GENERALITIES
The three and four pole change-over switches, with Motorized operation,
allow remote control of change- Over/breaking/disconnection under
load of power circuits in low voltage systems.
COMPOSITION OF THE RANGE
The range of motorized change-over switches is made by 14 sizes of
switches of current rating from 160 A to 3150A, 3 and 4 poles are
available in the COVISYS-S series with switch laid one upon the other
and in the COVISYS-H series with switch horizontally interlocked.
The COVISYS-S series is made by 3 families:
MO, MOX, MOY, differentiated between them mainly by the supply
voltage and by the display of the position of the change-over switch.
The COVISYS-H series (horizontal) is made in the MO version only.
|
|
|
|
|
|
As a worldwide leading company in changeover solutions Socomec launches a new generation of changeover switches.
Application:
Network / Generator Set
- Generator set control
- ATS solution
Network / Network
- Building services
- Control with or without priority
Originality and advantages:
- ATyS M is a modular changeover system with fully integrated internal security and mechanical and electrical interlocking.
- This innovative concept patented by Socomec combines the benefits of switching technology and fast operation with unique control flexibility.
- The integrated “Manual Security” function is operated via a standard Allen key.
- A complete range of standard accessories is available: bridging bars, voltage sensing kits, positions I-0-II auxiliary contact, terminal shrouds, etc.
Features:
ATyS M: product family for electrical changeover applications from 63 to 160 A.
ATys: from 125 to 3200 A
ATyS M products are available for remote (ATyS M 3s or ATys 3s) or automatic (AtyS M 6 or ATys 6) control and can be used for all types of changeover applications between 2 networks or between a network and a generator set.
|
|
|
|
|
|
GE Zenith Transfer Switches are used to provide a continuous source of power for lighting and other critical loads by automatically transferring from source 1 power to source 2 power in the event that source 1 falls outside preset limits. Voltage sensing and system control is performed via a state-of-the-art microcontroller located on the cabinet door. GE's ATS microprocessor family is designed for highly accurate control of the transfer switch system
MX150 - Standard Applications:
With powerful integrated features,the MX150 microprocessor controller offers pre-engineered programmability, simple field interface, high reliability and ease of preconfigured operation.
MX250 - Specified Engineered Applications:
With powerful integrated features,the MX250 microprocessor controller offers expanded programmability, field adaptability, high reliability and ease for unattended operation.
MX350 - Mission Critical Applications
The MX350 Transfer Switch Graphical Operator Interface includes a ¼ VGA, color graphical display. Making the MX350 an intuitive and easy-to-operate ATS controllers. MX350 is built on the GE Multilin proven UR relay and EPM metering platforms.
|
|
In projecting AT205 automatic panel, Tecnoelettra srl has been involved in realizing an highly industrialized product.
Design has been minded in every detail. New materials for the frontal injection pressing have been used. Sturdiness has been kept by the metal bottom and a remarkable new logic for control has been created. This new electronic card has remarkable potentialities which are linked to an exceptional easiness in utilization.
|
|
GE Zenith Controls ZTS Series Automatic Transfer Switches are the preferred standard for quality and reliability in the electrical industry. The ZTS-MV Series Medium Voltage Automatic Transfer Switch provides that same quality for installations from 5kV to 15kV.
Designed for use in the most critical applications, including hospitals, military sites, airports, communications facilities and computer installations, ZTS-MV Series switches fit the need for dependable continuity of power where emergency or standby applications exist.
|
|
The GE Zenith Controls ZTS Series of transfer switches—the building block of our transfer switch product line—has become a hallmark of quality and performance. This ruggedly built power contactor family of switches is available in open construction for switchboard installation or NEMA enclosed to your specifications. They are specifically designed with dependability, versatility and user friendliness as top priorities.
The power panel components, which include power switching contacts, drive mechanism and terminal lugs, are mounted on a specially formed panel for optimum performance. Logic devices such as microprocessor control, auxiliary time delays and special accessory equipment are mounted on the door for ease of maintenance and to keep them separated from the power section. They are connected with a numbered wiring harness equipped with a disconnect plug that allows the control panel to be isolated for maintenance.
|
|
|
|
|
|
The GE Zenith Controls ZTX Series of transfer switches is built for residential and light commercial critical/non-life safety applications requiring the dependability and ease of operation found in a power contactor switch. The ZTX transfer switches are designed for standby applications, and incorporate a double-throw, mechanically interlocked contactor mechanism.
