Custom rotary unions
Pressure: 0 psi - 150 psi
Rotational speed: 0 rpm - 30 rpm
... 2-passage rotary union designed to supply a water/glycol mixture from truck-mounted chillers to a rotating turret deck to cool electronics aboard the nation's fastest and most advanced ...
Pressure: 310 bar
Rotational speed: 2 rpm
Nominal size: 8.44 in - 11.685 in
This 5-passage custom hydraulic swivel features an OEM design that integrate directly into the customer's tight envelope size and unique connection interfaces, a heavy-duty construction capable of withstanding the harsh ...
Pressure: 100, 145 psi
Rotational speed: 7 rpm
Nominal size: 9.45 in
The 3 passage rotary union is built specifically for filling application in carbonated beverage rotary. Its characteristics include a mounting configuration depending on customer stated ...
Pressure: 0 bar - 350 bar
Rotational speed: 15,000 rpm
Nominal size: 15 mm - 360 mm
For high pressures and speeds The tried-and-tested ROTOSTAT E sealing system uses a hydrostatically controlled radial gap seal, ensuring reliable operation even under the most demanding operating conditions. Extremely long service ...
Pressure: 2,031 psi
Rotational speed: 0 rpm - 30,000 rpm
Nominal size: 0.375 in
... seals made from silicon carbide for long life even under difficult operating conditions Compact size can be adapted for custom installations Anodized aluminum housing resists corrosion Media MQL, Coolant Rotor ...
Pressure: 17 bar
Rotational speed: 100 rpm
4-Way Hybrid rotation in the nominal 4 + 5. Steam and condensate in 4 + 5, time round air and water over small nominal widths. Execution as a prototype for the tobacco industry.
Pressure: 3,000 psi
Nominal size: 4 in
Machinery Workholding 8 Passages 1/4" NPT 3000 PSI Hydraulics Start Your Custom Project Today.
Pressure: 275 bar
Rotational speed: 120 rpm
Nominal size: 1 in
... Dimension: 1”NPT Fluid: water Temperature: 70° C Pressure: 275 bar Speed: 120 rpm Installation: Rotary union installed on progressive cavity pumping for the extraction of viscous ...
Pressure: 0 bar - 250 bar
Rotational speed: 0 rpm - 250 rpm
Nominal size: 80, 125, 135 mm
Multi passage rotary union Media Type Hydraulic Oil, Air - Vacuum Max. Speed 250 RPM Max. Pressure 250 Bar Max. Temperature 80 °C Rotor Size 2 x 1/4" - 12 x 3/4" Connection Type NPT, BSPP, BSPT Multi ...
Pressure: 0 bar - 20 bar
Rotational speed: 20 rpm
Nominal size: 0.5 in - 4 in
20 RPM+ as per design Coolant DN on request Up to 20 bar (290 Psi) Up to 120°C (248°F) Sealing system :Mechanical seal Steel indsutry - Roll mill - Cooling water Other configurations on request Technical ...
Rotational speed: 2,000 rpm
... Single Channel Fiber Optic Rotary Joint Single model single channel fiber optic rotary joint,Model Number: BTFO-01-01,Channel:Single channel,single model or multi-model.ByTune a diverse types slip ...
The rotary union, or call rotary joint, is used in the fluid and gas transferring industries widely. It provides a mechanical seal between a stationary supply pipe and a rotating ...
Rotary Unions are self-contained and self-supporting rotary seals used to transfer different media such as steam, water, air or oil from a stationary source to and from rotating ...
Pressure: 50 bar
Rotational speed: 100 rpm
Nominal size: 135 mm
... speed: 0~60RPM Working temperature: -10~90 centigrade Slip ring is designed to use to transmit power, signal or data, pneumatically or hydraulically from a stationary to a rotating platform. It ...
Rotary unions allow the transfer of liquids or gases into or out of a rotating part. Rotary joints, rotating joints are installed directly in or at machines, ...
Pressure: 515 bar
Rotational speed: 500 rpm
Nominal size: 0.125 in - 1 in
... GP and GPS (stainless steel) Series multiple passage rotary unions are available in 2, 3, 4, 6, 8, 10 & 12 passage models. They meet highly demanding requirements in terms of pressure and rotating ...
