Pneumatic-drive pump 2018/913 IC-Dstationaryindustrialtransfer
Add to favorites
Compare this product
Characteristics
- Operation
- pneumatic-drive
- Mobility
- stationary
- Domain
- industrial
- Applications
- transfer, feed, recirculation
- Material
- stainless steel
- Fluid specification
- for low-viscosity fluids, for medium-viscosity products, for high-viscosity fluids
- Flow
45 l/min
(11.88774 us gal/min)- Pressure
Max.: 6 bar
(87.023 psi)Min.: 2 bar
(29.008 psi)- Input diameter
1.5 in
- Output diameter
1 in, 1.5 in
Description
Ratio 3:1 - 45 lpm
application: low/medium viscosity products
use: supply / transfer / recirculation
PUMP PERFORMANCE
Ratio: - 3:1 b
Max cycles / minute: - 60
Displacement per cycle: - 757 civil code
Air consumption @ 6 bar: - 1000 Nlpm
PUMP SPECIFICATIONS
Lower pump material: - Stainless Steel
Pumping stem material: - 316SS with HDCC ceramic coating
cylinder material: - 316L Stainless Steel
Seal set: - Teflon + UHMW – PE special compound
Air motor: - 2018
motor diameter: - 100mm
strokes: - 150mm
Multistage Diameter: - 100mm
Air inlet: - G 3/8″ (M)
