Laboratory gas cylinder ALPHAGAZ™ 1

gasnitrogencylindrical

Summary
High-purity nitrogen gas suitable for laboratory analyses from % range down to ppm levels.

Applications

• Laboratory analysis: carrier gas (GPC), instrument gas (LC-MS), purge and zero gas, protective atmosphere
• Cryogenic fluid (liquid N2)
• Semiconductor industry: purge gas, inerting, cleaning, CVD carrier gas

DETAILED DESCRIPTION
ALPHAGAZ™ 1 Nitrogen (N2) is a high-purity gas from the ALPHAGAZ™ 1 family. With low levels of critical impurities (moisture, oxygen, hydrocarbons, etc.) and high gas purity, ALPHAGAZ™ 1 products meet or exceed the requirements of most analytical instrument manufacturers. It can be used as a versatile laboratory gas. Cylinder sizes are adapted and available on request. Equipped with a SMARTOP valve for easy opening and with a pressure gauge for internal pressure monitoring.

Advantages

• Simplified selection: laboratory gas for analyses from % range to ppm
• Choice of cylinder sizes according to demand (examples: S11, M20, L50, V09)
• Equipped with SMARTOP valve (easy opening and pressure gauge)

Quality

• Guaranteed critical impurity levels
• Certificate of conformity provided
• Traceability ensured by batch number
• Special pre-treatment of cylinders to guarantee long-term purity and stability

Service

• Product held in stock for availability
• Support from quotation to delivery (expertise center)

Properties and features
Product designed for laboratory analyses from % range to ppm; specification of critical impurities (moisture, oxygen, hydrocarbons) to avoid interferences and equipment contamination. Shelf life: 5 years (60 months). Quality ensured via ISO 9001 certification of laboratories.

Safety & Transport
Hazards: at high concentrations may cause asphyxiation. Non-flammable.
Official designation: Compressed gas
UN No.: 1066
ADR class: 2
Classification code: 1A

Specifications (table)
Reference: P0271
Physical state: gaseous
Relative density (gas): 0.97 (air=1)
Relative density (liquid 1 & 2): 0.8 (water=1)
Molecular weight: 28.01 g/mol
Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male) Cylinder thread: 38x2 (S)
CAS No.: 7727-37-9
Single molecule: N2 ≥ 99.999 %
Total purity (Vol. abs): ≥ 99.999 %
Impurities: H2O ≤ 3 ppm
O2 ≤ 2 ppm
CnHm ≤ 0.5 ppm
CO ≤ 1 ppm
CO2 ≤ 1 ppm
Additional information: Recommended for analyses from % range to ppm
Warranty: 60 months
Colour: colourless
Odour: odourless
Shelf life: 60 months

Technical characteristics / specifications

• Reference: P0271
• Physical form: gaseous
• Purity: N2 ≥ 99.999 % (total purity ≥ 99.999 % vol. abs)
• Guaranteed critical impurities: H2O ≤ 3 ppm, O2 ≤ 2 ppm, CnHm ≤ 0.5 ppm, CO ≤ 1 ppm, CO2 ≤ 1 ppm
• Molecular weight: 28.01 g/mol
• CAS No.: 7727-37-9
• Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male); cylinder thread 38x2 (S)
• Colour / Odour: colourless / odourless
• Shelf life / Warranty: 60 months
• Transport: UN No. 1066, ADR class 2, Classification code 1A
