Hydrocarbon hose

for crude oilnitrileViton®

Overview
Continental single and double carcass marine hoses are designed for FPSO tandem offloading operations. Manufactured to OCIMF and GMPHOM 2009 guidelines, they are available in standard and customised constructions to suit reeled, catenary or stationary installations. API 17K-compliant variants are offered for applications requiring extended service life and reduced intervention, including submarine catenary systems.

Sustainable Benefits

• Low environmental risk: Proven track record in demanding marine environments; double carcass anti-pollution hoses with integrated leak detection can be supplied for both floating and submarine service to minimise spill risk.
• Long service life: Optimised reinforcement materials and construction deliver high fatigue resistance and extended operational lifetime, reducing total operating costs. API 17K submarine hoses provide a long-life option where required.

Technical Specifications

• Full range of hoses to GMPHOM 2009 available
• Range of inner linings: Nitrile, HNBR and FKM (VITON)
• API 17K compliant options for catenary and non-floating applications
• Single carcass and double carcass designs with leak detection
• Pressure ratings: GMPHOM up to 21 bar; API 17K up to 50 bar
• Customised hose design and manufacturing to meet operational requirements
• Buoyancy variants: extra, reduced or negative buoyancy
• Polyurethane and anti-marine growth covers available
• System design services and troubleshooting support available