The ZTX transfer switches are equipped with the MX60 Control Panel.This microprocessor includes:
Undervoltage sensing (90% pickup/80% dropout) of the utility source
Voltage and frequency sensing of the generator source (90% voltage/95% frequency pickup)
Time Delay Engine Start - 5 seconds (P)
Time Delay Engine Warmup - Transfer to Generator - 20 seconds (W)
Time Delay Utility Stabilization/Retransfer to Utility - 5 minutes (T)
Time Delay Engine Cool Down - 5 minutes (U)
Indicating LEDs for power availability, switch position and load energized
Pushbuttons for test, engine start (manual), generator exerciser, timer bypass and program cancel
Special status annunciation of in-phase transfer and timer operation
Selectable 7, 14, 21 or 28 day (factory set 28 days) generator exerciser timer
Diagnostic LED indications in logical one-line configuration
All time delays are fixed.
The unit is available in open type, NEMA 1 or NEMA 3R enclosures. Additional options include:
A3/A4 Auxiliary contacts (1 each) closed in utility and generator positions
Integrated battery charger 1.5A/12V
Special timer settings
|
|
The GE Zenith ZTE series of transfer switches (ATS) go beyond just source switching. Integral metering and communications, high level diagnostics and unsurpassed flexibility make the ZTE Series ATS a perfect solution for
today’s critical source switching. 40-4000Amps, 2-4 Pole, standard and
bypass isolation construction. Proven solenoid operated mechanism. GE-engineered and manufactured contacts and arc quenching components. Standard/open two position transition plus delayed and closed transition. UL/IEC 3-cycle (unconditional). ¼ VGA color display with built-in Help menus. System status LEDs and menu-driven soft keys. Dedicated control and navigational pushbuttons. Front accessible USB programming port. Password protected control switches.
|
|
|
GE Zenith ZTSSL Series Transfer Switches combine traditional switching of the utility supply to a backup generator source with the capability for soft load transfers between the sources and continuous paralleling of the generator set to the utility supply.The ZTSSL transfers power using proven GE Zenith Closed-Transition Transfer Switches (ZTSCT).
|
|
Safe, dependable protection for critical facilities
- 30 to 4000 amps, in standard-, programmed- and closed-transition configurations
- Simple, integrated communication interface using Ethernet or LAN line
- Service-entrance, non-automatic, automatic and bypass configurations
- UL 1008 Listed CSA Certified
Bridging the utility with standby power is no small job, which is why KOHLER® transfer switches are indispensable to the all-KOHLER power system. The MPAC(TM) 1500 - Kohler's new generation of transfer switches - is loaded with sophisticated technologies and advanced design features that ensure transfer of power to critical-load applications. When power fails, power is transferred from the standby system within one-sixth of a second. And you continue functioning as normal.
|
|
|
|
|
|
The AC power supply from shore, generator or inverter has to be perfectly managed for safety and to ensure your valuable equipment remains undamaged.
Mastervolt gives you the option to switch automatically between available power sources. The Masterswitch will connect the output to the highest priority input, if available. Combinating power sources becomes possible for high power consumption situations, such as when you want to do the laundry and cook at the same time with a limited shore or generator power supply.
This lightweight (1.2 kg) Masterswitch, with two inputs and one output, functions as junction in your 230V on board system. The Masterswitch offers the comfort and safety you need. The simple and effective solution!
- Selectable time delay for generator stability
- Two inputs (230V): inverter, shore power or generator
- Single outlet to the 230V power group
- Fully automatic or manual switching
- Power transfer up to 5 kW
- Can be combined with circuit breakers
- Discreet installation enclosure
|
|
|
The Piller Apotrans takes care of critical loads by automatically and transparently providing an alternative power source whenever the preferred power source becomes deficient. This changeover, occurring within a few milliseconds assures that the load is always fed by the optimum power supply. With Apotrans, redundancy is engineered into the power system infrastructure, giving steadfast confidence in the performance of critical operations. Apotrans provides optimum power to secure the load for continuous operation. Every time the preferred power source fails or its voltage no longer meets specified quality requirements, APOTRANS intelligently switches to the alternate source. APOTRANS automatically or manually returns the load to the preferred source once it is sensed to be stable.
|
|
