Control valves

... glandless sampling valves open downwards (in the valve), consists of hard chrome plated piston & PTFE seats which ensures 100% shut off & zero contamination of the material. These valves can be used as ...

DN: 15 mm - 200 mm
Pressure: 0 bar - 16 bar
Temperature: -60 °C - 200 °C

... PVDF, PP; UHMW-PE Options - 5mm lining, monitoring and flushing connection, limit switch, stem extension, heating jacket, control ball ...

... Plug valve features a cylindrical or conic disc that controls the flow of the fluid, opening and closing the passageway between the opposite ports. The lever to control the valve ...

Pressure: -1 bar - 10 bar
Temperature: -20 °C - 200 °C

... Hastelloy C22 • PFA Lined Operation • Push down lever until sample is collected. • Valve spring closes. Features • Spring return (Close). • Lever operated or air actuated. • Wafer Type. • Virgin PTFE ...

DN: 25 mm

... Valve 25 of sphere with demultiplier. Thread of 1 “female-female, male-TC female or male-female. ...

DN: 0.5 in
Pressure: 250 bar
Temperature: -20 °C - 80 °C

... This type of valves allows the fast and exact regulation of the flow in a sense. Roquet commercializes regulators of 2 and 3 ways with connections with threaded fittings or plate. ...

... that has clumped together in storage, dust formation, ensuring exact/calibrated quantities etc. Product range ■Flat slide valves ■Chutes ■2-way switches Properties/variants Applications For flowing or pourable bulk materials Configurations ...

DN: 10 mm - 50 mm
Pressure: 10 bar - 16 bar
Flow rate: 51,000 l/h

... Proportional ball valve based on the C 200 Patented ball geometry with proportional characteristic curve (linearised connection of flow quantity and opening angle) Simple automation using electric variable speed actuators Reproducible ...

DN: 0.75 in
Pressure: 250 bar
Temperature: -54 °C - 204 °C

... flow restrictor hydraulic valve. Operation The NV08-P0 allows the orifice to change from fully closed to fully open with counterclockwise adjustment rotation. Feature Adjustment cannot be backed out of valve. ...

DN: 0.5 in - 6 in
Pressure: 10 bar - 160 bar
Temperature: -46 °C - 400 °C

... Metal seated Wafer Ball Valve construction with floating ball for high temperature services. There are three valve models: ● For low pressure services (AP10) ● For high pressure services (AP10HP) ● Ball valve ...

DN: 10 mm
Pressure: 10 bar
Temperature: 65 °C

... Front control valve, inlet and outlet copper tube 10x1mm, for water TECHNICAL FEATURES Media: Water Maximum pressure: 10 bar Maximum temperature: 65° C Fluid identification: EN 13792 Design: DIN 12918-1 Inlet ...

DN: 0.125, 0.25, 0.375, 0.063 in
Pressure: 10,000, 15,000 psi
Temperature: 650, 450, 350, 200 °F

... Materials include high tensile type 316 stainless steel for the valve body and hardened 17-4PH stainless steel lower section stem. Air operators for remote control operation are available for all valves. ...

DN: 100 mm - 400 mm
Temperature: -25 °C - 150 °C

... Butterfly valves suitable for intercepting powdered products - Size DN100 - 150 - 200 - 250 - 300 - 350 - 400 - 2 half-bodies in cast aluminum with double flange: identical upper and lower flange - Possibility of installing the fitting ...

DN: 0.25 in - 2 in
Pressure: 63 bar
Temperature: -20 °C - 200 °C

... AISI-316 · BSPP ISO-5211 mounting pad to mount directly actuators Characteristics •General industry application. •Blow-out proof stem design. •100% tested with air & water (Open/Close). Specifications •Ends: BSPP threaded acc. to DIN-259. ...

... The Model DGV Deluge Valve is designed for use in controlling water flow to deluge, pre-action or foam-water type fire protection sprinkler systems. This valve is UL Listed in Special Systems Water Control ...

DN: 6 mm
Pressure: 700 bar
Temperature: -20 °C - 60 °C

... Our manual valve is designed for reliable use with single or double acting hydraulic systems. If desired, it is available with a lock function for secure load holding. Technical data Mounting face Cetop C DIN 24340-A6 (others ...

... and secondary vessels in mixing plants, wagons, reservoirs under filters and separators, cone worm mixers By means of the lever system, the flap is vertically moved down and swivelled laterally by the side of the discharge opening, ...

DN: 40 mm - 1,200 mm
Pressure: 40, 10, 16, 25 bar

... STANDARDS OF MANUFACTURE Metal seat gate valves EN 1171 (ISO 1083) DUCTILE IRON GATE VALVES EN 1074-2 ISOLATING VALVES EN 558 (ISO 5752) FACE TO FACE EN 1092-2 (ISO 7005-2) DRILLING FLANGES MATERIALS BODY EN ...

DN: 0.25, 0.375, 0.5 in
Pressure: 0 bar - 300 bar
Flow rate: 12, 20, 25 l/min

... The FPSB series engineered by Dicsa, is a flow- control valve, composed of a steel made body and interior. Its exterior surface features a zinc plated construction. Furthermore, this Dicsa flow control ...

Pressure: 10.3 bar
Temperature: 0 °C - 40 °C

... The ISQBF series control valve is an electronic pressure regulator designed to precisely and proportionally control the pressure of gases based on an electronic signal. The ISQBF is an FM approved and ...

DN: 0.25 in - 4 in
Pressure: 1,000, 800, 600 psi
Temperature: -20 °F - 450 °F

... psi W.O.G; 4" 600 psi Temperature range -20° to 450°F End types threaded with Locking device Locking lever handle ...

