cast iron tombstone / double-sided
cast iron tombstone
Doppelwinkel Aufspanntürme

... accuracy, no additional surface grinding of tombstone necessary Standard tombstones for pallet sizes 400 mm and 500 mm Suitable for all common machining plates 400 x 400 mm and 500 x 500 mm All tombstones ...

cast iron tombstone
cast iron tombstone
Aufspanntürme mit Spannmittel

... accuracy, no additional surface grinding of tombstone necessary Standard tombstones for pallet sizes 400 mm and 500 mm Suitable for all common machining plates 400 x 400 mm and 500 x 500 mm All tombstones ...

cast mineral tombstone
cast mineral tombstone

Material: Mineral cast is a two-component system comprising mineral fillers and an epoxy resin as the binding agent. It is cold-cast using precision negative moulds at room temperature and subsequently hardened. The KIPP block clamping ...

modular tombstone
modular tombstone
5RS series

Flanged Style Risers Jergens Workholding Solutions presents a truly modular approach to 5-Axis machining. Fixture-Pro® 5-Axis Risers raise,position and locate the part off the machine or rotary table so the part is accessible for machining ...

tombstone
tombstone
C160

Pneumatic clamping tombstone Technical data - Actuation: compressed air filtered (10µm) and lubrified - Operating pressure range: from 0.3 to 0.9 MPa - Operating temperature range: from 5°C to 60° C - Installation ...

tombstone
tombstone
01850

Norelem has manufactured the 01850 four face angle plates equipped with lifting eye-bolts suitable for transportation. A cover prevents the hollow spaces in the angle plates from filling with chips. These devices are sized to pallets ...

modular tombstone / cast iron
modular tombstone

... overall material and base finished -Completely finished with tolerance of ± 0,02 mm -Grid tombstone with calibrated holes and solid threads -Grid tombstone with hardened bushings 100 Cr6 and inox steel helicoils

modular tombstone
modular tombstone
TS series

arrangement of clamping points 4 x 90° clamping against the central fixed jaw mechanically operated sizes 100•125•125 mm

tombstone
tombstone
47220, 47520

Ideal for manual 5-face machining of workpieces by turning workholding device with clamped workpiece 4x 90 degrees using a 3-axis machine tool. Absolutely stable and sturdy, case-hardened steel body, grinded rectangular to 0.01 mm.

tombstone
tombstone
0-MAK 20 4x90º

... connections for a quick pneumatic switch. Designed with holes and k-slots for an easy assembly on the machine. Plates and tombstones can be designed as per customers requirements on demand.

tombstone
tombstone
890 030 series

One-piece structure to support four vices placed at 90 degrees The jaws are fastened and aligned on the central hub With special drain for coolant and chip evacuation Material: Ductile iron for stability in time and for absorbing vibration ...

tombstone
tombstone
890 034 series

One-piece structure to support four vices placed at 90 degrees The jaws are fastened and aligned on the central hub With special drain for coolant and chip evacuation Material: Ductile iron for stability in time and for absorbing vibration ...

tombstone
tombstone
6373V, 6373A

The V, A Series of Tombstone, manufactured by AMF ANDREAS MAIER, is specifically designed with base surface fine-milled. Its clamping surface only faces the pre-milled. This device is also used for a specific customer applications.

tombstone
tombstone
6374V, 6374A

Design V: base surface fine-milled. Clamping surface faces pre-milled only, extra tol. for customers finishing. Features: Material: GG25 Alignment hole and centre hole: with hardened bushes in accordance with DIN 179 Base surface : ...

tombstone
tombstone
6364A series

Features: Parallelism: 0.01/200 mm Clamping surface faces: smoothed Hardness: unhardened Material: case-hardened steel Alignment hole and centre hole: with hardened bushes in accordance with DIN 179 with base surface Base surface : with ...

cast mineral tombstone / cast iron
cast mineral tombstone
AMROK®

AMROK Tombstones and Grid Plates are designed to hold the industry's tightest tolerances for flatness, parallelism, perpendicularity, surface finish, and hole location. All Tombstones and grid plates ...

modular tombstone / cast mineral
modular tombstone
tripoxy series

Triag tombstones are made of epoxy mineral casting making them lighter than aluminum in specific weight. This material greatly reduces vibration, guaranteeing high accuracy in your machining, even when using the upper ...

cast iron tombstone / double-sided
cast iron tombstone

The clamping column, clamping blocks and double sided clamping column are made out of cast iron and are extremely stable, warp resistant and vibration reducing. In addition to this, there are base plates in different sizes in the delivery ...

indexing work-holding tombstone / cast iron
indexing work-holding tombstone
BJ070-00 series

The body is made from FC300 cast iron - annealed and semi-finish machined.

