- Temperature, Temperature/RH/Dew Point, Voltage and Current Models
Windows Software Included
- Datalogger Plugs Directly into Computer 's USB Port for Easy Setup and Data Download (No USB Cable Required)
- User-Programmable Alarm Thresholds with LED Indicators
- Bright Red,Green and Orange LED Indication
- Low Battery Warning
- IP67 Protection
The OM-EL-USB Series of data loggers includes models for temperature, temperature/relative humidity, voltage, and current measurement. The user can easily set up the data logger and download the stored data by plugging the module into a PC's USB port and running the easy-to-use Windows software. Software-selectable setup parameters include logging rate, start-time, high/low alarm settings, and temperature units (°C or °F). Data can then be graphed, printed, and exported to other applications such as Excel. Each data logger is supplied complete with a long-life lithium battery. Built-in LED indicators show data logger status. OM-EL-USB Series data loggers are protected against moisture to IP67 standards when the protective cap is fitted.
|
|
EL-USB-RT
- -20 to +70°C (-4 to +158°F) Measurement Range
- 0 to 100%RH Measurement Range
- Dew point indication via Windows Control Software
- USB Interface
- User-Programmable Alarm Thresholds for T & RH%
When plugged into the USB port of a PC installed with the purpose designed software under Windows XP and Vista(32-bit only), EL-USB-RT measures temperature and relative humidity from -20° to +70°C (-4° to +158°F) and 0 to 100%RH. The PC displays the temperature, humidity and dew point(the temperature at which water vapor present in the air begins to condense) in real-time and saves it to a file which can store up to 7 day's worth of data.
This data file is overwritten at the beginning of each new logging session. The software provides the option for the user to save the data file permanently to the hard-drive. Temperature, relative humidity and dew point can be graphed, printed and exported to other applications.
|
|
|
|
|
|
EL-USB-2-LCD
- LCD display shows high/low and last readings
- Humidity/Temp USB data logger
- Calculated dew point
- Free configuration software
- User-selectable alarm thresholds
This standalone data logger measures and stores up to 16,379 relative humidity and 16,379 temperature readings over 0 to 100%RH and -35 to +80°C (-31 to +176°F) measurement ranges. The user can easily set up the logger and view downloaded data by plugging the module into a PC's USB port and using the supplied software. Relative humidity, temperature and dew point (the temperature at which water vapour present in the air begins to condense) data can then be graphed, printed and exported to other applications.
The high contrast LCD can show a variety of temperature and humidity information. At the touch of a button, the user can cycle between the current temperature and humidity, along with the maximum and minimum stored values for temperature and humidity.
The data logger is supplied complete with a long-life lithium battery, which can typically allow logging for up to 1 year.
|
|
|
|
|
|
MCC has announced the addition of two battery powered temperature dataloggers to its growing datalogger line. These battery powered dataloggers are offered in two models: the USB-501 for remote temperature logging, and the USB-502 for remote temperature and relative humidity logging. These products are the perfect, cost-effective solution for long or short-term data logging applications. Both the USB-501 and USB-502 log up to 16,382 temperature measurements in the -35 to +80 ºC (-31 to +176 ºF) range. The USB-502 additionally supports up to 16,382 additional relative humidity measurements over the full 0 to 100 percent range. Rates for both dataloggers can be set from 10-second to 12-hour intervals. The loggers plug directly into a standard PC or laptop USB port for setup and data download. The included USB-500 Series Data Logging Application software supports both products. This user-friendly, intuitive software is used initially to configure the loggers, program alarm thresholds, logging rates, start times, and measurement units. When the loggers are retrieved from the field, the software provides simple one-click access to download, display, and export the data.
With the included USB-500 Data Logging Application software, the user can display time-stamped temperature, relative humidity, dew point, and alarm limits on a powerful strip chart graph. The data can also be downloaded to a text or a .csv (comma separator values) file. Supporting these file types allows users to easily export the logged data to Excel. With one mouse click, spreadsheets and reports are easily generated. The software and USB-500 series dataloggers are compatible with Windows 2000/XP.
|
|
The key tool for temperature monitoring
TomKEY : the USB key that displays and records temperature
> Integrated USB port, no adapter needed
> Free software
> Calibration certificate included (traceable to international standards)
> High accuracy 0.3°C
> Dust and waterproof IP 67
> Direct Min/Max and alarm readings (no computer needed)
> Measuring range from -40 to +80 °C
|
|
|
|
|
|
The independent PDF Logger® revolutionizes cold chain monitoring
With the LIBERO PDF Logger®, you require only one single device and no specific software to monitor temperature during the global transfer of goods to respective destinations. The LIBERO can be plugged into the USB interface of any PC to automatically generate a PDF file which can be read anywhere without difficulty. The ELPRO LIBERO is the first PDF datalogger in the world which complies with the ISO Standard 19005-1-Document Management.
