LED light booth Light4Color 400-S

color viewingcolor matching

Product overview
The LED-based light booth is designed for daily industrial color matching and quality control. It provides switchable CIE D50 (5000 K) and CIE D65 (6500 K) illuminants plus an UV-ONLY (UV-A) option. The Light4Color 400-S integrates a prismatic UV-trans pane and an aluminum housing to deliver uniform, standardized viewing conditions for color assessment.

Key features

• Innovative, cost-effective LED-based light box
• LED technology for stable spectral characteristics and long lifetime
• Expected life of > 50,000 hours
• Instant-on; dimmable without color shifts, suitable for soft proofing
• Shadow- and glare-free CAD-based prismatic diffuser
• Switchable D50 / D65 (5000 K and 6500 K) illuminants
• UV component switchable on / off (UV-A)
• Two memory presets

High performance LED-based viewing light

• Unmatched light distribution uniformity
• High uniformity and optimal spectral characteristics
• D50 exceeds ISO 3664:2009 standards
• D65 exceeds ISO 3668 standards
• UV-ONLY: UV-A for detection of optical brighteners
• CRI (Ra): ≥ 95; Metamerism index (visible) MIvis: ≤ 0.8; MIuv: ≤ 0.6
• USB interface for dimming and softproofing capabilities
• Maintenance free; no tube replacement

Light / Spectral information
Provides CIE D50 (5000 K), CIE D65 (6500 K) and UV-ONLY (UV-A) illuminants; spectral distribution available for D50, D65 and UV-A.

Standards

• ISO 3668
• ISO 3664
• ASTM D1729-16

Characteristics / technical specifications

• Model: Light4Color 400-S
• Pane: Special prismatic pane UV-Trans
• Housing: Aluminum
• Connection: Power cable, angled plug type 303 to IEC connector type 601
• Light types: CIE D50 (5000 K), CIE D65 (6500 K), UV-ONLY (UV-A)
• Operating mode: S1: Continuous operation
• Product weight: 10 kg
• Protection class: IP 52
• Voltage / frequency: 50 / 60 Hz
• Chromaticity error: < 0.002
• Radiant power (UV-ONLY): 6 W
• Illuminated area (WxD): 64 x 36 cm
• Max. current consumption: 0.2 A
• Dominant wavelength (UV-ONLY): 365 nm
• External dimensions (WxHxD): 70 x 71 x 43 cm
• Metamerism index (UV range): ≤ 0.6
• Metamerism index (visible range): ≤ 0.8
• Ra (Color rendering index): >= 95
• Permissible ambient temperature: 0°C - 40°C
• Exact target chromaticity (10°): D50: x = 0.3478 y = 0.3595 (≤ 0.002); D65: x = 0.3138 y = 0.3309 (≤ 0.002)
• Expected lifespan in continuous operation: > 50,000 h
• Risk assessment (DIN-EN-62471): D65+UV / D50+UV: RG0; UV-ONLY: RG1
• Max. electrical power / Operating electrical power: 45 W / 40 W
