Electric chamfering machine GA322

portableorbitalprecision

Overview
The GA322 orbital beveling machine is built for precise, repeatable tube weld preparation across a wide diameter range. Tube OD range: 5.5 – 12.750" (141 – 328 mm). High-speed milling heads with carbide inserts remove material significantly faster than HSS tooling. The patented lubricant-free process reduces pre-weld cleaning and increases workshop throughput. The GA322 shares its frame with AXXAIR CC orbital cutting machines and can be converted for cutting or welding using dedicated conversion kits, offering an integrated solution for tube preparation.

Versatility
Suitable for industrial tube welding preparation where repeatability and consistent bevel quality are required. The machine accepts conversion kits and optional automatic rotation and clamping systems to increase productivity and enable three operations: cutting, beveling and welding.

Product advantages

• Concentric stainless-steel clamping system with multiple contact points: extends beveling range and minimises tube deformation; stainless jaws protect the tube surface from contamination.
• Distinctive rotation wheel ensures smooth rotation, improving insert life and bevel finish.
• Optional automatic rotation and clamping for higher repeatability and faster cycle times.
• Carbide inserts deliver faster material removal than HSS and are available standard in V-bevels (30° / 37.5° / 45°) and J-bevel (10°).
• Spring-loaded penetration lever and tracking system engage the saw blade for consistent, effortless beveling, improving safety and ease of use.
• Compatible with support benches for long tubes and conversion kits to perform cutting, beveling and welding with the same machine.

Specifications (table)
Description: GA322
Part No.: GA322-M1 / GA322-M2
Diameter range: 5.5 – 12.750" / 141 – 328 mm
Beveling wall thickness capacity*: Up to 0.3" / 8 mm
Milling head speed: 2050 – 7300 rpm
Electric motor power: 1700 W
Voltage: 110 or 220 V
Frequency: 50 / 60 Hz
Max acoustic radiation: 99 dB
Vibration level: < 2.5 m/s2
Unit weight: 71 kg / 157 lbs
Machine dimensions: 25.55 x 25.35 x 11.96" / 649 x 644 x 304 mm
Packing dimensions: 37.40 x 21.65 x 33.46" / 950 x 550 x 850 mm
Packing weight: 176 lbs / 80 kg
*depending on type of inserts used and tube material

Technical characteristics

• Model: GA322
• Part numbers: GA322-M1 / GA322-M2
• Tube outside diameter range: 5.5 – 12.750" (141 – 328 mm)
• Beveling wall thickness capacity: up to 0.3" (8 mm)
• Milling head speed: 2050 – 7300 rpm
• Motor power: 1700 W
• Voltage: 110 V or 220 V
• Frequency: 50 / 60 Hz
• Acoustic emission: 99 dB (max)
• Vibration level: < 2.5 m/s2
• Unit weight: 71 kg (157 lbs)
• Machine dimensions: 649 x 644 x 304 mm (25.55 x 25.35 x 11.96")
• Packing dimensions: 950 x 550 x 850 mm (37.40 x 21.65 x 33.46")
• Packing weight: 80 kg (176 lbs)
• Inserts: Carbide inserts standard (V-bevel 30° / 37.5° / 45°, J-bevel 10°)
