Differential residual current circuit breaker 03424

single-phaseresidual currentsingle-pole

Overview
Residual-current circuit breaker (RCD) 1P+N, rated current 63 A, residual sensitivity 30 mA, Type A. Designed to protect personnel by detecting earth leakage currents including AC and pulsating DC components (Type A). Complies with EN 61008-1 and is intended for residential, commercial and industrial installations in accordance with NF C15-100.

Details

• Reference : 03424
• Function : Residual-current protection
• Rated operational voltage (Ue) : 240 Vac
• Number of poles : 1P+N
• Rated current : 63 A
• Type : A
• Residual sensitivity : 30 mA
• Standard : EN 61008-1
• Weight : 0.400 kg

Technical specifications

• Function: Residual-current protection for personnel and equipment
• Rated operational voltage (Ue): 240 Vac
• Number of poles: 1P+N
• Rated current: 63 A
• Type: A (detects AC and pulsating DC residual currents)
• Residual sensitivity: 30 mA
• Standard: EN 61008-1
• Weight: 0.400 kg
• Product reference: 03424
