Ball valve SE seriespneumatically-operatedfor airaluminum
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- pneumatically-operated
- Media
- for air
- Material
- aluminum, anodized aluminum, NBR
- Associated function
- exhaust, quick-release exhaust
- Other characteristics
- ISO, with seal, ATEX
- DN
Max.: 16 mm
(0.63 in)Min.: 5 mm
(0.197 in)- Pressure
Max.: 10 bar
(145 psi)Min.: 0.5 bar
(7.3 psi)- Temperature
Max.: 70 °C
(158 °F)Min.: -10 °C
(14 °F)- Flow rate
Max.: 5,600 l/min
(1,479.36 us gal/min)Min.: 600 l/min
(158.5 us gal/min)
Description
Medium
Filtered, oil-free and dried compressed air according to ISO 8573-1:2010, Class 7:2:4, instrument air, free of aggressive additives. Alternatively the pressure dew point must be at least 10°C below lowest occurring ambient temperature.
Materials Body: Al (anodized), seals: NBR
Valves in accordance with 2014/34/EU (ATEX) available. (Chapter 13)
A quick exhaust valve is used to increase the speed of a pneumatic cylinder. The flow from the control valve to the cylinder ports is unrestricted. If valve port 1 is de-pressurized, air is exhausted from 2 to 3.
