Solid set of drill bits A095206

for plasticsfor non-ferrous metalsfor cast iron

Product overview
HSS twist drill A095206 from DORMER manufactured to DIN 338. Delivered as a 29-piece set covering diameters from 1 to 13 mm in 0.5 mm increments. Type N geometry with 4×D length and tin-coated tip for standard drilling operations.

Technical specifications

• Reference: A095206
• Standard: DIN 338
• Material: HSS (high-speed steel)
• Diameter range: 1 - 13 mm (0.5 mm step)
• Designation: Type N, 4×D
• Delivery: 29-piece spiral drill set
• Tip/coating: tin-coated tip

Applications

• Drilling of mild and alloyed steels, cast iron, non-ferrous metals and plastics
• Suitable for drill presses, CNC machines and stationary drilling equipment
• Intended for general-purpose metalworking in industrial environments

Packaging and ordering
Supplied as a compact 29-piece set covering the stated diameter range. Check product reference A095206 when ordering.

Notes
Conforms to DIN 338. Compatible with standard drill chucks. Follow recommended cutting speeds, feeds and lubrication for the drilled material; drills can be resharpened where applicable.
