Plastic film flexographic press FlexiProof 630

for papercartonfor aluminum foil

Overview
The FlexiProof 630 is a bench-top flexographic proofing press designed to produce fast, reliable print samples with solvent-based, water-based or UV flexographic inks. It is intended for ink manufacturers, converters and laboratories involved in quality assurance, R&D, proofing and computer-assisted colour formulation.

Special features

• Variable printing speed up to 100 m/min to accommodate low-viscosity inks
• Choice of chrome-plated or ceramic anilox rollers
• Minimal ink volume consumption for economical sampling
• Digital displays for precise settings between anilox, plate and printing rollers
• Capable of printing on a wide range of flexible substrates: paper, film, PVC, foil, tissue
• Maximum printing areas vary by configuration (see technical data)
• Compact, easy-to-clean design suitable for bench-top use

Scope of delivery

• FlexiProof 630, power supply 230 V, 50/60 Hz (other voltages on request)
• Ceramic anilox roller with standard engraving
• FlexiProof cliché/plate roller
• Doctor blade
• 5 spare doctor blades
• 50 proofing sheets (matt/glossy)
• 50 disposable pipettes
• Allen key
• Operating instructions

Technical data

• Model: FlexiProof 630
• Drive: Electric
• Printing width: 75 mm
• Ink types: Solvent-based, water-based, UV
• Supported substrates: Flexible paper, board, film, foil and tissue
• Bench space required: 55 cm (W) x 45 cm (D)
• Printing speed: Variable 20–99 m/min (up to 100 m/min depending on configuration)
• UV lamp: 200 W/cm² peak; wavelength 310–370 nm
• LED lamp options: FJ200 16 W/cm² at 395 nm; FJ100 12 W/cm² at 395 nm (385 & 405 nm available)
• UV power supply: 220–240 V, 50/60 Hz, 15 A single phase
• UV powerpack dimensions: 40 x 40 x 20 cm — ≈25 kg
• Standard plate thickness: 1.14 mm + 0.5 mm cushion mount (other sizes available)
• Weight: approx. 45 kg net — 51 kg gross
• Power supply options: 220–240 V or 100–120 V, 50/60 Hz
• Substrate sizes and max printing areas vary by configuration: examples include 297 x 105 mm (half A4) with max print area 240 x 75 mm; alternative formats: 60 x 240 mm; FlexiProof 100/UV+UVLED variant: substrate 125 x 105 mm, max print area 90 x 75 mm

Technical specifications

• Model: FlexiProof 630 — bench-top flexographic proofing press
• Drive: Electric
• Printing width: 75 mm
• Ink compatibility: Solvent, water, UV
• Max printing area (typical): up to 240 x 75 mm (depends on configuration)
• Suitable substrates: paper, film, foil, board, tissue
• Typical bench footprint: 55 cm x 45 cm
• Operational speed range: 20–99 m/min (variable)
• UV curing: 200 W/cm² peak; LED curing options available
• Net weight: ~45 kg
