Air pressure regulator RY Series diaphragmsingle-stagebrass
Add to favorites
Compare this product
Characteristics
- Product
- for air
- Technology
- diaphragm
- Number of stages
- single-stage
- Material
- brass, stainless steel, zinc, POM, NBR, coated
- Applications
- industrial
- Other characteristics
- relieving
- Pressure
Max.: 10 bar
(145.04 psi)Min.: 0.2 bar
(2.9 psi)- Flow
Max.: 14,000 l/min
(3,698.41 us gal/min)Min.: 1,000 l/min
(264.17 us gal/min)- Temperature
Max.: 50 °C
(122 °F)Min.: -10 °C
(14 °F)
Description
Temperature range :-10°C ... +50°C
Input range max. :16 bar ( size Y0 max. 12 bar )
Mounting :arbitrary
Medium :compressed air according to ISO 8573-1:2010, neutral gases
Materials: Body: Grivory (PA66) and POM, seals: NBR,inner parts: zinc coated steel, stainless steel and brass
Pressure regulator with diaphragm and relieving feature.Locking: rotary lock and padlock possible.
