Plug-in current sensors

Primary current: 2 mA - 100 mA

... MD0630STA-PM Introduction The MD0630STA-PM AC DC leakage current sensor (compatible with Type A and Type B) features high sensitivity, accurate measurement, and a compact & integrated design. It outputs an alarm signal when it detects a DC leakage current ...

Primary current: 2 mA - 15 mA

MD0630STA-P earth leakage sensor detect both AC and DC ground faults in a very small, PCB-style form factor. The RCD module is designed for integration directly into inverters. Outputs way is open collector output. With the characteristics of high sensitivity, ...

Primary current: 3 mA - 100 mA

... The trend in PV string inverters for large solar power plants is towards higher power classes. This requires current sensors with a higher current capability. The new MD Series leakage current sensor MD0630T41A was specially developed to fulfill the ...

Primary current: 3 mA - 100 mA

AC/DC sensitive residual current detection device model MD0630T01A is a specialized leakage current sensor designed for electric vehicle (EV) charging stations. This sensor is engineered to ensure the safety and reliability of the EV charging process. ...

Primary current: 3 mA - 100 mA

MD0630T01A-2 is an automotive grade ultra-small leakage current sensor designed for portable charger also called residual current monitoring (RCM), residual current detection (RCD), differential current sensor, earth leakage detector and differential ...

Primary current: 3 mA - 100 mA

MD0630T01A-Z is a new, compact, horizontal type pin mount rcd sensor with pins designed for use in e-mobility infrastructure and AC charging station designs to monitor leakage currents in mode two/three/four electric vehicle charging. The RCD sensor is ...

Primary current: 2 mA - 15 mA

MD36DA-C is a high sensitivity and cost-effective dc leakage current sensor also colled residual direct current monitoring module, residual direct current monitoring device(RDC-MD), residual direct current detecting device(RDC-DD), residual direct current ...

Primary current: 10 A

... The measurement accuracy will be 0.02 class and 0.01 class .It has high stability zero and temperature drift. It has Stable Performance During Temperature Rise and widely Used in 0.2S Energy Meter. Product Parameter ●High Accuracy to Class 0.01/0.02 ●Coil ...

Primary current: 600 A

... 600 A/333 mV Ø60 mm 12 Vdc converter Rogowski loop Rogowski loops are a new generation of flexible current transformers that allow users to easily pass the product around the cable or bar, even in confined spaces. Rogowski loops are particularly ...

Primary current: 1,500 A

... 1500 A/333 mV Ø160 mm 12 Vdc converter Rogowski loop Rogowski loops are a new generation of flexible current transformers that allow users to easily pass the product around the cable or bar, even in confined spaces. Rogowski loops are particularly ...

Primary current: 2,500 A

... 2500 A/333 mV Ø160 mm 12 Vdc converter Rogowski loop Rogowski loops are a new generation of flexible current transformers that allow users to easily pass the product around the cable or bar, even in confined spaces. Rogowski loops are particularly ...

Primary current: 4,000 A

... 4000 A/333 mV Ø180 mm 12 Vdc converter Rogowski loop Rogowski loops are a new generation of flexible current transformers that allow users to easily pass the product around the cable or bar, even in confined spaces. Rogowski loops are particularly ...

Primary current: 75 A - 1,000 A

SCY15C Series open loop current sensor is develop on basis of Hall effect. It is especially designed for the electronic measurement of DC, AC or pulsed currents in high power and low voltage automotive applications with galvanic isolation between the ...

Primary current: 10 mA - 100 mA

... SCD10 series DC leakage current sensor, using the principle of magnetic modulation closed-loop, for isolated measurement of DC milliampere small current. Main feature: The isolation voltage between primary and secondary is greater than 3000VAC. Temperature ...

Primary current: 20 mA

... SCD1-20mA is one typical model of SCD1 Series DC Leakage Current Sensor. This current sensor develop on base of magnetic modulation closed loop principle, apply unique patented technology for measure tiny current (mA level from 0ma to 20ma). Main ...

Primary current: 100 A - 500 A

... SCK3A Series are the family product of SCK3 series. - SCK3A series are open loop current sensor develops on the basic of open-loop hall effect principle, through hole install, window size 10.5*20.5mm. Primary input current rating from 50 Amps to 600 ...

Primary current: 2,000, 200 A

... SCY7 Series suit for larger primary input current measure. Primary input current range 200A..2000A, primary aperature size ø40mm. Main features: 1. SCY7 Series Hall Current Sensor is a new generation Open loop Split core current sensor based on Hall ...

Primary current: 400 A

... SCK3M-400A is one of the typical model of SCK3M Series, which are a open loop current sensor develops on the basic of open-loop hall effect principle, through hole install(panel installation), window size 10.5*20.5mm. Primary input current rating 400Amps. Characteristics. •Open-loop ...

Primary current: 100 A

SCY6-100A is the typical model of SCY6 Series, which is a split core current transducer develops on hall-effect, primary current through hole size: 20mm. Non-contact measurement of current from 100Amps to 500Amps. Built in 2 open-able parts, give a flexible ...

Primary current: 750 A

... SCY13C-750A SCY13C-750A is a electric open-loop current sensor develops on hall effect principle. There is galvanic isolation between primary and secondary circuit provides accurate electronic measurement of DC, AC or pulse currents. Bipolar power supply ...
