Tube lifting clamp RBL200

verticalmanualautomatic

General
The Round Bar Lifter RBL200 is a fully automatic, self-locking device designed to grab, lift and move steel bars and tubes. It operates without hydraulic power, slings or chains and enables single-operator handling.

Applications

• Lifting and transferring steel bars, tubes and pipes.
• Handling round stock in workshops, warehouses and steel yards.
• Operations requiring single-operator lifting without additional rigging.

Key features

• Model: RBL200
• Brand: Aardwolf
• Auto-locking latch mechanism
• No hydraulic supply, slings or chains required
• Grip range: 100–200 mm (3.9"–8")
• Working load limit (WLL): 150 kg (331 lb)
• Net weight: 7 kg (15 lb)
• Gross weight: 8 kg (18 lb)
• Packaging dimensions: L.420 x W.190 x H.370 mm (16.5" x 7.5" x 14.6")

Technical specifications

• Operation: Auto-locking latch, manual lift interface
• Application: Designed for steel bars and tubes
• Suitable for single-operator use