Specifications
Temperature logging from -35°C to +70°C with internal sensor
Multiple use on 400 operating days within 3 years (switch on/off possible)
16,000 temperature data points
Accuracy of measurement: +/- 0.2° (-10°C to 25°), -/+ 0.5° (from -35° to -10° and 25° to 70°)
Logging modes: start/stop mode, loop mode (Ti1 only)
2 alarm limits or 5 alarm ranges
Integrated PDF file generator which automatically creates an evaluation file including a chart
Evaluation report (Adobe® PDF/A) with text and graph visualizing the temperature curve and the raw data for all transport sections
Whitepaper PDF/A
Possible applications
Pharmaceutical industry
Transport of medication, vaccines, units of stored blood, ampullae, ointments as well as active pharmaceutical ingredients and basic elements
Clinical trials (medication tests and launches)
Shipments to uncommon delivery destinations with decent infrastructure
Biotech
Transport of temperature-sensitive products
Food industry
Transport of perishable foodstuffs (fresh, refrigerated and frozen products)
Transport of flowers and other temperature-sensitive products
|
|
This data logger measures and stores over 32,000 temperature readings from either a K, J or T type thermocouple . A thermocouple is attached via the thermocouple socket at the base of the unit. The user can easily set up the thermocouple type, logging rate, start-time, logging mode, and download the stored data by plugging the module straight into a PC's USB port and running the purpose designed software under Windows 2000, XP or Vista(32-bit only). Data can then be graphed, printed and exported to other applications.
Each EL-USB-TC data logger is supplied complete with a basic K-type thermocouple (for 0 to 400ºC measurement), long-life lithium battery, which will last for approximately 6 months.
This is a popular part, normally stocked in high quantity and suitable for new designs.
|
|
|
|
|
|
RogaDAQ 16 datalogger Description:
With the introduction of the RogaDAQ16 USB2.0 data acquisition system, a new age of measurement technology begins.
USB 2.0 / 480MBIT (USB1.1/12MBIT COMPATIBLE)
16 analog input channels (16bit/500kHz max.)
IEPE sensor supply (24V/4mA)
0.125V to 10V input range
Individual preamplifiers
4 analog output channels (16bit/100kHz)
Powerful DSP (255MIPS) for filtering, control etc.
24 digital I/Os
Optional 24bit counter, timer, PWM, incremental encoder
Free drivers for major application software
including DASYLab; LabView & DiaDem drivers & RogaRec Software; FlexPro7 Standard
The RogaDAQ16 is an affordable multichannel IEPE solution. The USB 2.0 interface permits unrivalled portability. Hotplugging the data acquisition unit during operation has now become a reality. The compact and rugged measurement unit with its BNC connectors breakout boxes obsolete. Downward compatibility to USB 1.1 also permits to run this high performance measuring system with older hardware. Simplicity of integration, whether mobile or stationary, has reached a new level.
|
|
|
2 channel USB sound card with IEPE sensor supply. It can be used for noise and vibration measurement.
|
|
|
|
|
|
RogaDAQ 16 datalogger Description:
With the introduction of the RogaDAQ16 USB2.0 data acquisition system, a new age of measurement technology begins.
USB 2.0 / 480MBIT (USB1.1/12MBIT COMPATIBLE)
16 analog input channels (16bit/500kHz max.)
IEPE sensor supply (24V/4mA)
0.125V to 10V input range
Individual preamplifiers
4 analog output channels (16bit/100kHz)
Powerful DSP (255MIPS) for filtering, control etc.
24 digital I/Os
Optional 24bit counter, timer, PWM, incremental encoder
Free drivers for major application software
including DASYLab; LabView & DiaDem drivers & RogaRec Software; FlexPro7 Standard
The RogaDAQ16 is an affordable multichannel IEPE solution. The USB 2.0 interface permits unrivalled portability. Hotplugging the data acquisition unit during operation has now become a reality. The compact and rugged measurement unit with its BNC connectors breakout boxes obsolete. Downward compatibility to USB 1.1 also permits to run this high performance measuring system with older hardware. Simplicity of integration, whether mobile or stationary, has reached a new level.
|
|
|
2 channel USB sound card with IEPE sensor supply. It can be used for noise and vibration measurement.
|
|
DEWE-43-V packs incredible punch
The all-new DEWE-43-V is taking the data acquisition world by storm. Find out just how great this powerful and yet highly affordable system really is!