... Ball Valves Ball Valves with unresticted flow Ball valves or nickel-lated brass with a chomium-plated ball. Seals fo Teflon (PTFE and NBR). Metal lever (alu alloy). Straight-through ...

DN: 15 mm - 900 mm
Pressure: 1,600,000 Pa - 42,000,000 Pa
Temperature: -196 °C - 380 °C

... Ball Valve Body materials: carbon steel, stainless steel, alloy steel WCB, LCB, CF3, CF3M, CF8, CF8M, MONEL, and more. Valve Ball type: floating ball, trunnion mounted ball. Valve Manufacturing standards: ...

Pressure: 500, 700 bar
Flow rate: 60 l/min

... Control valves Pressure valves Flow control valves Stop valves ...

DN: 15 mm - 50 mm
Pressure: 40, 50 bar
Temperature: -20 °C - 160 °C

... Full bore ball valve, F/F, with extended polyamide ISO-T-handle, anticondensation and dripless. ...

DN: 2 in - 12 in
Pressure: 150 psi

... SIZE: 2＂～12＂ JOINT END: FLANGE (ANSI /DIN / JIS/ CNS) WORKING PRESSURE: 150PSI Key words: CPVC pneumatic butterfly valve ...

DN: 15 mm - 800 mm
Pressure: 20 bar - 420 bar
Temperature: -50 °C - 200 °C

... Side Entry Valves suitable for Oil & Gas production, processing, transportation, distribution, chemical and petrochemical refining including system isolation, pressure level and flow measurement, instrument drain, chemical injection ...

... precision formed tapered seat. For replacement Viton® O-ring Kit, see R110112.0-12mm high vacuum valve(T-Type) Accessories: S540012 0-12mm high vacuum plug and control knob Viton® O-ring at tip 42.05 ...

DN: 1.25 in

... unique patented concept for mechanical tapping of plastic pipes. The positioning/ securing of the saddle is easy done by a lever arm system, and a spring loaded compensaton is providing a constant sealing against the pipe Advantages: ...

DN: 40 mm - 300 mm
Pressure: 25, 16, 10 bar
Temperature: 40 °C

... operation The flow– control valve completely hydraulically ensures a pre–determined maximum flow, irrespective of any changes in the operating pressure. The nominal flow rate can be progressively varied up to ±15% ...

DN: 0.25 in
Temperature: -20 °C - 70 °C

... Dependable safety valve to retain a set supply air pressure and guarantee a steady process control when a supply air is suddenly failed by accident and its pressure becomes lower than a set pressure Features - Rugged ...

DN: 15 mm - 25 mm
Pressure: 20 bar
Temperature: -10 °C - 130 °C

... terminal balancing valve with standard test points (Fig. 9525) and optional electric actuator (Vaurien) Additional information Material - DZR Brass Typology - Static balancing Connection - ISO 228/1 DZR brass ON/OFF terminal ...

DN: 15 mm - 50 mm
Pressure: 16 bar - 40 bar
Temperature: -10 °C - 180 °C

... The 21IA4T15GC is a 2-way angle seat air operated valve that is capable of providing high flow rates. Its body has been constructed out of stainless steel and it features a corrosion resistant actuator that can be rotated up to 360 degrees. ...

DN: 15 mm - 400 mm
Pressure: 16 bar - 150 bar
Temperature: -20 °C - 350 °C

... Bellow Sealed Globe Valve Manufacturer: Bellow Seal Globe Valves, 1/2-16 Inch, DN15-DN400, Class 150-900 LB, PN16-PN150, API 602, DIN 3356, BS 5160, ASME B16.34. The Med Bellow Sealed valves have been ...

DN: 15 mm - 125 mm

... Flanges drilled acc.to ANSI Possibility of equipment with handlever, manual gear, pneumatic or electric actuator (on request) Control equipment connection according to ISO 5211 On request, possibility of special executions with the ...

DN: 0.25 in - 2.5 in
Pressure: 25 bar - 63 bar
Temperature: -20 °C - 150 °C

... The Siral V2000 is a brass ball valve which features its capacity to make a full flow stream in conveying general steam of water, air, vacuum oils and non-corrosive liquids. It comes with a nominal pressure of PN 25 to PN 63 and a temperature ...

DN: 15 mm - 100 mm
Pressure: 16 bar

... Angle seat pattern globe valve Fig. VS 104 BODY - INOX CF8M 2 - DISC - INOX CF8M 3 - STEM - INOX 316 4 - GLANDPACKING - Graphite-PTFE 5 - GLAND - INOX CF8M 6 - BONNET - INOX CF8M 7 - NUT - BRONZE 8 - HANDWHEEL ...

DN: 15 mm - 300 mm
Pressure: 3 bar - 16 bar
Temperature: -20 °C - 120 °C

... invented the one-piece plastic flanged ball valve in 1992 No metal fittings, PTFE seal, flange connection, wide application range Fewer leakage points, quick opening, and closing. Optional flanged ball valve with lock ...

DN: 0.125 in - 0.5 in
Pressure: 0 bar - 255 bar
Temperature: -29 °C - 250 °C

... Minor series valves are the finest regulation version of our needle valves. They are called Minor since they are of reduced dimensions and precision regulation. Ideal for instrumentation panels and for high-pressure circuits. ...

DN: 50 mm - 500 mm
Pressure: 10, 6 bar
Temperature: 180 °C

... One-piece body, tight-closing, centric disc With blow-out proof shaft Design for mounting between flanges according to DIN EN 1092-1 Face-to-face length according to DIN EN 558-1-R20 Leakage rate A according to DIN EN 12266-1 For all flammable gases ...
