Hot-wire cutting machine MAMMUT

for EPSfor extruded polystyrenepanel

Description
CNC hot wire cutter for large-format foams. The MAMMUT is designed for cutting EPS (expanded polystyrene), XPS (extruded polystyrene) and rigid foam with an accuracy of +/-0.03 mm. A direct evolution of the Infinity model, it is modular and expandable with a standard cutting area of X = 3,020 mm × Y = 1,250 mm, expandable to 4,500 mm or 6,000 mm with modular structure. Suitable for both industrial and craft productions: 3D letters and signs, insulating panels, molds, prefabricated elements and large-volume set pieces.

Applications

• Signage and visual communication: precise cuts and finishes
• Construction and thermal insulation: exterior insulating panels, roofing sheets, thermally insulating monoblocks, formwork
• Decoration and set design: decorative elements and large-volume set pieces
• Industrial packaging: insulating boxes, custom protective packaging, preforms for sensitive products
• Design and prototyping: conical, tapered and standard geometries
• Swimming pools and spas: preforms, components and lining elements
• Blinds and prefabricated elements: insulating boxes for blinds

MAMMUT Cutter Equipment
Expandable cutting area for blocks of any format with four sliding, pneumatically locking mobile boards and rollers for loading large polystyrene blocks. Automatic wire tensioning system with tilt for conical and tapered shapes. Titanium cutting wire available (0.25–0.50 mm selectable). Microprocessor temperature control for constant wire temperature. Axis travel accuracy guaranteed at +/-0.03 mm with axis speed up to 25 m/min. Nettuno Docker Cam operator interface with 3D preview and Corel Draw license included; portable handheld controller for operation from any point in the work area.

Construction and Engineering
Steel structure with flattened and machined profiles milled for rigidity and stability. Overall dimensions: 6,500 × 3,500 × 2,000 mm. Transmission: X axis rack-and-pinion + double linear guides; Y axis rolling screws + double linear guides. Brushless servomotors with absolute encoders. Power consumption 2 kW / 10 kW depending on configuration.

Options

• Extended cutting length: extendable structure up to 4,500 mm standard or up to 6,000 mm with modular roots
• Vertical rotary table: optional for radial cuts and revolution geometries
• Additional configurations and accessories: multi-axis combinations, vertical rotation, horizontal turn, MW for advanced cutting operations

More information
The MAMMUT features a modular structure on fixed roots and an automatic tilting tensioner enabling conical and tapered shapes, ensuring uniform cutting performance on long runs and large formats. Processable materials: EPS, XPS and rigid foam.

Technical specifications

• Overall dimensions: 6,500 x 3,500 x 2,000 mm
• Cutting area: X = 3,020 mm – Y = 1,250 mm (expandable)
• Table top: multiple mobile boards (marble-effect mobile boards with rollers)
• Cutting wire length: 1,300 > 4,500 mm (automatic setting)
• Axis speed: 25 m/min
• Number of axes: 5 + Vertical Rotation + Horizontal Turn + MW
• Accuracy: +/- 0.03 mm
• Type of cutting wire: Titanium (0.25–0.50 mm available)
• Wire tensioner: automatic (tilting)
• Wire temperature control: microprocessor (PC-controlled)
• Cutting wire diameter: 0.20 - 0.60 mm (recommended 0.25 - 0.50 mm)
• Processable foams: EPS, XPS, rigid foam
• Motors: brushless servomotors with absolute encoder
• Transmission: X: rack-and-pinion + double linear guides; Y: rolling screws + double linear guides
• Handheld controller: included
• Structure: steel with flattened and machined profiles
• Operator interface: Nettuno Docker Cam (3D preview)
• Corel Draw license: included
• Vertical turntable: optional
