LN870 Light Tower provides visual on/off indication of process conditions in safe and hazardous areas. Configurable up to five tiers high in a choice of five super-bright colours (red, amber, green, blue and white), they can be built exactly the way you want.
Each tier has a unique prism cut lens and internal reflective cone to improve visibility and requires one LED lamp for illumination which is current-limited to take a maximum of only 2OmA. Available for hazardous area use in both zones 1 and 2, up to two tiers can be driven from a single IIC interface.
There is a choice of pole or direct mounting, both incorporating a special vibration absorber. With the LED's low power consumption, low heat dissipation and long life expectancy, the LN870 is an ideal indicator for safe and hazardous areas alike.
|
|
Federal Signal's Litestak status indicator is a column of signal lights that indicate the status of a process or machine. The units may include up to five Light Modules (Model LSL) available in amber, blue, clear, green and red; or four light modules plus an optional Sound Module (Models LSS or LSH) to create a dual purpose audible/visual status indicator. The Sound Module always occupies the top position of a Litestak unit.
- Available in 24VDC, 120VAC and 240VAC
- Five lens colors
- Surface mount and integrated 3/4- inch pipe mount
- Indoor use only
- Type 1 enclosure
- Optional sounder available
- UL and cUL Listed, CSA Certified
|
|
The Federal Signal Litestak Sound Module is a microprocessor-based audible signaling device. The model LSS can be used as a stand-alone audible device or combined with the Federal Signal Litestak light modules to create an audible/visual signal.
- Available in 24VDC and 120VAC
- Modular unit fits on top of any Litestak configuration
- Select one of 18 tones
- Capable of outputs between 59- 69dB @ 10' (69- 79dB @ 1m)
- Indoor use only
- Type 1 enclosure
- UL Listed and CSA Certified
|
|
|
|
|
|
halfDOME90
# visual-audible LED-signal tower in half dome design
# for universal industrial, building and other applications
# any colour combination and housing size (2-5 positions) available
# 6 lens colours, 2 housing colours (grey, chrome)
# LED-steady light or LED-flashing light for each position selectable
# high protection class IP 65 - suitable for outdoor and indoor
# for horizontal and vertical mounting
# particular lens optics with reflective coating
- optimal signalling and visibility from each viewing angle (180)
- "moving" bright LED-light
# optional piezo buzzer in upper housing area available
- tone types continuous and pulsing
- volume individually adjustable ~70 - 90 dB (A) in 1 m
# SPS-fit (leakage, inrush current)
# available in nominal voltages 24 V AC/DC, 110/120 V AC, 230/240 V AC
# UL-certified - UL 4, 4X, 13
NOTE: The supply voltage 24 V AC/DC, 110/120 V AC or 230/240 V AC is determined by selecting the housing in the desired voltage. The built-in light and sound modules always operate with 24 V only.
|
|
Monolithic indicator banks 40, 60, 100 mm
Description
Indicator banks 40, 60 & 100 mm
Simplicity and speed of installation thanks to pre-cabled and pre-assembled products
Base mount: pole or base mount
Source light: LED
- guaranteed long life and maintenance free thanks to high resistance of LEDs to mechanical shock and vibration
- energy saving design with low power consumption
IP 54
Color of illuminated units: Red, Yellow, Green, Blue, White
Voltage: AC/DC 24V (DC 24 V : XVC1)
Type of illuminating effect: steady/ and/or blinking
Sound level [dB]: 70 to 85 or 60 to 85
Buzzer in option
Standards and certifications: CE, UR
Manufactured in conformity with the requirements of the RoHS (Restriction of Hazardous Substances) European Directive.
|
|
|
|
|
|
WERMA KombiSIGN 71 Modular Signal Tower System with high protection rating IP 65 and long-life LED
WERMA is extending its successful modular Signal Tower range with the addition of an attractive tower with a diameter of 70mm. The KombiSIGN 71 offers the high protection rating IP 65 for use in extreme conditions.
The unique KombiSIGN features, such as the practical bayonet fixing system facilitating simple operation and modular assembly, are once again incorporated into KombiSIGN 71. As a result of these features tool free bulb changes are possible with minimum effort.
KombiSIGN 71 offers the choice of two terminal elements; either an improved screwable connection or a terminal element with Cage Clamp technology providing screw free wiring. This simple connection system is unique to WERMA and its KombiSIGN is the only signal tower on the market which offers this technology.
The large degree of variety within the range of optical and audible elements available and a comprehensive array of accessories make it easy to find the right Signal Tower combination for every application.
