Air cooling system MQL

Product Overview

• High accuracy: runout ≤0.03 mm before and after clamping
• Precise positioning: accurate pinpointing of heating position
• Multi-function: manual or automatic heating and air-cooling with adjustable parameters
• Compact design: space-saving body for easy operation
• Operator interface: 7-inch touchscreen with responsive, intuitive controls and logical functional layout
• Compatibility: supports standard, enhanced-type and light-type tool holders
• Customizable: tool holder materials and types tailored to machining requirements
• Data visualization: displays and records tool type, heating cycle count, heating time and cooling time

Application Cases
Suitable for clamping and dismounting of precision shrink-fit tool holders.

Technical Parameters
Item | A-312 | S-312
Material | Alloy Steel | Stainless Steel
Tool Range | D3-D12 | D3-D12
Cooling Method | Air-cooling | Air-cooling
Coil Inner Diameter | ⌀45 | ⌀45
Tool Holder Diameter | Max. ⌀24 at small end | Max. ⌀24 at small end
Heating Time | 6-16s | 12-30s
Cooling Time | 150-180s | 120-150s
Weight | 38 kg | 38 kg
Power | 3.5 kW | 3.5 kW
Dimension (LxWxH) | 540 x 450 x 810 mm | 540 x 450 x 810 mm

Technical specifications

• Models: A-312, S-312
• Material: A-312 — Alloy Steel; S-312 — Stainless Steel
• Tool Range: D3-D12 (both models)
• Cooling Method: Air-cooling (both models)
• Coil Inner Diameter: ⌀45 (both models)
• Tool Holder Diameter: Max. ⌀24 at small end (both models)
• Heating Time: A-312 — 6–16 s; S-312 — 12–30 s
• Cooling Time: A-312 — 150–180 s; S-312 — 120–150 s
• Weight: 38 kg (both models)
• Power: 3.5 kW (both models)
• Dimension (LxWxH): 540 x 450 x 810 mm (both models)
