Primary shredder MSC‑E series

four shaftfor electronics scrapheavy-duty

Product description
Four-shaft industrial shredder MSC‑E series. Designed to process end-of-life lithium batteries using four counter-rotating cutting shafts. Cutting knives are made of wear-resistant alloy with replaceable tips for rapid servicing and reduced downtime. Low energy consumption and reliable operation under heavy-duty conditions. Built for safe and efficient mechanical pre-processing in battery recycling lines.

Processed materials
For recycling (after disassembly and full discharge):

• Cylindrical cells including 18650, 21700, 4680 and similar
• Prismatic hard-case cells
• Pouch (soft-pack) cells
• Prismatic plate-type cells
• Small battery modules

Limitations: not recommended for shredding parts with high-strength bolts > 8 mm diameter, steel or aluminum sheets thicker than 2 mm, stainless steel sheets thicker than 1 mm.

Key components

• Modular knife system: replaceable cutting modules in wear-resistant alloys (9CrSi, 55SiCr, etc.) to extend service life and simplify maintenance
• Detachable cutting chamber: full disassembly capability to maintain shaft and housing concentricity
• Heavy-duty planetary gearbox: gears from high-strength cast/forged material with heat treatment for long service life
• Electrical control: PLC-based control (SIEMENS/SCHNEIDER), HMI touchscreen, premium electrical components for stable operation
• Sealing system: multi-layer dust and moisture protection to extend bearing life
• Auxiliary units: optional feeding modules and a rotary screen for particle size control for downstream processes
• Splined shaft: splined connection between gearbox and main shaft for high contact area and impact resistance

Technical specifications

• Model: MSC‑E900S — Blade diameter: φ290 mm; Shaft speed: 15–25 MP; Blade thickness: 25 mm; Number of blades: 32*2; Chamber size: 900×800 mm; Motor power: 18.5*2 kW; Machine size: 2400×1550×2500 mm; Weight: 4700 kg
• Model: MSC‑E900L — Blade diameter: φ290 mm; Shaft speed: 15–25 MP; Blade thickness: 25 mm; Number of blades: 40*2; Chamber size: 900×1000 mm; Motor power: 18.5*2 kW; Machine size: 2600×1550×2500 mm; Weight: 5000 kg
• Model: MSC‑E1000S — Blade diameter: φ320 mm; Shaft speed: 15–25 MP; Blade thickness: 40 mm; Number of blades: 25*2; Chamber size: 1000×1000 mm; Motor power: 22*2 kW; Machine size: 2900×1700×2800 mm; Weight: 6600 kg
• Model: MSC‑E1000 — Blade diameter: φ320 mm; Shaft speed: 15–25 MP; Blade thickness: 40 mm; Number of blades: 30*2; Chamber size: 1000×1200 mm; Motor power: 22*2 kW; Machine size: 3100×1700×2800 mm; Weight: 7100 kg
• Model: MSC‑E1000XL — Blade diameter: φ320 mm; Shaft speed: 15–25 MP; Blade thickness: 40 mm; Number of blades: 30*2; Chamber size: 1000×1400 mm; Motor power: 22*2 kW; Machine size: 3300×1700×2800 mm; Weight: 7600 kg
• Model: MSC‑E1300S — Blade diameter: φ430 mm; Shaft speed: 10–25 MP; Blade thickness: 50 mm; Number of blades: 24*2; Chamber size: 1300×1200 mm; Motor power: 30*2 + 15*2 kW; Machine size: 4100×2000×3100 mm; Weight: 15600 kg
• Model: MSC‑E1300L — Blade diameter: φ430 mm; Shaft speed: 10–25 MP; Blade thickness: 50 mm; Number of blades: 28*2; Chamber size: 1300×1400 mm; Motor power: 30*2 + 15*2 kW; Machine size: 4300×2000×3100 mm; Weight: 16000 kg
• Model: MSC‑E1300XL — Blade diameter: φ430 mm; Shaft speed: 15–25 MP; Blade thickness: 50 mm; Number of blades: 32*2; Chamber size: 1300×1600 mm; Motor power: 30*2 + 15*2 kW; Machine size: 4500×2000×3100 mm; Weight: 17000 kg
