Car wheel balancer ER10

the compact 3D balancer with digital touch display ER10 is an entry level wheel balancer with unbeatable features and quality, granted by the deep study of every single element. Mechanics developed with the help of computer simulations, electronics with touch-sensitive screen, never used before on machines belonging to such a market range, AutoAdaptive mode and innovative software Virtual Sonar which, in the absence of an actual sonar device, detects the rim width. Detection of wheel data The automatic gauge enables detection of distance and diameter (from 12″ to 28″) with relative activation of desired balancing program (clip-on or stick-on weights). No error due to manual inputs possible. The machine enables the operator to work according to his preferences. The correct application of counterweights can be selected in two different modes: with the accuracy of position repeater or the conventional 12 o’clock position. Virtual Sonar Virtual Sonar is the new CEMB software for a 3D wheel measurement which enables, in the absence of an actual sonar device, to detect the rim width. After having detected the first correction plane thanks to the automatic gauge, Virtual Sonar calculates the position of the external plane, according to the measured unbalance and the tolerance calculated with AutoAdaptive mode.