-8 universal inputs with 200 kS/s/ch max sample rate
-Simultaneous sampling and 24-bit resolution
-8 synchronous counter/encoder inputs / 24 digital TTL inputs
-2 high speed CAN bus interfaces
-Powered from 6-36 VDC
-Connects to your PC via USB 2.0 (locking connector on the DEWE-43!)
-Includes DEWESoft-SE acquisition/replay software
|
|
The multifunction USB Data Acquisition Systems from Intelligent Instrumentation provide 16 analog inputs with up to 100 kHz sampling rate, 2 analog outputs and 16 digital channels. They are powered through the USB cable, which makes them ideal for mobile applications with notebook computers.
Connection to field signals are either made with a 50pin connector or built-in screw terminal blocks.
|
|
|
|
|
|
The DT9818 is perfect for embedding in a custom application where isolation is required. The DT9818 is a high-performance USB data acquisition module that combines the functionality of multiple boards by providing simultaneous analog input and output, digital I/O, and counter/timer operations. Many software choices make application development easy, from ready-to-measure programs that ship with the board to full graphical programming with our Measure Foundry application builder.
Key Features:
150 kHz throughput on both the A/D and D/A with 16-bit resolution
Up to 32 single-ended or 16 differential analog input channels
Two deglitched analog outputs for smooth waveform generation
16 digital input/output lines that can be clocked synchronously with one bank of eight digital input lines that also support interrupt-on-change
Two 32-bit counter/timer channels that can be clocked synchronously at the analog input rate
500 volt galvanic isolation prevents ground loops, maximizes analog signal integrity, and protects your computer
Runs on USB power... no external power required
Flexible clocking and triggering
Flexible acquisition modes for input operations, and flexible output modes for output operations
BNC case available as an option
|
|
|
|
|
|
The DT9832 is a family of high speed, high performance USB Data Acquisition Modules that provide simultaneous analog input operation at up to 2.0 MHz per channel. Each analog input has its own A/D converter to eliminate phase shift between channels and to allow you to correlate measurements at the exact same instant in time. Additionally, all functions of the module (A/D, D/A, DIO, C/T, Q/D) can be triggered simultaneously and the data streamed synchronously to host memory. These USB DAQ modules also feature 3 quadrature decoders for measuring absolute and relative position and for detecting rotational speed.
Key Features:
* Simultaneous A/D operation with sampling rates up to 2.0 MHz per channel
* All subsystems operate synchronously at 48 MHz.
* 2 or 4 analog inputs, 2 waveform analog outputs, 16 digital inputs, 16 digital outputs, 2 32-bit counter timers, and 3 quadrature decoders.
* 16-bit deglitched DAC’s run at 500 kS/s per channel for waveform generation.
* 500 V isolation provides low-noise measurements and protects PC.
* Ships with DT-Open Layers device drives, Ready-to- measure applications, Measure Foundry evaluation, and much more.
|
|
|
|
|
|
Measurement Computing's USB-2416 is a multifunction measurement and control board designed for the USB bus. It is a multiplexed 24-bit measurement system that provides up to 16 differential and up to 32 single-ended analog inputs with a 1 kS/s aggregate throughput. It offers nine software-selectable analog input ranges (±20V, ±10V, ±5V, ±2.5V, ±1.25V, ±0.625V, ±0.312V, ±0.156V, ±0.078V). The analog inputs can be configured as thermocouple inputs (up to 16 differential). In thermocouple mode, the USB-2416 includes built-in cold-junction compensation and open thermocouple detection.
In addition to the analog inputs, the USB-2416 includes eight lines of digital I/O and two 32-bit counters.
The USB-2416 provides 500 VDC isolation between the field wiring and the USB interface.
The PS-5V2AEPS 10-W regulated power supply (included), provides the 5 VDC, 2A power to the USB-2416.
An optional expansion module AI-EXP32 doubles the analog input channels to 32DI/64SE, and adds 16 digital I/O lines.
Product Highlights:
- 500 VDC minimum isolation between field wiring and USB interface
- 32 single-ended/16 differential analog inputs
- 24-bit resolution
- 1 kS/s aggregate throughput
- Configurable for voltage or thermocouples
- Two 32-bit counters
- An optional expansion module AI-EXP32 doubles the analog input channels to 32DI/64SE.
