Industrial gas cylinder ALPHAGAZ™ 1

gasoxygenstorage

General description
High-purity oxygen gas suitable for precise analyses from percent to ppm levels. Designed as a certified calibration/standard gas for laboratory analysis, it ensures optimal operation of analytical instruments and reproducible results. Impurity content is kept below the limits required by most analyzer manufacturers.

Applications

• Flame gases (flame ionization detector, FID)
• Instrument gases (carrier gas for analyses, e.g. TOC analysis)
• Drinking water treatment (oxidation processes)

Benefits / Selection

• Laboratory gas for routine analyses in the % to ppm range
• Multiple cylinder sizes and bundles available (e.g. 11, 20, 50 L and 9x50 L bundles) depending on application
• Equipped with SMARTOP valve: easy opening and integrated pressure gauge for internal pressure indication

Quality

• Low impurity levels
• Certificate of conformity provided (product label per cylinder)
• Traceability ensured via batch number
• Long-term stability and gas purity ensured by special cylinder pre-treatment

Service

• Product available for delivery on demand (distributors / networks depending on country)
• Supply chain support from quotation to delivery

Physical-chemical properties
Compressed gas, colorless and odorless, heavier than air and supports combustion. Indicated shelf life: 60 months.

Video
Presentation video of ALPHAGAZ gases available (product overview).

Characteristics / technical specifications

• Reference: P0361L50S2A001
• Commercial name: ALPHAGAZ™ 1 OXYGENE
• Example variation name: ALPHAGAZ 1 OXYGENE SMARTOP bottle 50 L 200 bar
• Pressure: 200 bar
• Packaging type and size: 50 L (examples of available sizes: 11, 20, 50 L; 9x50 L bundles)
• Cap: SMARTOP
• Capacity (50 L): 10.6 m³
• Physical state: gaseous
• Relative density (gas): 1.1 (air = 1)
• Relative density (liquid): 1.1 (water = 1)
• Molecular weight: 32 g/mol
• Valve connection: AFNOR F (22.91 x 1.814 SI - right female); bundle connection: 35x2 (V)
• CAS No.: 7782-44-7
• Composition / purity: O2 ≥ 99.995 mol %; total purity ≥ 99.995 %
• Indicative impurity limits: H2O (5 bar) ≤ 2 ppm; CnHm ≤ 0.5 ppm; CO ≤ 0.5 ppm; CO2 ≤ 0.5 ppm (full details in technical data sheet)
• Additional information: recommended for analyses from % to ppm; warranty/shelf life: 60 months
• Color: colorless
• Odor: odorless
• Environmental notes: cylinders filled and produced using 100% renewable electricity (supplier statement)
