Stainless steel cartridge heater
high-temperaturetubular

stainless steel cartridge heater
stainless steel cartridge heater
stainless steel cartridge heater
stainless steel cartridge heater
Add to favorites
Compare this product


Characteristics

Material
stainless steel
Other characteristics
high-temperature, tubular
Diameter

Min.: 6.5 mm
(0.26 in)

Max.: 100 mm
(3.94 in)

Length

Min.: 50 mm
(1.97 in)

Max.: 500 mm
(19.69 in)

Power

Min.: 0.01 kW
(0.01 hp)

Max.: 300 kW
(407.89 hp)

Description

Made in Italy Standard dimensions: inches 1/4″ – 3/8″ – 1/2″ – 5/8″ and/or in millimetres: 8mm – 10mm – 12.5mm – 14mm – 16mm – 20mm. Realized also on project according to customer specifications. TYPES: LOW (LD), MEDIA (MD) AND HIGH DENSITY (HD) according to the power output (W/cm²). OPERATING TEMPERATURE: MAX 750°C (HD) Construction: Tubular ceramic core Resistive wire* spiraled around the core Electrical insulation of the filament with first choice MAGNESIUM OXIDE. Protective outer tubular armour in stainless steel ________________________________ * Iron-chromium-aluminium alloy (FeCrAl). DIAMETER and TYPE defined according to the type of use. Category: Cartridge heaters Additional information Areas of use Agriculture, Food, Industrial, Packaging, Plastic and metal moulding Applications AIR heating, SOLID heating

Catalogs