See the other products
Fixtureworks
indexing work-holding tombstone / cast iron
indexing work-holding tombstone
BJ070 series

The body is made from FC300 cast iron annealed and precision machined. The alignment bushings are made from SUJ2 steel. The thread inserts are made from S45C steel and heat treated. MTP hole spacing is 50mm +/-0.02. Includes protection ...

See the other products
Fixtureworks
double-sided tombstone / cast iron
double-sided tombstone
CP6 series

The body is made from FC300 cast iron – annealed and precision machined. Each face is machined with 0.5mm deep finishing allowance for extra face finish to your specifications. Eye bolts included. Custom configurations are available.

See the other products
Fixtureworks
cast iron tombstone / modular
cast iron tombstone
T series

The tooling block concepts offered by OK-VISE Oy provide the state-of-the-art features that support effective and efficient fixturing enabling higher productivity of the CNC system.

cast iron tombstone / modular
cast iron tombstone
CL-500300600-FTBM-50

Four-Sided Tooling Blocks – Modular, Heavy 5/8" (500mm) Modular Fixturing New item! Precision tooling block for horizontal machining centers, incorporating our Heavy (5/8-11) modular system. One-piece cast iron construction provides ...

cast mineral tombstone
cast mineral tombstone
ROC®

ROC® mineral cast media has low thermal conductivity and excellent resistance to corrosion. As the mineral cast component has low tensile and impact strength, unintended impacts to the composite structure will not disturb the steel positioning ...

cast iron tombstone / modular
cast iron tombstone

... of the steel and aluminium tombstones are completed with high precision machines using the highest quality tools available. This assure the highest accuracy possible and outstanding dimensional repeatability. All tombstones ...

modular tombstone
modular tombstone
DUO Plus 125 series

Scope of application: Modular clamping system for horizontal machining centres Product features: Base gives high stability and extreme accuracy for your machining Clamping width adjustment for clamping two workpieces ...

See the other products
ALLMATIC-Jakob Spannsysteme
indexing work-holding tombstone
indexing work-holding tombstone
DST series

The DST series is an indexing work-holding tombstone designed to be mounted on the pallet of NC machining centers. It can perform versatile machining on five surfaces without re-chucking and ten surfaces with the twin ...

tombstone
tombstone

Use: drilling, milling Clamping of several workpieces at the same time Hydraulic clamping

gripper tombstone
gripper tombstone
1C/35J

tombstone
tombstone
Pallet-Master™

Pallet fixtures, also known as tombstones, tombstone fixtures or tooling blocks, provide a solid base for mounting vises, fixtures, or sub-plates. Made from one-piece, class 40 cast iron that has been ...

See the other products
Suburban Tool, Inc
tombstone
tombstone
RWP-019-4X45T

... fixtures are made from 17-4 Stainless Steel. The fixture clamps are made from 17-4 Stainless Steel. This Raptor Nest tombstone mounts to the top of any of the following 1.5" dovetail fixtures: RWP-001, RWP-001SS, ...

double-sided tombstone / cast iron
double-sided tombstone
BP07,BP10,BP20,BP23,BP29,BP31,BP33 series

Material: Cast Iron FC300(JIS) / GG30(DIN) (BPA: High Strength Aluminum Casting ) Heat treated: Normalized Application: Horizontal Machining Center. Features: Ready to accept a hole pattern for your special jig.

See the other products
Leave Industrial
modular tombstone
modular tombstone
400 mm | TC2C40616

... thickness and flexibility to the majority of parallel machining centers. These boxes are about 30% low-weight as compared to the tombstones with aluminium sub-discs that are structured to lower the installation span. ...

See the other products
Kurt Manufacturing-Industrial Products Division

How to choose this product

tombstone

Tombstones, also known as clamping pillars, tooling fixtures or clamping columns, are used to hold workpieces in place on horizontal machining centers. They are combined with machine tool vises for optimal accessibility to the workpiece.

Applications

Tombstones are used specifically for horizontal machining centers. They can clamp multiple workpieces for applications requiring fast production times.

Technologies

Tombstones are made out of cast iron, case-hardened steel or aluminum. They can come with two, three, four or even six faces, depending on the number of workpieces to be mounted. Tombstones can be designed to use either manual vises, hydraulic vises or zero-point clamping cylinders.

How to choose

Most manufacturers provide custom-built tombstones in order to fit the machine and the type of workpiece being machined.
