Hydraulic torque wrench LPTW1

steelATEXfor heavy-duty applications

Overview
The LPTW-Series is a low-profile hydraulic torque wrench designed for confined-space bolting and industrial maintenance. Its modular power-head accepts interchangeable hex and square drive cassettes, covering metric sizes 19–185 mm and imperial sizes 3/4"–7 1/4". The tool delivers consistent torque with ±3% accuracy and is supplied in a hard protective case for transport and storage.

Key Features

• Versatility: Modular single power head compatible with multiple drive cassettes in Metric and Imperial ranges.
• Performance: High-efficiency alloy construction for faster cycle times and extended service life.
• Safety: Ergonomic safety handle to improve operator control and reduce risk during use.
• Compliance: CE and ATEX certified for use in regulated industrial environments.
• Recommendations: Use BVA Twinhoses to maintain hydraulic system integrity and achieve optimal performance.

Technical specifications

• Model: LPTW
• Rated torque (nameplate): 1754 Nm (1294 Ft/lbs) - 60720 Nm (44785 Ft/lbs)
• Material: Aluminum / Steel
• Weight: 3.3 kg (7.275 lbs) - 38.6 kg (85.1 lbs)
• Overall length: 159 mm (6.3 in) - 391 mm (15.4 in)
• Nominal torque rated at: 700 bar (10,000 psi)
• Minimum torque rated at: 70 bar (1000 psi)
• Accuracy: +/- 3%
• Cassette compatibility: 19 mm up to 185 mm; (3/4" up to 7 1/4")
• Includes: Hard protective case for transport and storage
• Certifications: CE, ATEX

Applications

• Confined-space bolting in industrial plants
• Flange and pipeline maintenance
• Petrochemical, power generation and offshore installations
• Heavy machinery assembly and maintenance
