Air rotary joint QCN0101-11Shydraulicpneumaticfor transfer
Add to favorites
Compare this product
Characteristics
- Medium
- for air
- Applications
- hydraulic, pneumatic, for transfer
- Material
- aluminium
- Other characteristics
- compact
- Rotational speed
Max.: 300 rpm
(1,884.96 rad.min-1)Min.: 0 rpm
(0 rad.min-1)- Pressure
8 bar
(116 psi)
Description
Air rotary joints also are known as rotary swivels, widely used in numerous manufacturing processes to transfer pneumatic or hydraulic. This is light weight, compact size, one air flow passage rotary union with aluminum alloy construction, interface G1/8'' and G3/8'' are optional.
Electrical noise - ≤35mΩ(50rpm)
Dielectric strength - ≥300V@50Hz
Insulation resistance
- 100MΩ@100VDC
Contact material - precious metals
Air channel - 1 air channel
Pressure - ≤ 8Bar
