Automatic filling machine ZRO 90T

capsulefor tabletspowder

About the ZRO 90T
The ZRO 90T is a capsule filling machine using patented ZRO (Zero Relative Motion, ZRM) powder-filling technology designed to maximize capsule yield and minimize powder waste. It is intended for high-speed, dust-controlled production of large batches and handles challenging powders that are sticky, fluffy, hygroscopic or heat-sensitive.

Applications

• Filling of powders, pellets, tablets, micro-tablets, capsules, soft gels and combinations of these into hard capsules

Features & Benefits

• Patented ZRO (Zero Relative Motion, ZRM) powder-filling station — achieves high capsule yield with reduced powder wastage and supports difficult-to-handle formulations
• Partial filling capability down to ~25 mg (capsule sizes 000–5) — enables low-dose API filling, including inhalation formulations
• Mechanical changeover in under 1 hour — reduces downtime and supports fast product changeovers
• High-speed, dust-controlled filling up to 90,000 capsules/hr — suitable for large-batch production
• Compatible with multiple product formats — powders, pellets, tablets, micro-tablets, soft gels and combinations
• Optional integration with ACCURA 100% capsule check-weigher — enables in-line weight verification

Key highlights

• Zero Relative Motion (ZRM) patented powder-filling technology
• Dust-free, high-speed filling up to 90,000 capsules/hr
• Partial filling down to ~25 mg for capsule sizes 000–5
• Handles sticky, hygroscopic and heat-sensitive powders and high fines
• Mechanical changeover in under 1 hour
• Adaptable to multiple dosage forms
• Integrable with ACCURA 100% capsule check-weigher

Technical specifications

• Stations: 10
• Capsule sizes: 000–5
• Maximum speed: up to 90,000 capsules/hr
• Partial filling capability: as low as ~25 mg
• Technology: Patented ZRO (Zero Relative Motion / ZRM) powder-filling station
• Suitable for: sticky, fluffy, hygroscopic, heat-sensitive powders and powders with high fines
• Product formats: powders, pellets, tablets, micro-tablets, capsules, soft gels and combinations
• Changeover: simple mechanical changeover in under 1 hour
• Optional integration: ACCURA 100% capsule check-weigher for guaranteed weight verification