- 9 programmable input ranges from ±0.078 V to ±20 V
- 8 digital I/O lines
|
|
Analog I/O
12-bit or less resolution
14 and 16 bit resolution
Temperature
Analog Output
High-drive Voltage
Voltage/Current
Voltage
Digital I/O
High Voltage
Parallel
Counter-Timer
|
|
|
|
|
|
The USB-3101FS is a 4-channel, 100 kS/s simultaneously updating analog output module. The USB-3101FS also features ±30 V overvoltage protection, short-circuit protection, low crosstalk, fast slew rate, high relative accuracy, and NIST-traceable calibration. The USB-3101FS module includes a channel-to-earth ground double isolation barrier for safety and noise immunity..
Software included with the USB-3101FS is extensive, including TracerDAQ®, a full-featured, data logging, viewing, and analysis application; Universal Library™, programming libraries and drivers for most popular Windows-based programming languages; Universal Library for LabVIEW™, VIs and program examples for LabVIEW; and InstaCal™ installation, calibration, and test utility.
Product Highlights:
4 simultaneously updated analog outputs, 100 kS/s
16-bit resolution
±10 V analog output range
NIST-traceable calibration
-40 to 70 °C operating range
250 Vrms channel-to-ground isolation protects the module and computer from ground spikes, and ensures a reliable data stream
An on-board LED indicates the status of the device
Field connections are made to a 10-position screw-terminal block
Power for the USB-3101FS modules comes from the +5 volt USB supply from your computer. No external power is required
|
|
Personal Daq/3000 Series
1-MHz, 16-Bit USB Multifunction Modules
– Models /3000, /3001, /3005
The new USB 2.0 Personal Daq/3000 series offers high speed, multifunction data acquisition in a low-cost, portable package. The module offers synchronous and concurrent voltage input, temperature input, waveform output, counter input, quadrature encoder input, timer output, and digital I/O.
Key Highlights
• 1-MHz, 16-bit multifunction USB modules
• Synchronous analog input, analog output,
digital I/O, and counter/timer I/O
• 8 differential or 16 single-ended analog inputs (software selectable per channel)
• Thermocouple inputs on any of the 8 differential inputs
• User-expandable up to 64SE/32DE analog inputs including thermocouple measurements
• Up to four 16-bit, 1-MHz analog outputs
• 24 high-speed digital I/O lines
• Four 32-bit counter input channels with quadrature encoder capability
• Low-latency control output capability
(as low as 2 µs latency)
|
|
The DT9841 is a real-time USB Data Acquisition Module with an embedded DSP for high-accuracy sound and vibration testing. It features full data acquisition capability: eight 24-bit analog inputs, two 24-bit analog outputs, 24 lines of digital I/O, and three 32-bit counter timers.
Key Features:
* Delta-Sigma A/D and D/A converters for high-accuracy measurements at up to 800 kS/s (aggregate)
* Real-time control with embedded TMS320C6713, 300 MHz DSP for stand-alone or system operation
* Software programmable DSP
* Two packaging configurations: Sleek Box version for easy connections or board-level version for OEM-embedded applications
* Flexible memory configuration: 128 MB SDRAM and 2 MB Flash for autonomous operation
* Scalable design for connecting up to 8 modules for high-channel count applications
* High-speed host USB 2.0 host interface (480 Mbits/seconds)
* 500 V Isolation for maximizing signal integrity
|
|
|
|
|
|
Measurement Computing today announced the release of three new 1-MHz, 16-bit multifunction USB data acquisition devices, and a cost-saving expansion module for high channel count applications. The USB-1616HS, the USB-1616HS-2, and the USB-1616HS-4 deliver outstanding performance with synchronous analog, digital, and frequency I/O in one compact package. The AI-EXP48 plug-in expansion module coupled with any of the USB-1616HS series modules can quadruple the analog input channel count.
