Water hose Metalpress Chemical®foodstuffthermoplastic rubberTPV
Add to favorites
Compare this product
Characteristics
- Use
- for water, foodstuff
- Material
- thermoplastic rubber, TPV, galvanised steel, polyester
- Applications
- suction, transfer, for chemical applications, FDA, low-temperature
- Other characteristics
- flexible, chemical-resistant, standard, reinforced, spiral
- Inner diameter
Min.: 20 mm
(0.787 in)Max.: 102 mm
(4.016 in)- Pressure
16 bar, 30 bar, 36 bar, 42 bar, 48 bar
(232.06 psi, 435.113 psi, 522.136 psi, 609.158 psi, 696.181 psi)- Temperature
Min.: -25 °C
(-13 °F)Max.: 80 °C
(176 °F)- Delivered length
30 m
(98'05" )
Description
Thermoplastic rubber (TPV) hose with double reinforcement - textile and metal spiral - for suction and transfer of products in the chemical industry (see chemical resistance chart).
Applications
Transfer of drinking water, dairy food liquids and those that are consistent with the declaration of conformity (FDA 21 CFR Section 177,2600, ANSI/NSF Standard 51: "Food Equipment" and NSF/Ansi Standard 61: "Drinking Water System Components "). Very flexible, even at low temperatures.
