Optical sorting machine MCV_BELT

automaticfor vegetablesfor separation units

100% inspection and sorting machine with conveyor belt, characterized by high productivity at a low price. Optimized for optical dimensional inspection of pins, studs, and other cylindrical components with main development along the axis of symmetry (recommended length-to-diameter ratio > 2), with diameters in the 3-25 mm range and lengths in the 7-70 mm range, it can also be used for light bolts. The machine works by Dimac MCVx 2.0 vision software and control system, supported by Dimac PLC-managed handling system. AVAILABLE FUNCTIONS Multilanguage, user-friendly interface for the free creation of new recipes Unlimited number of recipes and control plans Sorting statistics, measurements, and defects reports available for ERP exchange Users’ login is regulated by password and hierarchical privileges Offline monitoring Data backup system by UPS Close circuit air conditioning, IP 55 electrical cabinet, Fanless PC for dust and oil protection All Dimac machines are built to be upgradable OPTIONAL EXTRA Additional 3rd Exit chute for specific defect selection Isolation transformer Bar code reader to load recipes Metering for power and air consumption (Transaction 5.0 compliance) Data collection in real-time Offline programming Loaders and vibrating hoppers Boxing machines MSA /metrological report at the delivery and periodically Guarantee expansion and maintenance programs Pay-per-use renting formula
