Pit jack Adjustable 13 Tonne Twin Ram Pit Jack with Security Struts

hydro-pneumatic13 tonautomotive

Adjustable 13 tonne twin-ram commercial pit jack designed for vehicle inspection pits, fitted with Security Struts for enhanced safety. UK-made, air-over-oil hydraulic design with a fast-acting air pump and independently operable cylinders for precise positioning and reliable performance.

Key features

• Capacity: 13 Tonne
• 400 mm lifting stroke
• Available in three frame sizes with wide adjustment ranges for pit widths
• Fast-acting air pump for rapid operation
• Air-over-oil hydraulic system for high output and extended cylinder life
• Ergonomic handles for moving the unit along the pit
• Integrated tool tray for convenient access to tools and parts
• Independently operable cylinders and transversely sliding rams for accurate wheelpoint positioning
• Suitable for ATF & MOT test lanes
• Multiple safety layers: safety lowering valves, anti-burst valves, ram lock-off handles and Security Struts
• Delivered with accessories: 2×125 mm extensions, 2×Vee head adapters, 2×Dish head pansies, rear adapter rack holder and air blow gun
• UKCA / CE marked; conforms to EC regulations
• 5 year warranty (T&Cs apply)

Range of adjustment by frame size

• Small — Pit min 750 mm; Pit max 1030 mm
• Medium — Pit min 860 mm; Pit max 1160 mm
• Large — Pit min 1110 mm; Pit max 1410 mm

Construction & components

• Beam: covers pit widths from 750 mm to 1400 mm
• Wheels: beam runs on four wheels with needle roller bearings; parallel wheels standard for flat pit edges, tapered wheels for RSJ supporting rails; spring-loaded wheels available on request (retract under load to lock position)
• Power pack: high-output hand pump with delivery valve, preset overpressure valve and 'dead man' release for controlled high flow to cylinders
• Rams: two double-acting hydraulic cylinders, 400 mm stroke, chrome-plated rods and advanced seals; each cylinder fitted with hose burst valve and 90° isolation valve for visual position confirmation
• Warranty & compliance: 5 year warranty (T&Cs apply); designed and manufactured to Machinery Directive 98/37/EC and BS EN 1494:2001; complies with EC requirements and LOLER; each unit tested, serial numbered and supplied with test certificate

Technical specifications

• Capacity: 13 Tonne
• Lifting stroke: 400 mm
• Frame sizes / pit adjustment ranges: Small 750–1030 mm; Medium 860–1160 mm; Large 1110–1410 mm
• Beam pit width coverage: 750–1400 mm
• Included accessories: 2×125 mm extensions; 2×Vee head adapters; 2×Dish head pansies; rear adapter rack holder; air blow gun
• Safety features: safety lowering valves, anti-burst valves, ram lock-off handles, Security Struts
• Operation: air-over-oil hydraulic system with fast-acting air pump; independently operable cylinders; transversely sliding rams
• Suitable for: ATF & MOT test lanes
• Standards & marking: UKCA / CE marked; conforms to EC regulations; Machinery Directive 98/37/EC; BS EN 1494:2001; LOLER compliant
• Warranty: 5 years (T&Cs apply)
