Industrial gas cylinder ALPHAGAZ™ 2

gasoxygencylindrical

Summary
ALPHAGAZ™ 2, the analytical-grade solution for optimal performance
ALPHAGAZ™ 2 OXYGEN recommended for analyses from ppm to ppb

Applications

• Flame gases
• Instrumentation gases

Detailed specifications (excerpt from datasheet)
Reference: P0362L50S2A001
Variation name: ALPHAGAZ™ 2 OXYGEN Cylinder Smartop 50L 200 bar
Pressure: 200 bar
Packaging type and size: 50L
Cap: SMARTOP
Capacity: 10.6 m³
Physical state: gaseous
Relative density (gas): 1.1 (air=1)
Relative density (liquid 1 & 2): 1.1 (water=1) 1.1 (water=1)
Molecular weight: 32 g/mol
Valve connection: AFNOR F (22.91 x 1.814 SI - right female)
CAS No.: 7782-44-7
Single component: O2 ≥ 99.9995%
Total purity (% Vol. abs): ≥ 99.9995%
Impurities (see datasheet for full details): H2O (5 bar) ≤ 0.5 mol-ppm
CO ≤ 0.1 mol-ppm
CO2 ≤ 0.1 mol-ppm
CnHm ≤ 0.1 mol-ppm
H2 ≤ 0.1 mol-ppm
Additional information: Product recommended for analyses from ppm to ppb
Warranty: 60 months
We use 100% renewable electricity to produce and fill cylinder gases.

Safety & Transport (excerpts)
Hazards: Oxidiser, may react violently with combustible materials
Flammability range: non-flammable
Official designation: Compressed gas cylinders
UN No.: 1072
ADR class: 2
Classification code: 1O
ADR pictograms: oxidiser and non-flammable pictograms (see safety data sheet)

Technical features / specifications

• Brand / range: ALPHAGAZ™ 2
• Product: High-purity oxygen (O2 ≥ 99.9995%)
• Product reference (variation): P0362L50S2A001
• Packing: Cylinder Smartop 50L, 200 bar
• Gas capacity (volume): 10.6 m³
• Valve connection: AFNOR F (22.91 x 1.814 SI - right female)
• CAS No.: 7782-44-7
• Guaranteed impurities (examples): H2O ≤ 0.5 mol-ppm; CO, CO2, CnHm, H2 ≤ 0.1 mol-ppm
• Physical state: gaseous
• Colour: colourless
• Odour: odourless
• Storage / Warranty period: 60 months