By means of Chip-On-Board technology a revolutionary and futuristic LED application has been employed in KombiSIGN 71. LED chips with a remarkably high visibility of 180 are bonded directly onto a gold-plated circuit board. This LED technology comes in the form of an LED Bulb 956 with BA 15d Socket, which is inserted into permanent light elements or as an LED permanent light element with integrated LED-COB. The LED elements have a life duration of up to 100.000 hours and a protective switch ensures current limitation and guards against surge voltage.
|
|
Bright flashing lights and loud alarms capture attention in busy industrial environments. Mounted on a control panel or machine, GE Light Tower signals a potential problem or required action before.
GE Light Tower offers a wide variety of visual options, AC and DC versions, global approvals (UL, CSA, CE) and flexible mounting options, for effective use in almost every situation. Suitable for NEMA Type 1, 3R, and 12 applications, Light Towers go where you need them - indoors or out, in commercial or harsh industrial environments.
Features and Benefits
Three different diameters - 45mm, 56mm, 85mm.
Steady lights can easily be change to flashing by adjusting a simple jumper (56mm and 85mm only).
New lens design produces 360B of bright, shadow-free, colored light for maximum visibility from a distance.
|
|
modulSIGNAL70
# modularly designed, versatile, flexible and powerful signal towers
# any desired combination possible for many different kind of applications
# complete range of visual and audible modules in all
conventional voltages
# extensive mounting options
# 6 lens colours
# PLC fit (leakage/inrush current)
# UL certified, Protection class IP 65, UL type 4, 4X, 13
# modulary construction with bayonet locking system
# fast and easy to operate, mount, configurate and change of modules
# troublefree and fingersafe bulb change at any position
without using any tools
NOTE: Light sources have to be ordered separately (except xenon tubes and fixed LEDs)!
|
|
modulSIGNAL50
# modularly designed, versatile, flexible and powerful
signal towers for smaller machines
# any desired combination possible for many different kind of applications
# complete range of visual and audible modules in all
conventional voltages
# extensive mounting options
# 6 lens colours
# PLC fit (leakage/inrush current)
# UL certified, Protection class IP 65, UL type 4, 4X, 13
# modulary construction with bayonet locking system
# fast and easy to operate, mount, configurate and change of modules
# troublefree and fingersafe bulb change at any position
without using any tools
NOTE: Light sources have to be ordered separate
|
|
The Edwards Triliptical Stackable Status Indicator is a unique audible-visual signaling device that can contain up to 5 light modules and a pulsating horn in a single stack. All modules are gasketed.
The Triliptical Stackable Status Indicator bases are available in three models. A shorter base for conduit or surface mounting or a larger base designed for use with an optional tone module assembly. The larger base is also available with an optional DeviceNet
|
|
|
|
|
|
Luminous columns and sound OPTASON: AE&T proposes to you the luminous and sound columns O270 presenting of many advantages:
- Facilitated Extrme of assembly
- Many choices of luminous modules: incandescence, Led, Flash
- Many choices of luminous effects: fix, flickering, turning
- Varied sound Modules: its fixed, its alternated, buzzer
- Accessories of fixing (squares, feet, etc)
You can thus create your own column meeting your specific needs by assembling to 7 different modules parmis the sound and luminous range suggested.
Very resistant (IP54 and 64), this range is also economic and weak consumer of energy.
Range of the luminous modules:
O270I: fixed light with incandescence
O270LF: fixed light with bulb with Led
O270LFC: fixed light or indicator with Led
0270F: fire flash Xenon
0270L: fire led multifunction (fixes, flickering or rotary) or mutlicouleurs (green orange red)
Range of the sound modules:
O270S85: its continuous or intermittant of 85dB with 1m
O270S90: 16 sounds different of 90dB with 1m (according to sound)
O270S95: its continuous or intermittant of 100dB with 1m
O270S85S: its continuous or intermittant of 85dB with 1m AND FIXED LIGHT
|
|
| ... products without technical information |
| |
|
|
|
|
Get the attention you need with LKEH series signal tower with voice message/audible alarm hybrid unit.
* Available in voice message type (LKEH-FV) and 32 pre-recorded sounds type (LKEH-FA/FC/FD/FE)
* Size: 100mm diameter
* Available in 24V DC, 100V AC and 220V AC versions
* Volume is adjustable from 0 to 105dB at 1 meter
* Continuous or flashing light
* Colors available: red, amber, green, blue and clear/white
* LED modules are interchangeable and stackable after purchase (up to 4 modules)
* Units are shipped completely pre-wired and pre-assembled
LKEH-FV (Voice synthesizer)
* Voice message or sound data is field-programmable with SD card (SD card is sold separately)
* Total recording time of 64 seconds (64kbit/s) can be divided up to 5
channels by bit input or 31 channels by binary input
LKEH-FA/FC/FD/FE (32 pre-recorded sounds)
* 32 sounds are pre-recorded in one unit. 4 sound types are available
* Select one sound group to play back 8 sounds by bit input or 32 sounds can be played back by binary input
Available by Special Order
* PNP open collector transistor type
|
|
|
|
see the results for the following category :