The USB-1616HS series modules have a unique, low-latency control output mode, whereby any input—analog, digital, or counter, can control an output—digital, analog, or timer, based on pre-defined limits, including hysteresis. The outputs are controlled directly from the USB-1616HS series module, and do not require PC intervention. This results in response times that are measured in microseconds instead of milliseconds
The USB-1616HS series offers extensive trigger options, ranging from analog trigger with 1 µs max latency, to multichannel triggering, where any combination of analog, digital, and counter input channels can be combined to initiate the trigger. Other trigger modes include digital pattern, level, edge, inside/outside window, and pre- and post-trigger.
|
|
Sealevel SeaI/O OEM - USB (Modbus RTU) Data Acquisition Boards
SeaI/O USB U-Series OEM boards provide digital and analog I/O through any available USB port. Sealevel is the first to allow a distributed I/O network to be controlled from a traditional point-to-point USB host connection transforming any USB-equipped PC into a powerful controller. Sealevel's SeaMAX software drivers and utilities make installation and operation easy using Windows 2000, XP and Vista operating systems.
|
|
|
|
|
|
MEASURpoint™ is an ultra-accurate instrument that allows any combination of temperature and voltage to be measured with a single software solution. Up to 48 configurable channels allow the ultimate flexibility with voltage, thermocouple, and RTD inputs. MEASURpoint incorporates ISO-Channel™ technology to eliminate any common mode noise and ground loop problem in any environmental conditions.
Key Features:
Dedicated 24-bit, Delta Sigma A/D converter per channel operating in parallel
Configure up to 48 channels in groups of 8 channels per board
ISO-Channel™ protection eliminates noise and ground loops
1000V galvanic isolation channel to channel and to the host computer to protect signal integrity
DC/DC converter per channel maximizes isolation
10Hz throughput rate on each channel simultaneously or 480Hz for 48 channels
Ethernet (LXI Class C compliant) or USB operation
Compact, rugged 2U half rack enclosure (3.5" H x 8.25" W x 8.25" L)
Dedicated CJC (cold junction compensation) for each thermocouple channel
B, E, J, K, N, R, S, and T type thermocouples supported
Dedicated reference current source for each RTD channel
Platinum RTD types supported: Pt100, Pt500, Pt1000
3 software selectable input ranges on voltage boards: ±10V, ±100V, ±400V
Includes ready-to-measure Measurement Application
|
|
|
|
|
|
Precision High Voltage Measurement Instruments VOLTpoint is a family of precision instruments designed for measuring a wide range of voltage inputs; ideally suited for cell-by-cell battery testing where sources range from millivolts to ±400V. Available in both USB and Ethernet (LXI) versions, VOLTpoint can be configured with 8, 16, 24, 32, 40, or 48 input channels. Each VOLTpoint instrument ships with a ready-to-measure application, allowing you to view, graph, and export your data. VOLTpoint uses ISO-Channel™ technology to eliminate connection problems by using galvanic isolation methods to guarantee 1000V isolation between sensor grounds.
VOLTpoint USB Instrument
DT9873: Precision Voltage Measurement Instruments for USB
* Dedicated 24-bit, Delta Sigma A/D converter for each voltage input channel for simultaneous, high-resolution measurements
* ISO-Channel™ – 1000V galvanic isolation channel to channel and to the host computer to protect signal integrity
* Sampling rates up to 10 Hz per channel
* Measurement Instruments Application and programming examples included
|
|
|
|
|
|
TEMPpoint™ is a series of temperature measurement instruments designed for high accuracy and industrial robustness. TEMPpoint utilitzes ISO-Channel™ front end architecture to eliminate common mode noise and ground loops through 1000V channel to channel galvanic isolation. These instruments allow direct thermocouple, RTD, and precision voltage or resistance measurements with a PC. Temperature and voltage values can be viewed, graphed, or exported to Excel, and allow limit checking for control or monitoring of a manufacturing process. USB and Ethernet (LXI) versions are available with 8, 16, 24, 32, 40, or 48 channels
TEMPpoint Ethernet (LXI) Instruments for Thermocouples
DT8871U: Highly Accurate Thermocouple Temperature Measurement Instruments
* 8 to 48 simultaneous differential inputs per instrument
* Connect any thermocouple or voltage directly at the front panel
* Galvanic Isolation Channel-to-Channel ±500V
* TEMPpoint datalogger application, programming examples, and web-based application included
|
|
| ... products without technical information |
| |
Data acquisition products from PXI to multifunction USB data acquisition boards to PCI Analog & Digital I/O boards
The KPCI-1801HC/1802HC multifunction data acquisition boards combine high performance with high channel capacity. They make it simple to gather analog data, read and output digital signals, provide analog stimulus, and much more. Both boards provide 32 differential or 64 single-ended inputs and two analog outputs. The KPCI-1801HC offers software programmable high-gain inputs of 1, 5, 50, and 250, while the KPCI-1802HC features low gain inputs of 1, 2, 4, and 8.
|
|
|
|
