Modular rack

for equipmentopen-frame

Overview
Custom rack systems for Carbolite standard furnaces and ovens, including associated control boxes, designed to stack or integrate multiple units to save floor space and meet specific process requirements. Configurations can include common control panels, integrated gas supplies and safe containment for toxic processes while maintaining individual furnace performance up to 1200°C.

Examples

• Three tube furnaces up to 1200°C installed in a safety cabinet with a common control box
• Four HTR 11/75 rotary reactor tube furnaces arranged in a space‑saving frame
• Four GHA 12/450 tube furnaces mounted in a single rack with a shared control panel
• Two pairs of special tube furnaces (12/230/450) built into a rack with an integrated gas system
• Three ovens with Nadcap compliance fitted into one frame with a common six‑channel chart recorder
• Twelve stacking PF 120 ovens configured for Nadcap processes

Technical features / specifications

• Bespoke rack design to accommodate multiple Carbolite standard furnaces, ovens and control boxes
• Space‑saving stacked arrangements and dedicated frames for tube furnaces and ovens
• Support for tube furnace ratings up to 1200°C (dependent on model)
• Options for shared control panels, common chart recorders and centralized monitoring
• Safety cabinet and containment solutions available for toxic or hazardous processes
• Integration options: gas delivery systems, rotary reactor units and application‑specific services
• Nadcap compliance achievable for specified multi‑oven stacked configurations
