Brushless motor BS10413NFLBLDCDC48 V
Add to favorites
Compare this product
Characteristics
- Type
- brushless, BLDC, DC
- Voltage
- 48 V
- Applications
- for collaborative robots, for robotics, for humanoid robot
- Other characteristics
- with brushless DC motor
- Power
0.31 kW
(0.42 hp)- Intensity
4 A
- Torque
2.3 Nm
(1.696393 ft.lb)- Rotational speed
Max.: 850 rpm
(5,340.7075 rad.min-1)Min.: 640 rpm
(4,021.2386 rad.min-1)- Diameter
104 mm
(4.09 in)
Description
Product overview
BS10413NFL is a brushless DC motor with a 104 mm diameter and 21.5 mm length. Rated voltage is 48 V with a maximum output power of 310 W. Nominal speed and torque are 640 rpm and 2.3 N·m respectively; no-load speed is 850 rpm.
Applications
Customizable options
Pricing
Unit price: Quote based on customer quantity and solution requirements.
Characteristics / Technical specifications
BS10413NFL is a brushless DC motor with a 104 mm diameter and 21.5 mm length. Rated voltage is 48 V with a maximum output power of 310 W. Nominal speed and torque are 640 rpm and 2.3 N·m respectively; no-load speed is 850 rpm.
Applications
- Collaborative robots
- Mechanical arm
- Humanoid robot
Customizable options
- Specifications
- Wire length
- Performance
- Gearbox
Pricing
Unit price: Quote based on customer quantity and solution requirements.
Characteristics / Technical specifications
- Voltage: 48.0 V
- Line resistance: 1.8 Ω
- Line inductance: 1.7 mH
- No-load speed: 850 rpm
- No-load current: 0.2 A
- Stall torque: 14.5 N·m
- Stall current: 26.7 A
- Nominal torque: 2.30 N·m
- Nominal speed: 640 rpm
- Nominal current: 4.0 A
- Max. output power: 310 W
- Max. efficiency: 86 %
- Back-EMF constant: 56.0 mV/rpm
- Torque constant: 0.540 N·m/A
- KV value: 17.7 rpm/V
- Speed/torque gradient: 59 rpm/N·m
- Rotor inertia: 1256 g·cm²
- Weight: 405 g
