Rack-mount power supply XG 1500

DCprogrammable

The XG 1500 is an industry-leading programmable DC power supply designed for testing, production, laboratory, OEM, and quality assurance applications. The XG 1500 is a 1500 Watt, 1U programmable DC power supply with constant voltage and constant current modes, automatic cross-over, and numerous features enabling cost-effective, easy integration. Features And Benefits Easy Integration XG 1500 DC power supply has many control and indication signals such as shutdown, constant voltage (CV) vs. constant current (CC) mode indication, OVP, OCP, OTP, and so on. In addition, the logical high or -low is free selectable. Thus, enabling the XG 1500 to replace existing DC power supplies with little or no system engineering required. Free selectable analog control range Most DC power supplies provide a 0 to 5 or 0 to 10 V analog control range to control the DC output from zero to full DC output range. With the XG 1500 variable DC power supply, the analog control range is free selectable starting at 0V to an upper range between 2V and 10V. In other words, the analog programming interface range is freely adjustable. Auxiliary DC output channels with control In many ATE systems one or more low-power, fixed-voltage supplies are needed to provide electrical power for any periphery within the ATE cabinet. For this purpose, the XG 1500 DC output power supply provides two standard auxiliary DC output channels. Both auxiliary power channels are controllable directly from the front panel or through SCPI commands. With these channels, it is possible to drive output-disconnect or polarity-reversal relays, without needing a complicated computer-controlled relay board.
