Dimension
169 x 134 x 63 mm (W x H x D)
Weight
0.5 Kg
Mount
Standard rail or bolts
Working Temperature
From -40ºC to 85 ºC
I/O Feature
Built-in digital inputs
12 (Optical coupling isolated input, 2 of them can be used as high-speed counters)
Built-in digital outputs
8 (Relay output)
Built-in analog inputs
8 (0-20mA or 0-5V)
Built-in high-speed impulse counters
2 single-phase or 1 two-phase (100 KHz impulse counting, can be used as 2 single-phase or 1 two-phase)
I/O state indicators
44 pcs.
Power Supply and power output
Power Supply
Rated Voltage
220V AC or 24V DC
Range
From 90V AC to 250V AC, 50Hz, or 24V DC
Isolated power output
Rated voltage
24VDC
Rated current
0.2A
Output resistance
About 20 Ohm
Terminals
VOUT(24V+, 24V-)
