Modular formwork UniKit

framebeamslab

Overview
Doka UniKit is a modular engineering kit for transferring and supporting heavy loads in infrastructure and industrial construction. The system uses standardized components with smart connections for fast, interface-free assembly alongside Doka formwork and scaffolding equipment. Components can be configured project-specifically and are supported by Doka planning and rental services.

Key applications

• Shoring towers for temporary support under slabs and beams (480 kN and 1000 kN classes)
• Truss spans and temporary support structures — Truss 1250
• Primary and secondary beam supports for large-span formwork and load transfer

Product components & highlights

• Shoring tower 480: transfers up to 480 kN per leg for medium heavy-duty support.
• Shoring tower 1000 & Load bearing frame 1000: transfers up to 1000 kN per leg for high-capacity applications.
• Truss 1250: engineered for spans ranging from 15 to 21 m.
• Connectable primary and secondary beams: high load-bearing capacity with compact jobsite footprint.
• Modular standard parts and smart connections designed for rapid assembly and disassembly (plug & play).
• Interface-free integration with Doka formwork and scaffolding systems for streamlined workflows.

Services & supply
Doka supports UniKit with planning services (shoring and formwork planning), professional rental workflows, worldwide supply of systems and accessories, and on-demand assembly/disassembly services. Standardized parts and procedures optimize utilisation and rental-park efficiency.

Your benefits / system advantages

• Consistent planning and coordinated solutions for safe load transfer across construction phases.
• Fast, efficient assembly due to modular plug & play design.
• Professional rental processes reduce on-site complexity and improve cost-effectiveness.
• Reliable global supply and fast delivery of equipment and accessories.
• Project-specific assembly/disassembly and technical support available on request.

Technical specifications

• Modular engineering kit for heavy loads
• Shoring tower capacities: up to 480 kN/leg and up to 1000 kN/leg
• Truss type: UniKit Truss 1250 (suitable spans: 15–21 m)
• Connectable primary and secondary beams with high load-bearing capacity
• Load bearing frame available (1000 kN class)
• Designed for interface-free integration with Doka formwork and scaffolding systems
• Modular standard parts and smart connections for fast assembly (plug & play)
• Supported by Doka planning, rental, supply and assembly/disassembly services
