Forklift broom 867M05 series

industrial

Description
The magnetic sweeper for forklift is designed for fast and safe collection of metallic debris such as nails, screws, chips and ferrous residues over large surfaces. It is ideal for cleaning operations in industrial environments, yards, storage areas and work zones where quick and efficient intervention is required.

Function and use
Mountable on a forklift, it allows collection of ferrous materials directly during normal handling operations, improving operator safety and reducing intervention times compared with manual operations. The integrated high-strength magnet ensures effective and continuous pickup of metallic debris, including small particles. After collection, material discharge is simple and controlled thanks to the assisted opening system operated by a stainless steel lever, allowing rapid release of ferrous residues at the desired location without effort or direct contact with the material.

Main features

• Suitable for forklift mounting
• Heavy-duty construction for industrial use
• High-efficiency magnet for ferrous debris collection
• Assisted opening for discharge via stainless steel lever
• Quick and safe discharge system
• Ideal for large surfaces and frequent interventions

Operational benefits

• Improves workplace safety
• Enables cleaning without direct manual intervention
• Reduces downtime and repetitive tasks
• Simple, fast and controlled discharge

Application sectors
Industry, warehouses, logistics, recycling.

Available versions (table)
Model | L (mm) | P (mm) | H (mm) | Magnetic force (kg) | A (mm) | B (mm) | C (mm)
867M0515 | 1500 | 600 | 280 | 85/100 | 210 | 75 | 640
867M0525 | 2500 | 600 | 300 | 145/160 | 220 | 85 | 640
867M0530 | 3000 | 600 | 300 | 175/190 | 220 | 85 | 640

Characteristics / technical specifications

• Series: 867M05 series (models 867M0515, 867M0525, 867M0530)
• Main dimensions by model: see table (L x P x H in mm)
• Indicated magnetic force by model: 867M0515 = 85/100 kg; 867M0525 = 145/160 kg; 867M0530 = 175/190 kg
• Fork pocket dimensions (mm): A, B, C respectively 210/220/220 x 75/85 x 640 depending on model (see table)
• Quick discharge operated by stainless steel lever
• Robust construction suitable for industrial use and forklift mounting
