Safety switch CES-I-BR-CC-FLX-C07-SA-165914

IP67IP65IP69K

• Suitable for actuator with same coding • Several devices can be connected in series, max. 20 • Switch chains up to 200 m long • 2 safety outputs (semiconductor outputs) • Short circuit monitoring • Diagnostic information via BR IO-Link Gateway • Category 4 / PL e according to EN ISO 13849-1 • Unicode • Three active faces • Plug connector M12, 8-pin (aligned) Industry 4.0 ready The switch can communicate in combination with an EUCHNER BR IO-Link Gateway, and sends process and device data to higher-level control systems. Comprehensive diagnostic messages enable rapid and targeted troubleshooting. Unicode evaluation The actuators of a packaging unit must be assigned to the safety switch by a teach-in operation so that they are detected by the system. This unambiguous assignment ensures a particularly high level of protection against tampering. The system thus possesses a high coding level. The coding is identical for all the actuators in a packaging unit. Actuators from different packaging units are coded differently. Only one actuator from a packaging unit has to be taught-in. All other actuators from the same package can be used without an additional teach-in operation. The switch detects only taught-in actuators. When an actuator from a new packaging unit is taught-in, the code for actuators from the previous packaging unit is disabled.
