Pit jack Adjustable 13 Tonne Pit Jack with Spring Loaded Ends

hydro-pneumatic13 tonfor lifting applications

The 13 Tonne Adjustable Pit Jack with Spring-Loaded Ends is a UK-made twin-ram commercial inspection pit jack designed for lifting trucks and other HGVs in inspection pits. It features adjustable beam sizes, spring-loaded retractable wheels for secure positioning and an air-over-oil hydraulic system for robust, long-life performance.

Key features

• Spring-loaded wheel system that retracts under load to lock the jack's position.
• Fast-acting air pump and air-over-oil hydraulic design for improved cylinder life and performance.
• Ergonomic handles and a tool tray for easy movement and convenient access to tools/parts while working.
• Cylinders can be operated independently; transversely sliding rams allow accurate positioning.
• Suitable for ATF and MOT test lanes.
• Triple layer of safety: safety lowering valves, anti-burst valves and ram lock-off handles. Security struts available as an optional extra and can be retrofitted.
• Comes included with: 2 x 125 mm extensions, 2 x vee head adapters, 2 x dish head pads, rear adapter rack holder and air blow gun.
• UKCA / CE marked and conforms to EC regulations.

Technical specifications

• Capacity: 13 Tonne.
• Lifting stroke: 400 mm.
• Beam: covering pit widths from 750 mm – 1400 mm (available in 3 sizes with a large range of adjustment).
• Wheels: spring-loaded wheels which retract when the jack is under load to lock its position.
• Power pack: high-output hand/air pump producing the high output flow to the cylinders.
• Rams: two double-acting hydraulic cylinders with 400 mm stroke; chrome-plated rods and modern seal technology; each cylinder fitted with safety hose burst valve and a 90° movement isolation valve for visual position confirmation. Cylinders operable independently.
• Safety & standards: triple safety features (safety lowering valves, anti-burst valves, ram lock-off handles); units fully tested, marked with serial number and supplied with a test certificate; designed/manufactured in accordance with Machinery Directive 98/37/EC and BS EN 1494:2001; complies with EC requirements and LOLER lifting regulations.
• Warranty: 5 year warranty (T&Cs apply).
